G11 High Temperature Glass Tubes .250" Wall Thickness
G11 Glass Tubes - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10 FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.250" Wall Thickness G11 Tubes |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum Purchase |
|---|---|---|---|---|
| DPT-1504 | 1.000 | 0.500 | $92.26 | 9 Feet |
| DPT-1509 | 1.062 | 0.562 | $98.11 | 9 Feet |
| DPT-1515 | 1.125 | 0.625 | $71.41 | 12 Feet |
| DPT-10875 | 1.187 | 0.687 | $75.43 | 12 Feet |
| DPT-1514K | 1.250 | 0.750 | $79.46 | 9 Feet |
| DPT-10877 | 1.312 | 0.812 | $83.48 | 12 Feet |
| DPT-1520 | 1.375 | 0.875 | $87.48 | 9 Feet |
| DPT-10852 | 1.437 | 0.937 | $91.51 | 9 Feet |
| DPT-10869 | 1.500 | 1.000 | $95.53 | 9 Feet |
| DPT-10847 | 1.562 | 1.062 | $99.51 | 9 Feet |
| DPT-10848 | 1.625 | 1.125 | $103.55 | 9 Feet |
| DPT-10849 | 1.687 | 1.187 | $107.56 | 9 Feet |
| DPT-10850 | 1.750 | 1.250 | $111.61 | 9 Feet |
| DPT-10851 | 1.812 | 1.312 | $115.58 | 9 Feet |
| DPT-10861 | 1.875 | 1.375 | $119.63 | 9 Feet |
| DPT-10853 | 1.937 | 1.437 | $123.63 | 9 Feet |
| DPT-10845 | 2.000 | 1.500 | $127.68 | 9 Feet |
| DPT-10855 | 2.062 | 1.562 | $131.66 | 9 Feet |
| DPT-10856 | 2.125 | 1.625 | $135.71 | 6 Feet |
| DPT-10857 | 2.187 | 1.687 | $139.71 | 6 Feet |
| DPT-10858 | 2.250 | 1.750 | $143.76 | 6 Feet |
| DPT-10859 | 2.312 | 1.812 | $147.73 | 6 Feet |
| DPT-10860 | 2.375 | 1.875 | $151.78 | 6 Feet |
| DPT-10829 | 2.437 | 1.937 | $155.78 | 6 Feet |
| DPT-10950 | 2.500 | 2.000 | $159.83 | 6 Feet |
| DPT-11033 | 2.562 | 2.062 | $163.81 | 6 Feet |
| DPT-11034 | 2.625 | 2.125 | $167.88 | 6 Feet |
| DPT-11035 | 2.687 | 2.187 | $171.86 | 6 Feet |
| DPT-11036 | 2.750 | 2.250 | $175.91 | 6 Feet |
| DPT-11037 | 2.812 | 2.312 | $179.91 | 6 Feet |
| DPT-11038 | 2.875 | 2.375 | $183.96 | 6 Feet |
| DPT-11048 | 2.937 | 2.437 | $187.93 | 6 Feet |
| DPT-11040 | 3.000 | 2.500 | $191.98 | 6 Feet |
| DPT-11032 | 3.062 | 2.562 | $195.98 | 6 Feet |
| DPT-10967 | 3.125 | 2.625 | $200.03 | 6 Feet |
| DPT-10968 | 3.187 | 2.687 | $204.01 | 6 Feet |
| DPT-10969 | 3.250 | 2.750 | $208.06 | 6 Feet |
| DPT-10970 | 3.312 | 2.812 | $212.06 | 6 Feet |
| DPT-10980 | 3.375 | 2.875 | $216.11 | 6 Feet |
| DPT-10972 | 3.437 | 2.937 | $220.08 | 6 Feet |
| DPT-10964 | 3.500 | 3.000 | $224.13 | 6 Feet |
| DPT-10973 | 3.562 | 3.062 | $228.13 | 6 Feet |
| DPT-10999 | 3.625 | 3.125 | $232.18 | 6 Feet |
| DPT-11000 | 3.687 | 3.187 | $236.16 | 6 Feet |
| DPT-11001 | 3.750 | 3.250 | $240.21 | 6 Feet |
| DPT-11002 | 3.812 | 3.312 | $244.21 | 6 Feet |
