.125" Thickness Channels
Aluminum 6063: Corrosion Resistance, weldable and heat treatable, non-magnetic. Unpolished mill finish.60 Brinell, 16,000 PSI Yield Strength, . -320°F to +212°F Operating Temperatures.
Fiberglass: High Strength, Non Conductive, Paintable. Operating Temperature: -45° to +140°F. Sold in 5' lengths
Fiberglass GP03: High Strength, Non Conductive, Paintable, Operating Temperature: 0° to +285°F., UL 94VO Flame Retardant. Opaque Red.
UHMWPE: Impact Resistant, Wear Resistant, Insulating, Machinable. ASTM D4020, D6712, D4076, 3-A, FDA, USDA. Operating Temperature -40° to +180°F, Softening Temperature: 260 F
.125" Thickness Channels |
|||||
| Part # | Material | Outside Width | Height | Length | Price |
|---|---|---|---|---|---|
| U Channel-005 | Aluminum 6063-T52 | 1.50" | .500" | 48" | $106.00 |
| U Channel-306 | Aluminum Alloy 385 | 1.25" | 1.25" | 96" | $647.10 |
| U Channel-410 | Aluminum Alloy 6063 | .500" | .750" | 48" | $49.09 |
| U Channel-418 | Aluminum Alloy 6063 | .750" | .375" | 48" | $40.67 |
| U Channel-419 | Aluminum Alloy 6063 | .750" | .500" | 48" | $49.09 |
| U Channel-411 | Aluminum Alloy 6063 | .750" | .750" | 48" | $62.04 |
| U Channel-412 | Aluminum Alloy 6063 | 1.00" | 1.00" | 48" | $75.27 |
| U Channel-413 | Aluminum Alloy 6063 | 1.25" | 1.25" | 48" | $91.74 |
| U Channel-420 | Aluminum Alloy 6063 | 1.50" | .500" | 48" | $63.56 |
| U Channel-421 | Aluminum Alloy 6063 | 1.50" | 1.50" | 48" | $118.24 |
| U Channel-414 | Aluminum Alloy 6063 | 1.75" | .750" | 48" | $81.44 |
| U Channel-415 | Aluminum Alloy 6063 | 1.75" | 1.00" | 48" | $95.22 |
| U Channel-416 | Aluminum Alloy 6063 | 2.00" | .500" | 48" | $77.64 |
| U Channel-423 | Aluminum Alloy 6063 | 2.00" | 1.00" | 48" | $104.46 |
| U Channel-417 | Aluminum Alloy 6063 | 3.00" | 1.00" | 48" | $116.02 |
| U Channel-407 | Aluminum Alloy 6063 | 3.00" | 3.00" | 48" | $188.39 |
| U Channel-408 | Aluminum Alloy 6063 | 4.00" | 1.00" | 48" | $140.42 |
| U Channel-357 | Fiberglass GPO-3 | 2.562" | 1.25" | 36" | $48.56 |
| U Channel-363 | Fiberglass GPO-3 | 2.562" | 1.25" | 72" | $80.71 |
| U Channel-383 | Fiberglass-Olive Green | 2.00" | .560" | 60" | $71.74 |
| U Channel-392 | UHMWPE (USDA) | 1.25" | .750" | 60" | $94.04 |
| U Channel-393 | UHMWPE (USDA) | 1.25" | .750" | 24" | $37.60 |
