Extruded Acrylic Tubes
Extruded offers good clarity at an economical price
Cast offers consistent and superior clarity for more high tech applications.
Acrylic Extruded Tubing, Clear Tubes are shipped in Kraft Corrugated Tubes for protection from transit damage. There is an additional package fee based on the diameter. |
|||||
| Part # | OD (in.) | ID (in.) | Wall (in.) | Minimum Purchase | Price Per 6 Feet |
|---|---|---|---|---|---|
| DPT-671 | .250 | .125 | .063 | 300' | $1.58 |
| DPT-2140 | .312 | .187 | .063 | 216' | $1.88 |
| DPT-4603 | .375 | .125 | .125 | 150' | $3.68 |
| DPT-4604 | .375 | .250 | .063 | 180' | $2.33 |
| DPT-672 | .500 | .250 | .125 | 96' | $6.08 |
| DPT-2143 | .625 | .375 | .125 | 60' | $6.53 |
| DPT-2142 | .625 | .500 | .063 | 96' | $4.23 |
| DPT-673 | .750 | .500 | .125 | 60' | $7.85 |
| DPT-2146 | .875 | .625 | .125 | 54' | $9.08 |
| DPT-2147 | 1.00 | .875 | .063 | 72' | $6.53 |
| DPT-2148 | 1.25 | 1.125 | .062 | 48' | $7.43 |
| DPT-675 | 1.25 | 1.00 | .125 | 48' | $12.83 |
| DPT-2162 | 1.50 | 1.00 | .250 | 24' | $8.16 |
| DPT-2925A | 1.625 | 1.375 | .125 | 24' | $17.18 |
| DPT-2150 | 1.75 | 1.50 | .125 | 36' | $18.53 |
| DPT-2153 | 2.75 | 2.50 | .125 | 18' | $35.18 |
| DPT-2154 | 3.00 | 2.75 | .125 | 18' | $35.78 |
| DPT-677 | 3.25 | 3.00 | .125 | 12' | $40.43 |
| DPT-2156 | 3.50 | 3.25 | .125 | 6' | $43.43 |
| DPT-2157 | 3.75 | 3.50 | .125 | 6' | $49.73 |
| DPT-2167 | 4.00 | 3.50 | .250 | 6' | $155.33 |
| DPT-2158 | 4.00 | 3.75 | .125 | 6' | $53.33 |
| DPT-5748 | 4.25 | 3.75 | .250 | 6' | $86.93 |
| DPT-2168 | 4.50 | 4.00 | .250 | 6' | $181.28 |
| DPT-2159 | 4.50 | 4.25 | .125 | 6' | $58.58 |
| DPT-2160 | 5.00 | 4.75 | .125 | 6' | $68.78 |
| DPT-7987 | 5.25 | 5.00 | .125 | 6' | $158.48 |
| DPT-8015 | 5.50 | 5.00 | .250 | 6' | $283.58 |
| DPT-8016 | 6.00 | 5.50 | .250 | 6' | $309.38 |
| DPT-8020 | 9.50 | 9.00 | .250 | 6' | $371.18 |
| Tolerances OD/ID Inches for Extruded Tubes | |
| OD's | Tolerance |
| .250" to "500 | +/-.010" |
| .625" to 1.0" | +/-.015" |
| 1.125" to 1.375" | +/-.020" |
| 1.50" to 2.0" | +/-.025" |
| 2.25" to 3.0" | +/-.030" |
| 3.25" to 4.0" | +/-.040" |
| 4.25" to 6.0" | +/-.060" |
| 6.50" to 8.0" | +/-.125" |
| 8.50" and Larger | +/-.250" |
Cast Acrylic Tubes, Clear 5 Foot Standard Lengths, Unless Noted * Available in 6 Foot Lengths |
|||
| Part # | OD (in.) | ID (in.) | Price Per Foot |
|---|---|---|---|
| DPT-829 | 1.50 | 1.00 | $179.54 |
| DPT-830 | 1.50 | 1.125 | $137.24 |
| DPT-831 | 1.50 | 1.25 | $142.28 |
| DPT-832 | 1.75 | 1.250 | $182.14 |
| DPT-833 | 1.75 | 1.375 | $170.84 |
| DPT-834 | 1.75 | 1.50 | $149.00 |
| DPT-835 | 2.00 | 1.50 | $178.22 |
| DPT-836 | 2.00 | 1.625 | $174.06 |
| DPT-837 | 2.00 | 1.75 | $151.68 |
| DPT-838 | 2.25 | 1.75 | $131.44 |
| DPT-839 | 2.25 | 2.00 | $128.94 |
| DPT-840 | 2.50 | 2.00 | $190.16 |
| DPT-841 | 2.50 | 2.125 | $174.58 |
| DPT-842 | 2.50 | 2.25 | $160.24 |
| DPT-843 | 2.75 | 2.25 | $193.40 |
| DPT-844 | 2.75 | 2.375 | $193.40 |
| DPT-845 | 2.75 | 2.50 | $161.10 |
| DPT-846 | 3.00 | 2.50 | $194.38 |
| DPT-849 | 3.00 | 2.625 | $179.80 |
| DPT-850 | 3.00 | 2.75 | $162.92 |