| DPT-11003 | 3.875 | 3.375 | $248.26 | 6 Feet |
| DPT-11004 | 3.937 | 3.437 | $252.23 | 6 Feet |
| DPT-11014 | 4.000 | 3.500 | $256.28 | 6 Feet |
| DPT-11006 | 4.062 | 3.562 | $260.28 | 6 Feet |
| DPT-10998 | 4.125 | 3.625 | $264.33 | 6 Feet |
| DPT-11008 | 4.187 | 3.687 | $268.31 | 3 Feet |
| DPT-11009 | 4.250 | 3.750 | $272.35 | 3 Feet |
| DPT-11010 | 4.312 | 3.812 | $276.36 | 3 Feet |
| DPT-11011 | 4.375 | 3.875 | $280.41 | 3 Feet |
| DPT-11012 | 4.437 | 3.937 | $284.38 | 3 Feet |
| DPT-11013 | 4.500 | 4.000 | $288.43 | 3 Feet |
| DPT-10990 | 4.562 | 4.062 | $292.43 | 3 Feet |
| DPT-10988 | 4.625 | 4.125 | $296.48 | 3 Feet |
| DPT-11005 | 4.687 | 4.187 | $300.46 | 3 Feet |
| DPT-10983 | 4.750 | 4.250 | $304.51 | 3 Feet |
| DPT-10984 | 4.812 | 4.312 | $308.51 | 3 Feet |
| DPT-10768 | 4.875 | 4.375 | $312.55 | 3 Feet |
| DPT-10760 | 4.937 | 4.437 | $316.53 | 3 Feet |
| DPT-10770 | 5.000 | 4.500 | $320.58 | 3 Feet |
| DPT-10771 | 5.062 | 4.562 | $324.58 | 3 Feet |
| DPT-10772 | 5.125 | 4.625 | $328.63 | 3 Feet |
| DPT-10773 | 5.187 | 4.687 | $332.60 | 3 Feet |
| DPT-10774 | 5.250 | 4.750 | $336.66 | 3 Feet |
| DPT-10775 | 5.312 | 4.812 | $340.66 | 3 Feet |
| DPT-10752 | 5.375 | 4.875 | $378.48 | 3 Feet |
| DPT-10750 | 5.437 | 4.937 | $382.88 | 3 Feet |
| DPT-10767 | 5.500 | 5.000 | $387.33 | 3 Feet |
| DPT-10745 | 5.562 | 5.062 | $391.71 | 3 Feet |
| DPT-10746 | 5.625 | 5.125 | $396.16 | 3 Feet |
| DPT-10747 | 5.687 | 5.187 | $400.53 | 3 Feet |
| DPT-10748 | 5.750 | 5.250 | $404.98 | 3 Feet |
| DPT-10749 | 5.812 | 5.312 | $409.36 | 3 Feet |
| DPT-10759 | 5.875 | 5.375 | $413.81 | 3 Feet |
| DPT-10751 | 5.937 | 5.437 | $418.18 | 3 Feet |
| DPT-10743 | 6.000 | 5.500 | $422.63 | 3 Feet |
| DPT-10753 | 6.062 | 5.562 | $427.01 | 3 Feet |
| DPT-10754 | 6.125 | 5.625 | $431.46 | 3 Feet |
| DPT-10755 | 6.187 | 5.687 | $435.83 | 3 Feet |
| DPT-10756 | 6.250 | 5.750 | $440.28 | 3 Feet |
| DPT-10757 | 6.312 | 5.812 | $444.66 | 3 Feet |
| DPT-10778 | 6.375 | 5.875 | $449.11 | 3 Feet |
| DPT-10744 | 6.437 | 5.937 | $453.48 | 3 Feet |
| DPT-10769 | 6.500 | 6.000 | $457.93 | 3 Feet |
| DPT-10795 | 6.562 | 6.062 | $422.71 | 3 Feet |
| DPT-10796 | 6.625 | 6.125 | $426.91 | 3 Feet |
| DPT-10797 | 6.687 | 6.187 | $431.05 | 3 Feet |
| DPT-10798 | 6.750 | 6.250 | $435.28 | 3 Feet |
| DPT-10799 | 6.812 | 6.312 | $439.43 | 3 Feet |
| DPT-10800 | 6.875 | 6.375 | $443.66 | 3 Feet |
| DPT-10810 | 6.937 | 6.437 | $447.81 | 3 Feet |
| DPT-10802 | 7.000 | 6.500 | $452.03 | 3 Feet |
