Metric Nylon Bolts
Fully Threaded, Black & White
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| Bolt-4976 | M6 x 1 | 10mm | 10mm | 4.7mm | 100 | $40.80 |
| Bolt-4977 | M6 x 1 | 16mm | 10mm | 4.7mm | 100 | $47.23 |
| Bolt-4978 | M6 x 1 | 20mm | 10mm | 4.7mm | 100 | $47.67 |
| Bolt-4979 | M6 x 1 | 30mm | 10mm | 4.7mm | 100 | $48.51 |
| Bolt-4980 | M6 x 1 | 40mm | 10mm | 4.7mm | 100 | $49.56 |
| Bolt-4981 | M8 x 1.25 | 16mm | 13mm | 6mm | 25 | $31.54 |
| Bolt-4982 | M8 x 1.25 | 20mm | 13mm | 6mm | 25 | $36.39 |
| Bolt-4983 | M8 x 1.25 | 25mm | 13mm | 6mm | 25 | $36.58 |
| Bolt-4984 | M8 x 1.25 | 30mm | 13mm | 6mm | 25 | $36.62 |
| Bolt-4985 | M8 x 1.25 | 35mm | 13mm | 6mm | 25 | $37.08 |
| Bolt-4986 | M8 x 1.25 | 50mm | 13mm | 6mm | 25 | $38.49 |
| Bolt-4987 | M10 x 1.5 | 20mm | 16mm | 7.5mm | 25 | $39.08 |
| Bolt-4988 | M10 x 1.5 | 30mm | 16mm | 7.5mm | 25 | $41.93 |
| Bolt-4989 | M10 x 1.5 | 35mm | 16mm | 7.5mm | 25 | $43.26 |
| Bolt-4990 | M10 x 1.5 | 50mm | 16mm | 7.5mm | 25 | $48.07 |
| Bolt-4991 | M12 x 1.75 | 25mm | 18mm | 9mm | 20 | $53.80 |
| Bolt-4992 | M12 x 1.75 | 30mm | 18mm | 9mm | 20 | $55.65 |
| Bolt-4993 | M12 x 1.75 | 35mm | 18mm | 9mm | 20 | $57.49 |
| Bolt-4994 | M12 x 1.75 | 40mm | 18mm | 9mm | 10 | $35.65 |
| Bolt-4995 | M12 x 1.75 | 50mm | 18mm | 9mm | 10 | $37.46 |
