Cadmium Plated Flex Top - Hex Nuts
| Cadmium Plated Steel Flex Top Hex Nuts | |||||
| Part # | Thread Size | Width | Height | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|
| DHN-2214 | #2-56 | 1/4" | 5/32" | 10 | $25.34 |
| DHN-2215 | #4-40 | 1/4" | 5/32" | 25 | $61.67 |
| DHN-2216 | #6-32 | 5/16" | 3/16" | 25 | $32.61 |
| DHN-2252 | #6-32 | 5/16" | 9/64" | 25 | $34.77 |
| DHN-2217 | #8-32 | 11/32" | 1/4" | 25 | $31.85 |
| DHN-2253 | #8-32 | 11/32" | 3/16" | 25 | $31.96 |
| DHN-2218 | #10-24 | 3/8" | 1/4" | 25 | $35.51 |
| DHN-2254 | #10-24 | 3/8" | 3/16" | 25 | $40.19 |
| DHN-2255 | #10-32 | 3/8" | 3/16" | 25 | $30.70 |
| DHN-2219 | #10-32 | 3/8" | 1/4" | 25 | $34.33 |
| DHN-2256 | 1/4"-20 | 7/16" | 7/32" | 25 | $40.90 |
| DHN-2220 | 1/4"-20 | 7/16" | 19/64" | 25 | $36.05 |
| DHN-2296 | 1/4"-20 | 1/2" | 7/32" | 25 | $40.19 |
| DHN-2283 | 1/4"-20 | 1/2" | 19/64" | 10 | $31.73 |
| DHN-2257 | 1/4"-28 | 7/16" | 7/32" | 25 | $30.95 |
| DHN-2221 | 1/4"-28 | 7/16" | 5/16" | 25 | $45.78 |
| DHN-2258 | 5/16"-18 | 1/2" | 17/64" | 10 | $15.85 |
| DHN-2222 | 5/16"-18 | 1/2" | 23/64" | 10 | $17.55 |
| DHN-2297 | 5/16"-18 | 9/16" | 17/64" | 20 | $42.14 |
| DHN-2284 | 5/16"-18 | 9/16" | 21/64" | 10 | $28.91 |
| DHN-2259 | 5/16"-24 | 1/2" | 17/64" | 10 | $16.23 |
| DHN-2223 | 5/16"-24 | 1/2" | 23/64" | 10 | $17.55 |
| DHN-2260 | 3/8"-16 | 9/16" | 9/32" | 10 | $22.11 |
| DHN-2224 | 3/8"-16 | 9/16" | 15/32" | 10 | $29.25 |
| DHN-2298 | 3/8"-16 | 5/8" | 9/32" | 10 | $25.55 |
| DHN-2285 | 3/8"-16 | 5/8" | 25/64" | 10 | $32.76 |
| DHN-2261 | 3/8"-24 | 9/16" | 9/32" | 10 | $18.69 |
| DHN-2225 | 3/8"-24 | 9/16" | 15/32" | 10 | $24.00 |
| DHN-2226 | 7/16"-14 | 5/8" | 15/32" | 5 | $28.47 |
| DHN-2299 | 7/16"-14 | 3/4" | 21/64" | 10 | $43.58 |
| DHN-2262 | 7/16"-20 | 5/8" | 21/64" | 5 | $23.50 |
| DHN-2263 | 1/2"-13 | 3/4" | 21/64" | 5 | $20.09 |
| DHN-2227 | 1/2"-13 | 3/4" | 39/64" | 5 | $28.60 |
| DHN-2300 | 1/2"-13 | 13/16" | 21/64" | 10 | $46.94 |
| DHN-2286 | 1/2"-13 | 13/16" | 1/2" | 5 | $37.96 |
| DHN-2264 | 1/2"-20 | 3/4" | 21/64" | 5 | $21.37 |
| DHN-2228 | 1/2"-20 | 3/4" | 39/64" | 5 | $33.37 |
| DHN-2265 | 5/8"-11 | 15/16" | 25/64" | 1 | $7.49 |
| DHN-2229 | 5/8"-11 | 15/16" | 49/64" | 1 | $9.11 |
| DHN-2301 | 5/8"-11 | 1.0" | 13/32" | 5 | $48.53 |
| DHN-2287 | 5/8"-11 | 1.0" | 41/64" | 1 | $11.71 |
| DHN-2266 | 5/8"-18 | 15/16" | 25/64" | 1 | $7.81 |
| DHN-2230 | 5/8"-18 | 15/16" | 49/64" | 1 | $8.88 |
| DHN-2267 | 3/4"-10 | 1 1/16" | 27/64" | 1 | $11.63 |
| DHN-2231 | 3/4"-10 | 1 1/16" | 57/64" | 1 | $16.71 |
| DHN-2288 | 3/4"-10 | 1 1/8" | 49/64" | 1 | $15.45 |
| DHN-2302 | 3/4"-10 | 1 1/8" | 27/64" | 3 | $43.28 |
| DHN-2268 | 3/4"-16 | 1 1/16" | 27/64" | 1 | $11.71 |
| DHN-2232 | 3/4"-16 | 1 1/16" | 57/64" | 1 | $14.59 |
| DHN-2289 | 7/8"-9 | 1 5/16" | 57/64" | 1 | $25.05 |
| DHN-2303 | 7/8"-9 | 1 5/16" | 31/64" | 2 | $47.60 |
| DHN-2269 | 1"-8 | 1 7/16" | 37/64" | 1 | $29.69 |
| DHN-2290 | 1"-8 | 1 1/2" | 1 1/64" | 1 | $36.96 |
| DHN-2304 | 1"-8 | 1 1/2" | 37/64" | 1 | $34.16 |
| DHN-2270 | 1"-14 | 1 7/16" | 37/64" | 1 | $25.76 |
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|
| DHN-2233 | M6 | 1 | 10 | 7.8 | 5 | $37.33 |
| DHN-2234 | M8 | 1.25 | 13 | 10.4 | 1 | $5.20 |
| DHN-2235 | M10 | 1.5 | 17 | 13 | 1 | $20.03 |
| DHN-2236 | M12 | 1.75 | 19 | 15.6 | 1 | $26.54 |
