Vibration Resistant Serrated Flange Head Bolts
18-8 Stainless Steel, Fully Threaded
| Vibration Resistant Serrated Flange Head Bolts | |||||||
| Part # | Thread Size | Overall Length | Flange Diameter | Head Width | Head Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|
| Bolt-256 | 6-32 | .250" | .312" | 1/4" | 3/32" | 50 | $24.99 |
| Bolt-257 | 6-32 | .375" | .312" | 1/4" | 3/32" | 50 | $25.41 |
| Bolt-258 | 8-32 | .375" | .343" | 1/4" | 7/64" | 50 | $29.61 |
| Bolt-259 | 8-32 | .500" | .343" | 1/4" | 7/64" | 25 | $15.22 |
| Bolt-260 | 10-24 | .375" | .437" | 5/16" | 3/16" | 50 | $37.17 |
| Bolt-261 | 10-24 | .500" | .437" | 5/16" | 3/16" | 50 | $40.19 |
| Bolt-262 | 10-24 | .750" | .437" | 5/16" | 3/16" | 25 | $22.80 |
| Bolt-263 | 10-24 | 1.00" | .437" | 5/16" | 3/16" | 25 | $21.92 |
| Bolt-264 | 10-32 | .250" | .437" | 5/16" | 3/16" | 50 | $36.33 |
| Bolt-265 | 10-32 | .375" | .437" | 5/16" | 3/16" | 50 | $37.17 |
| Bolt-266 | 10-32 | .500" | .437" | 5/16" | 3/16" | 50 | $40.19 |
| Bolt-267 | 10-32 | .625" | .437" | 5/16" | 3/16" | 25 | $22.63 |
| Bolt-268 | 10-32 | .750" | .437" | 5/16" | 3/16" | 25 | $23.98 |
| Bolt-269 | 10-32 | 1.00" | .437" | 5/16" | 3/16" | 25 | $26.67 |
| Bolt-270 | 12-24 | .500" | .500" | 5/16" | 7/32" | 20 | $19.74 |
| Bolt-271 | 12-24 | .750" | .500" | 5/16" | 7/32" | 20 | $26.62 |
| Bolt-272 | 12-24 | 1.00" | .500" | 5/16" | 7/32" | 20 | $29.52 |
| Bolt-273 | 1/4"-20 | .375" | .562" | 3/8" | 9/32" | 20 | $21.37 |
| Bolt-274 | 1/4"-20 | .500" | .562" | 3/8" | 9/32" | 20 | $24.36 |
| Bolt-275 | 1/4"-20 | .625" | .562" | 3/8" | 9/32" | 20 | $26.88 |
| Bolt-276 | 1/4"-20 | .750" | .562" | 3/8" | 9/32" | 25 | $31.35 |
| Bolt-277 | 1/4"-20 | 1.00" | .562" | 3/8" | 9/32" | 20 | $28.68 |
| Bolt-278 | 1/4"-20 | 1.25" | .562" | 3/8" | 9/32" | 20 | $31.66 |
| Bolt-279 | 1/4"-20 | 1.50" | .562" | 3/8" | 9/32" | 10 | $16.63 |
| Bolt-280 | 5/16"-18 | .375" | .687" | 1/2" | 21/64" | 20 | $34.06 |
| Bolt-281 | 5/16"-18 | .500" | .687" | 1/2" | 21/64" | 20 | $39.48 |
| Bolt-282 | 5/16"-18 | .625" | .687" | 1/2" | 21/64" | 20 | $40.32 |
| Bolt-283 | 5/16"-18 | .750" | .687" | 1/2" | 21/64" | 10 | $21.94 |
| Bolt-284 | 5/16"-18 | 1.00" | .687" | 1/2" | 21/64" | 10 | $24.04 |
| Bolt-285 | 5/16"-18 | 1.25" | .687" | 1/2" | 21/64" | 10 | $27.04 |
| Bolt-286 | 5/16"-18 | 1.50" | .687" | 1/2" | 21/64" | 10 | $27.55 |
| Bolt-287 | 3/8"-16 | .500" | .812" | 9/16" | 25/64" | 10 | $34.31 |
| Bolt-288 | 3/8"-16 | .625" | .812" | 9/16" | 25/64" | 10 | $34.56 |
| Bolt-289 | 3/8"-16 | .750" | .812" | 9/16" | 25/64" | 10 | $29.77 |
| Bolt-290 | 3/8"-16 | 1.00" | .812" | 9/16" | 25/64" | 2 | $33.25 |
| Bolt-291 | 3/8"-16 | 1.25" | .812" | 9/16" | 25/64" | 5 | $21.69 |
| Bolt-292 | 3/8"-16 | 1.50" | .812" | 9/16" | 25/64" | 5 | $23.77 |
| Bolt-293 | 3/8"-16 | 1.75" | .812" | 9/16" | 25/64" | 5 | $21.81 |
| Bolt-295 | 1/2"-13 | .750" | 1-5/64" | 3/4" | 33/64" | 5 | $33.16 |
| Bolt-296 | 1/2"-13 | 1.00" | 1-5/64" | 3/4" | 33/64" | 5 | $36.31 |
| Bolt-297 | 1/2"-13 | 1.25" | 1-5/64" | 3/4" | 33/64" | 5 | $40.51 |
| Bolt-298 | 1/2"-13 | 1.50" | 1-5/64" | 3/4" | 33/64" | 5 | $45.97 |
| Bolt-299 | 1/2"-13 | 2.00" | 1-5/64" | 3/4" | 33/64" | 5 | $54.05 |
| Bolt-300 | 1/2"-13 | 2.50" | 1-5/64" | 3/4" | 33/64" | 1 | $11.63 |
| Bolt-301 | 1/2"-13 | 3.00" | 1-5/64" | 3/4" | 33/64" | 1 | $13.06 |
