5052-H32 Sheets and Plates

5052 Aluminum Sheets

5052-H32 Aluminum Sheets

Technical Data
Part # Thickness Thickness Tolerance Width Length Width/Length Tolerance Price
DMS-2796 0.032" ±0.0025" 12" 12" ±0.125" $16.58
DMS-2795 0.032" ±0.0025" 12" 24" ±0.125" $30.02
DMS-2794 0.032" ±0.0025" 24" 24" ±0.125" $57.36
DMS-2793 0.032" ±0.0025" 24" 48" ±0.125" $112.50
DMS-2783 0.040" ±0.0035" 12" 12" ±0.125" $20.20
DMS-2790 0.040" ±0.0035" 12" 24" ±0.125" $34.48
DMS-2798 0.040" ±0.0035" 24" 24" ±0.125" $62.02
DMS-2788 0.040" ±0.0035" 24" 48" ±0.125" $124.02
DMS-2786 0.050" ±0.0035" 12" 12" ±0.125" $24.38
DMS-2785 0.050" ±0.0035" 12" 24" ±0.125" $46.62
DMS-2784 0.050" ±0.0035" 24" 24" ±0.125" $88.15
DMS-2846 0.050" ±0.0035" 24" 48" ±0.125" $165.06
DMS-2816 0.080" ±0.0045" 12" 12" ±0.125" $35.50
DMS-2878 0.080" ±0.0045" 12" 24" ±0.125" $72.00
DMS-2877 0.080" ±0.0045" 24" 24" ±0.125" $130.15
DMS-2876 0.080" ±0.0045" 24" 48" ±0.125" $229.86
DMS-2874 0.125" ±0.0055" 12" 12" ±0.125" $60.02
DMS-2865 0.125" ±0.0055" 12" 24" ±0.125" $99.04
DMS-2872 0.125" ±0.0055" 24" 24" ±0.125" $179.09
DMS-2880 0.125" ±0.0055" 24" 48" ±0.125" $316.33

  Mirrored #8 Finish

5032-H32 Aluminum Sheets

ASTM-B209, ADMS-QQ-250/2

Note: #4 & #8 Finish have PVC Peel Film Protection
Part # Thickness Thickness Tolerance Width Length Price
#4 Brushed Satin
DMS-4191 0.032" +/-.002 12" 12" $50.06
DMS-4183 0.032" +/-.002 12" 24" $71.68
DMS-4208 0.032" +/-.002 24" 24" $135.18
DMS-4190 0.040" +/-.004 12" 12" $56.34
DMS-4182 0.040" +/-.004 12" 24" $80.68
DMS-4207 0.040" +/-.004 24" 24" $152.14
DMS-4189 0.062" +/-.006 12" 12" $66.10
DMS-4181 0.062" +/-.006 12" 24" $112.94
DMS-4206 0.062" +/-.006 24" 24" $213.04
DMS-4188 0.080" +/-.006 12" 12" $71.86
DMS-4180 0.080" +/-.006 12" 24" $122.80
DMS-4205 0.080" +/-.006 24" 24" $231.62
DMS-4187 0.105" +/-.007 12" 12" $79.78
DMS-4179 0.105" +/-.007 12" 24" $136.36
DMS-4204 0.105" +/-.007 24" 24" $257.20
DMS-4178 0.125" +/-.007 12" 12" $98.02
DMS-4201 0.125" +/-.007 12" 24" $167.54
DMS-4194 0.125" +/-.007 24" 24" $316.04
DMS-4185 0.187" +/-.010 12" 12" $128.32
DMS-4203 0.187" +/-.010 12" 24" $219.34
DMS-4202 0.187" +/-.010 24" 24" $413.78
DMS-4186 0.250" +/-.014 12" 24" $274.50
DMS-4193 0.250" +/-.014 12" 12" $160.60
DMS-4210 0.250" +/-.014 24" 24" $517.86
#8 Mirror Finish
DMS-4200 0.032" +/-.002 12" 12" $60.18
DMS-4174 0.032" +/-.002 12" 24" $86.18
DMS-2520 0.032" +/-.002 24" 24" $162.52
DMS-4148 0.040" +/-.004 12" 12" $71.48
DMS-4173 0.040" +/-.004 12" 24" $102.34
DMS-2510 0.040" +/-.004 24" 24" $193.04
DMS-4147 0.062" +/-.006 12" 12" $81.30
DMS-4172 0.062" +/-.006 12" 24" $138.96
DMS-2509 0.062" +/-.006 24" 24" $262.10
DMS-4146 0.080" +/-.006 12" 12" $87.06
DMS-2539 0.080" +/-.006 12" 24" $148.80
DMS-2508 0.080" +/-.006 24" 24" $280.68
DMS-4168 0.105" +/-.007 12" 12" $95.00
DMS-2538 0.105" +/-.007 12" 24" $162.36
DMS-2507 0.105" +/-.007 24" 24" $306.26
DMS-4170 0.125" +/-.007 12" 12" $111.34
DMS-2560 0.125" +/-.007 12" 24" $190.28
DMS-2527 0.125" +/-.007 24" 24" $358.96
DMS-4153 0.187" +/-.010 12" 12" $144.46
DMS-2562 0.187" +/-.010 12" 24" $246.92
DMS-2511 0.187" +/-.010 24" 24" $465.82
DMS-4175 0.250" +/-.014 12" 12" $192.86
DMS-2545 0.250" +/-.014 12" 24" $329.66
DMS-2513 0.250" +/-.014 24" 24" $621.94