| DPT-10794 | 7.062 | 6.562 | $456.18 | 3 Feet |
| DPT-10804 | 7.125 | 6.625 | $460.38 | 3 Feet |
| DPT-10805 | 7.187 | 6.687 | $464.53 | 3 Feet |
| DPT-10806 | 7.250 | 6.750 | $468.76 | 3 Feet |
| DPT-10807 | 7.312 | 6.812 | $472.91 | 3 Feet |
| DPT-10808 | 7.375 | 6.875 | $477.13 | 3 Feet |
| DPT-10809 | 7.437 | 6.937 | $481.28 | 3 Feet |
| DPT-10786 | 7.500 | 7.000 | $485.50 | 3 Feet |
| DPT-10784 | 7.562 | 7.062 | $489.66 | 3 Feet |
| DPT-10801 | 7.625 | 7.125 | $493.85 | 3 Feet |
| DPT-10779 | 7.687 | 7.187 | $498.03 | 3 Feet |
| DPT-10780 | 7.750 | 7.250 | $502.23 | 3 Feet |
| DPT-10781 | 7.812 | 7.312 | $506.38 | 3 Feet |
| DPT-10782 | 7.875 | 7.375 | $510.61 | 3 Feet |
| DPT-10783 | 7.937 | 7.437 | $514.76 | 3 Feet |
| DPT-10793 | 8.000 | 7.500 | $518.98 | 3 Feet |
| DPT-10785 | 8.062 | 7.562 | $523.13 | 3 Feet |
| DPT-10777 | 8.125 | 7.625 | $527.36 | 3 Feet |
| DPT-10787 | 8.187 | 7.687 | $531.51 | 3 Feet |
| DPT-10788 | 8.250 | 7.750 | $535.71 | 3 Feet |
| DPT-10789 | 8.312 | 7.812 | $539.86 | 3 Feet |
| DPT-10790 | 8.375 | 7.875 | $544.08 | 3 Feet |
| DPT-10791 | 8.437 | 7.937 | $548.23 | 3 Feet |
| DPT-10727 | 8.500 | 8.000 | $552.46 | 3 Feet |
| DPT-10758 | 8.625 | 8.125 | $560.83 | 3 Feet |
| DPT-10693 | 8.687 | 8.187 | $564.98 | 3 Feet |
| DPT-10694 | 8.750 | 8.250 | $569.18 | 3 Feet |
| DPT-10695 | 8.812 | 8.312 | $573.33 | 3 Feet |
| DPT-10696 | 8.875 | 8.375 | $577.56 | 3 Feet |
| DPT-10697 | 8.937 | 8.437 | $581.71 | 3 Feet |
| DPT-10698 | 9.000 | 8.500 | $585.93 | 3 Feet |
| DPT-10708 | 9.062 | 8.562 | $590.08 | 3 Feet |
| DPT-10700 | 9.125 | 8.625 | $594.31 | 3 Feet |
| DPT-10692 | 9.187 | 8.687 | $598.46 | 3 Feet |
| DPT-10702 | 9.250 | 8.750 | $602.68 | 3 Feet |
| DPT-10703 | 9.312 | 8.812 | $606.83 | 3 Feet |
| DPT-10704 | 9.375 | 8.875 | $611.03 | 3 Feet |
| DPT-10705 | 9.437 | 8.937 | $615.18 | 3 Feet |
| DPT-10706 | 9.500 | 9.000 | $619.41 | 3 Feet |
| DPT-10684 | 9.562 | 9.062 | $623.56 | 3 Feet |
| DPT-10701 | 9.625 | 9.125 | $627.78 | 3 Feet |
| DPT-10699 | 9.687 | 9.187 | $631.93 | 3 Feet |
| DPT-10677 | 9.750 | 9.250 | $636.16 | 3 Feet |
| DPT-10678 | 9.812 | 9.312 | $640.31 | 3 Feet |
| DPT-10679 | 9.875 | 9.375 | $644.51 | 3 Feet |
| DPT-10680 | 9.937 | 9.437 | $648.66 | 3 Feet |
| DPT-10681 | 10.000 | 9.500 | $652.88 | 3 Feet |
| DPT-10691 | 10.062 | 9.562 | $657.03 | 3 Feet |
| DPT-10683 | 10.125 | 9.625 | $661.26 | 3 Feet |
| DPT-10676 | 10.187 | 9.687 | $665.41 | 3 Feet |
| DPT-10685 | 10.250 | 9.750 | $669.63 | 3 Feet |
| DPT-10686 | 10.312 | 9.812 | $673.78 | 3 Feet |
