Bronze Bolts
Fully Threaded, ASME B18.2.1
| Bronze Bolts | ||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| Bolt-4811 | 1/4"-20 | .375" | 7/16" | 5/32" | 25 | $28.79 |
| Bolt-4812 | 1/4"-20 | .500" | 7/16" | 5/32" | 25 | $32.29 |
| Bolt-4813 | 1/4"-20 | .625" | 7/16" | 5/32" | 25 | $32.69 |
| Bolt-4814 | 1/4"-20 | .750" | 7/16" | 5/32" | 20 | $31.33 |
| Bolt-4815 | 1/4"-20 | 1.00" | 7/16" | 5/32" | 20 | $35.65 |
| Bolt-4816 | 1/4"-20 | 1.25" | 7/16" | 5/32" | 20 | $40.23 |
| Bolt-4817 | 1/4"-20 | 1.50" | 7/16" | 5/32" | 10 | $21.71 |
| Bolt-4818 | 1/4"-20 | 2.00" | 7/16" | 5/32" | 10 | $25.97 |
| Bolt-4819 | 1/4"-20 | 2.50" | 7/16" | 5/32" | 10 | $28.24 |
| Bolt-4820 | 1/4"-20 | 3.00" | 7/16" | 5/32" | 10 | $34.10 |
| Bolt-4821 | 5/16"-18 | .750" | 1/2" | 13/64" | 10 | $24.02 |
| Bolt-4822 | 5/16"-18 | 1.00" | 1/2" | 13/64" | 10 | $26.06 |
| Bolt-4823 | 5/16"-18 | 1.25" | 1/2" | 13/64" | 10 | $29.84 |
| Bolt-4824 | 5/16"-18 | 1.50" | 1/2" | 13/64" | 10 | $33.55 |
| Bolt-4825 | 5/16"-18 | 2.00" | 1/2" | 13/64" | 5 | $21.31 |
| Bolt-4826 | 3/8"-16 | .500" | 9/16" | 15/64" | 10 | $28.77 |
| Bolt-4827 | 3/8"-16 | .750" | 9/16" | 15/64" | 10 | $34.46 |
| Bolt-4828 | 3/8"-16 | 1.00" | 9/16" | 15/64" | 10 | $44.40 |
| Bolt-4829 | 3/8"-16 | 1.25" | 9/16" | 15/64" | 5 | $24.63 |
| Bolt-4830 | 3/8"-16 | 1.50" | 9/16" | 15/64" | 5 | $27.15 |
| Bolt-4831 | 3/8"-16 | 1.75" | 9/16" | 15/64" | 5 | $28.66 |
| Bolt-4832 | 3/8"-16 | 2.00" | 9/16" | 15/64" | 5 | $31.66 |
| Bolt-4833 | 3/8"-16 | 3.00" | 9/16" | 15/64" | 5 | $33.68 |
| Bolt-4834 | 3/8"-16 | 4.00" | 9/16" | 15/64" | 5 | $44.68 |
| Bolt-4835 | 3/8"-16 | 5.00" | 9/16" | 15/64" | 5 | $65.58 |
| Bolt-4836 | 3/8"-16 | 6.00" | 9/16" | 15/64" | 5 | $72.28 |
| Bolt-4837 | 1/2"-13 | .750" | 3/4" | 5/16" | 5 | $35.08 |
| Bolt-4838 | 1/2"-13 | 1.00" | 3/4" | 5/16" | 5 | $37.98 |
| Bolt-4839 | 1/2"-13 | 1.25" | 3/4" | 5/16" | 5 | $43.38 |
| Bolt-4840 | 1/2"-13 | 1.50" | 3/4" | 5/16" | 5 | $44.78 |
| Bolt-4841 | 1/2"-13 | 1.75" | 3/4" | 5/16" | 5 | $47.68 |
| Bolt-4842 | 1/2"-13 | 2.00" | 3/4" | 5/16" | 5 | $54.08 |
| Bolt-4843 | 1/2"-13 | 2.50" | 3/4" | 5/16" | 5 | $62.58 |
| Bolt-4844 | 1/2"-13 | 3.00" | 3/4" | 5/16" | 5 | $70.01 |
| Bolt-4845 | 1/2"-13 | 3.50" | 3/4" | 5/16" | 5 | $76.21 |
| Bolt-4846 | 1/2"-13 | 4.00" | 3/4" | 5/16" | 5 | $88.18 |
| Bolt-4847 | 3/4"-10 | 1.50" | 1-1/8" | 15/32" | 1 | $26.83 |
| Bolt-4848 | 3/4"-10 | 2.00" | 1-1/8" | 15/32" | 1 | $32.65 |
