M6 Thread Hex Nuts Zinc Plated Steel
Zinc Plated Hex Nut M6 Thread |
|||||||||
| Thread Size | Pitch (mm) | Height | Width (mm) | Direction | Class | Specifications Met | Part # | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|---|
| M6 | 0.75 | 5mm | 10mm | Right Hand | Class 4 | DIN 439 | DHN-1736 | 100 | $34.21 |
| M6 | 1.0 | 3.2mm | 10mm | Right Hand | Class 4 | DIN 439B | DHN-878 | 100 | $8.44 |
| M6 | 1.0 | 6mm | 10mm | Right Hand | Class 8 | DIN 934 | DHN-2077 | 200 | $42.28 |
| M6 | 1.0 | 5mm | 10mm | Right Hand | Class 8 | DIN 934 | DHN-1660 | 500 | $28.83 |
| M6 | 1.0 | 5mm | 10mm | Left Hand | Class 8 | DIN 934L | DHN-590 | 100 | $29.48 |
| M6 | 1.0 | 6mm | 10mm | Right Hand | Class 8 | ANSI/ASME B18.2.2 | DHN-1050 | 100 | $31.64 |