| DPT-10687 | 10.375 | 9.875 | $677.98 | 3 Feet |
| DPT-10688 | 10.437 | 9.937 | $682.13 | 3 Feet |
| DPT-10689 | 10.500 | 10.000 | $686.36 | 3 Feet |
| DPT-10690 | 10.562 | 10.062 | $690.51 | 3 Feet |
| DPT-10710 | 10.625 | 10.125 | $694.73 | 3 Feet |
| DPT-10735 | 10.687 | 10.187 | $698.88 | 3 Feet |
| DPT-10707 | 10.750 | 10.250 | $703.11 | 3 Feet |
| DPT-10728 | 10.812 | 10.312 | $707.26 | 3 Feet |
| DPT-10729 | 10.875 | 10.375 | $711.48 | 3 Feet |
| DPT-10730 | 10.937 | 10.437 | $715.63 | 3 Feet |
| DPT-10168 | 11.000 | 10.500 | $719.83 | 3 Feet |
| DPT-10167 | 11.062 | 10.562 | $723.98 | 3 Feet |
| DPT-10166 | 11.125 | 10.625 | $728.21 | 3 Feet |
| DPT-10188 | 11.187 | 10.687 | $732.36 | 3 Feet |
| DPT-10190 | 11.250 | 10.750 | $736.58 | 3 Feet |
| DPT-10173 | 11.312 | 10.812 | $740.73 | 3 Feet |
| DPT-10195 | 11.375 | 10.875 | $744.96 | 3 Feet |
| DPT-10194 | 11.437 | 10.937 | $749.11 | 3 Feet |
| DPT-10193 | 11.500 | 11.000 | $753.31 | 3 Feet |
| DPT-10192 | 11.562 | 11.062 | $757.46 | 3 Feet |
| DPT-10191 | 11.625 | 11.125 | $761.68 | 3 Feet |
| DPT-10181 | 11.687 | 11.187 | $765.83 | 3 Feet |
| DPT-10189 | 11.750 | 11.250 | $770.06 | 3 Feet |
| DPT-10197 | 11.812 | 11.312 | $774.21 | 3 Feet |
| DPT-10209 | 11.875 | 11.375 | $778.43 | 3 Feet |
| DPT-10208 | 11.937 | 11.437 | $782.58 | 3 Feet |
| DPT-10207 | 12.000 | 11.500 | $786.78 | 3 Feet |
| DPT-10198 | 12.062 | 11.562 | $790.96 | 3 Feet |
| DPT-10205 | 12.125 | 11.625 | $795.16 | 3 Feet |
| DPT-10213 | 12.187 | 11.687 | $799.31 | 3 Feet |
| DPT-10203 | 12.250 | 11.750 | $803.53 | 3 Feet |
| DPT-9846 | 12.312 | 11.812 | $807.68 | 3 Feet |
| DPT-9855 | 12.375 | 11.875 | $811.91 | 3 Feet |
| DPT-9844 | 12.437 | 11.937 | $816.06 | 3 Feet |
| DPT-9843 | 12.500 | 12.000 | $820.28 | 3 Feet |
| DPT-9842 | 12.562 | 12.062 | $824.43 | 3 Feet |
| DPT-9841 | 12.625 | 12.125 | $828.63 | 3 Feet |
| DPT-9840 | 12.687 | 12.187 | $832.78 | 3 Feet |
| DPT-9809 | 12.750 | 12.250 | $837.01 | 3 Feet |
| DPT-9839 | 12.812 | 12.312 | $841.16 | 3 Feet |
| DPT-9829 | 12.875 | 12.375 | $845.38 | 3 Feet |
| DPT-9828 | 12.937 | 12.437 | $849.53 | 3 Feet |
| DPT-9827 | 13.000 | 12.500 | $853.76 | 3 Feet |
| DPT-9826 | 13.062 | 12.562 | $857.91 | 3 Feet |
| DPT-9825 | 13.125 | 12.625 | $862.11 | 3 Feet |
| DPT-9824 | 13.187 | 12.687 | $866.26 | 3 Feet |
| DPT-9823 | 13.250 | 12.750 | $870.48 | 3 Feet |
| DPT-9822 | 13.312 | 12.812 | $874.63 | 3 Feet |
| DPT-9821 | 13.375 | 12.875 | $878.86 | 3 Feet |
| DPT-9808 | 13.437 | 12.937 | $883.01 | 3 Feet |
