Steel M5 Thread Hex Nuts
Steel Hex Nut M5 Thread Standard Threads 60 Degrees, RH, DIN 934 |
||||||||
| Thread Size | Pitch (mm) | Class | Finish | Height | Width | Part # | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|
| M5 | 0.8 | 4 | Plain | 4mm | 8mm | DHN-1732 | 100 | $8.59 |
| M5 | 0.8 | 8 | Plain | 4mm | 8mm | DHN-1676 | 100 | $211.34 |
| M5 | 0.8 | 8 | Plain | 5mm | 8mm | DHN-2076 | 100 | $28.08 |
| M5 | 0.8 | 10 | Black Oxide | 3.2mm | 7mm | DHN-510 | 100 | $24.04 |
| M5 | 0.8 | 10 | Yellow Chromate | 4mm | 8mm | DHN-1605 | 100 | $27.74 |
