M8 Thread Hex Nuts Zinc Plated Steel
Zinc Plated Hex Nut M8 Thread |
|||||||||
| Thread Size | Pitch (mm) | Height | Direction | Grade-Class | Specifications Met | Width | Part # | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|---|
| M8 | 1.25 | 4mm | Right Hand | Class 4 | DIN 439B | 13mm | DHN-879 | 100 | $12.81 |
| M8 | 1.25 | 6.5mm | Right Hand | Class 8 | DIN 934 | 13mm | DHN-531 | 100 | $11.50 |
| M8 | 1.25 | 8mm | Right Hand | Class 8 | DIN 934 | 13mm | DHN-2078 | 100 | $42.58 |
| M8 | 1.00 | 6.5mm | Right Hand | Class 8 | DIN 934 | 13mm | DHN-1689 | 100 | $5.50 |
| M8 | 1.00 | 6.5mm | Right Hand | - | DIN 134 | 13mm | DHN-570 | 5 | $26.50 |
| M8 | 1.25 | 6.5mm | Left Hand | Class 8 | DIN 934L | 13mm | DHN-591 | 50 | $17.57 |
| M8 | 1.25 | 8mm | Right Hand | Class 8 | ANSI/ASME B18.2.2 | 13mm | DHN-1051 | 50 | $22.88 |
