Cast HS Blue Nylon Rod
This is superior engineering material for many diverse applications, the primary use as a bearing material, without lubrication, (under low pressure velocity limits) up to the point where a self lubricating or superior wear material becomes necessary. It replaces bronze, brass, steel, aluminum, and others. It has high impact resistance and is not subject to embrittlement or deterioration. High heat distortion temp, excellent vibration resistance. Not UV stabililzed. Intermittent to 330 deg F, continuous -40 deg F to 230 deg F
Nylon Cast HS Blue Technical Data Sheet
| Cast Nylon Blue Rod 4 feet Standard Length Blue Color |
||
| Diameter (in.) | Part # | Price Per Foot |
|---|---|---|
| 1.00 | DPR-1462 | $41.91 |
| 1.25 | DPR-1463 | $43.57 |
| 1.50 | DPR-1464 | $45.71 |
| 1.75 | DPR-1465 | $47.64 |
| 2.00 | DPR-1438 | $43.75 |
| 2.25 | DPR-3261 | $51.56 |
| 2.50 | DPR-1466 | $57.37 |
| 2.75 | DPR-3274 | $65.83 |
| 3.00 | DPR-1439 | $72.06 |
| 3.25 | DPR-3263 | $80.05 |
| 3.50 | DPR-3253 | $103.63 |
| 3.75 | DPR-3265 | $194.80 |
| 4.00 | DPR-1440 | $122.59 |
| 4.50 | DPR-3267 | $159.11 |
| 4.75 | DPR-3268 | $303.85 |
| 5.00 | DPR-1441 | $198.49 |
| 5.50 | DPR-3269 | $208.61 |
| 6.00 | DPR-1442 | $245.71 |