| DPT-854 | 3.00 | 3.50 | $197.76 |
| DPT-851 | 3.25 | 2.75 | $195.20 |
| DPT-852 | 3.25 | 2.875 | $180.68 |
| DPT-853 | 3.25 | 3.00 | $167.54 |
| DPT-854 | 3.50 | 3.00 | $197.68 |
| DPT-855 | 3.50 | 3.125 | $179.58 |
| DPT-856 | 3.50 | 3.25 | $171.66 |
| DPT-5495X | 3.75 | 3.25 | $77.80 |
| DPT-2742 | 3.75 | 3.375 | $188.64 |
| DPT-2737 | 3.75 | 3.50 | $188.64 |
| DPT-857 | 4.00 | 3.25 | $386.58 |
| DPT-861 | 4.00 | 3.50 | $204.24 |
| DPT-862 | 4.00 | 3.625 | $190.66 |
| DPT-860 | 4.00 | 3.75 | $176.14 |
| DPT-2746 | 4.25 | 3.75 | $198.90 |
| DPT-2743 | 4.25 | 3.875 | $191.92 |
| DPT-2738 | 4.25 | 4.00 | $179.80 |
| DPT-864 | 4.50 | 3.75 | $408.12 |
| DPT-865 | 4.50 | 4.00 | $203.74 |
| DPT-866 | 4.50 | 4.125 | $199.28 |
| DPT-867 | 4.50 | 4.25 | $181.82 |
| DPT-2750 | 4.75 | 4.00 | $415.14 |
| DPT-2747 | 4.75 | 4.25 | $207.96 |
| DPT-2744 | 4.75 | 4.375 | $200.98 |
| DPT-2739 | 4.75 | 4.50 | $200.98 |
| DPT-868 | 5.00 | 4.25 | $434.28 |
| DPT-869 | 5.00 | 4.50 | $212.28 |
| DPT-870 | 5.00 | 4.625 | $203.16 |
| DPT-871 | 5.00 | 4.75 | $187.50 |
| DPT-2758 | 5.25 | 4.875 | $222.68 |
| DPT-2775 | 5.25 | 4.50 | $448.24 |
| DPT-2767 | 5.25 | 4.75 | $234.82 |
| DPT-2751 | 5.25 | 5.00 | $195.04 |
| DPT-872 | 5.50 | 4.75 | $440.96 |
| DPT-873 | 5.50 | 5.00 | $233.00 |
| DPT-875 | 5.50 | 5.250 | $200.04 |
| DPT-2768 | 5.75 | 5.25 | $235.04 |
| DPT-2759 | 5.75 | 5.375 | $208.24 |
| DPT-2752 | 5.75 | 5.50 | $218.04 |
| DPT-876 | 6.00 | 5.25 | $518.32 |
| DPT-877 | 6.00 | 5.50 | $227.48 |
| DPT-878 | 6.00 | 5.625 | $202.52 |
| DPT-879 | 6.00 | 5.575 | $213.62 |
| DPT-665 | 6.00 | 5.750 | $213.62 |
| DPT-880 | 7.00 | 6.25 | $898.00 |
| DPT-882 | 7.00 | 6.625 | $239.46 |
| DPT-881 | 7.00 | 6.50 | $263.78 |
| DPT-883 | 7.00 | 6.75 | $243.55 |
| DPT-886 | 8.00 | 7.625 | $255.28 |
| DPT-884 | 8.00 | 7.25 | $939.40 |
| DPT-885 | 8.00 | 7.75 | $345.92 |
| DPT-887 | 8.00 | 7.75 | $247.26 |
| DPT-901 | 12.00 | 11.50 | $2,179.16 (2 Ft Length) |
|
Wall Thickness Tolerances: .250" (+/-.045") .375" (+/-.055") .500" (+/-.065") .750" (+/-.090") |
Outside Diameter
Tolerances: 1.50" to 3.00" (+/-.020") 3.25" to 3.75" (+/-.030") 4.0" to 12.0" (+/-.065") 13" to 18" (+/-.080") 20" to 27.5" (+/-.100") 32.6" (+.250"/-.100") 36" (+/-.100") 42.5" (+0.00"/-.280") 44.7" to 60" (+/-.100") 72" (+.100"/-.300") 96" (+.100"/-.500") |
Acrylic Square Tubing Only shipped in Full Lengths Tubes are shipped in Kraft Corrugated Tubes for protection from transit damage. There is an additional package fee based on the diameter. |
|||||
| Part # | Outside Width (in.) | Wall (in.) | Length | Minimum Purchase | Price |
|---|---|---|---|---|---|
| DPST-014B | .375 | .063 | 6' | 72' | $5.66 |
| DPST-002 | .500 | .063 | 6' | 90' | $5.27 |
| DPST-057 | .625 | .063 | 6' | 54' | $12.48 |
| DPST-001 | .750 | .063 | 6' | 48' | $12.48 |
| DPST-048 | 1.00 | .063 | 6' | 48' | $16.96 |
| DPST-049 | 1.25 | .125 | 6' | 48' | $24.65 |
| DPST-056 | 1.50 | .125 | 6' | 18' | $57.79 |
| DPST-059 | 2.00 | .125 | 6' | 12' | $38.00 |
| DPST-053 | 2.50 | .125 | 6' | 12' | $99.89 |
| DPST-052 | 3.00 | .125 | 6' | 12' | $109.90 |