| DPT-9819 | 13.500 | 13.000 | $887.23 | 3 Feet |
| DPT-9831 | 13.562 | 13.062 | $891.38 | 3 Feet |
| DPT-9817 | 13.625 | 13.125 | $895.58 | 3 Feet |
| DPT-9816 | 13.687 | 13.187 | $899.76 | 3 Feet |
| DPT-9815 | 13.750 | 13.250 | $903.96 | 3 Feet |
| DPT-9814 | 13.812 | 13.312 | $908.11 | 3 Feet |
| DPT-9813 | 13.875 | 13.375 | $912.33 | 3 Feet |
| DPT-9812 | 13.937 | 13.437 | $916.48 | 3 Feet |
| DPT-9811 | 14.000 | 13.500 | $920.71 | 3 Feet |
| DPT-9810 | 14.062 | 13.562 | $924.86 | 3 Feet |
| DPT-9864 | 14.125 | 13.625 | $929.08 | 3 Feet |
| DPT-9818 | 14.187 | 13.687 | $933.23 | 3 Feet |
| DPT-9820 | 14.250 | 13.750 | $937.43 | 3 Feet |
| DPT-9866 | 14.312 | 13.812 | $941.58 | 3 Feet |
| DPT-9847 | 14.375 | 13.875 | $945.81 | 3 Feet |
| DPT-9872 | 14.437 | 13.937 | $949.96 | 3 Feet |
| DPT-9871 | 14.500 | 14.000 | $954.18 | 3 Feet |
| DPT-9870 | 14.562 | 14.062 | $958.33 | 3 Feet |
| DPT-9869 | 14.625 | 14.125 | $962.56 | 3 Feet |
| DPT-9868 | 14.687 | 14.187 | $966.71 | 3 Feet |
| DPT-9520 | 14.750 | 14.250 | $970.91 | 3 Feet |
| DPT-9867 | 14.812 | 14.312 | $975.06 | 3 Feet |
| DPT-9856 | 14.875 | 14.375 | $979.28 | 3 Feet |
| DPT-9865 | 14.937 | 14..437 | $983.43 | 3 Feet |
| DPT-9832 | 15.000 | 14.500 | $987.66 | 3 Feet |
| DPT-9874 | 15.062 | 14.562 | $991.81 | 3 Feet |
| DPT-9863 | 15.125 | 14.625 | $996.03 | 3 Feet |
| DPT-9862 | 15.187 | 14.687 | $1,000.18 | 3 Feet |
| DPT-9861 | 15.250 | 14.750 | $1,004.41 | 3 Feet |
| DPT-9860 | 15.312 | 14.812 | $1,008.56 | 3 Feet |
| DPT-9859 | 15.375 | 14.875 | $1,012.76 | 3 Feet |
| DPT-9837 | 15.437 | 14.937 | $1,016.91 | 3 Feet |
| DPT-9836 | 15.500 | 15.000 | $1,021.13 | 3 Feet |
| DPT-9835 | 15.562 | 15.062 | $1,025.28 | 3 Feet |
| DPT-9834 | 15.625 | 15.125 | $1,029.50 | 3 Feet |
| DPT-9686 | 15.687 | 15.187 | $1,033.66 | 3 Feet |
| DPT-9858 | 15.750 | 15.250 | $1,037.88 | 3 Feet |
| DPT-9737 | 15.812 | 15.312 | $1,042.03 | 3 Feet |
| DPT-9590 | 15.875 | 15.375 | $1,046.23 | 3 Feet |
| DPT-9589 | 15.937 | 15.437 | $1,050.38 | 3 Feet |
| DPT-9310 | 16.000 | 15.500 | $1,054.61 | 3 Feet |
| DPT-9309 | 16.062 | 15.562 | $1,058.76 | 3 Feet |
| DPT-9308 | 16.125 | 15.625 | $1,062.98 | 3 Feet |
| DPT-9307 | 16.187 | 15.687 | $1,067.13 | 3 Feet |
| DPT-9306 | 16.250 | 15.750 | $1,071.36 | 3 Feet |
| DPT-9305 | 16.312 | 15.812 | $1,075.50 | 3 Feet |
| DPT-9304 | 16.375 | 15.875 | $1,079.71 | 3 Feet |
| DPT-9303 | 16.437 | 15.937 | $1,083.88 | 3 Feet |
| DPT-9340 | 16.500 | 16.000 | $1,088.08 | 3 Feet |
| DPT-9313 | 16.562 | 16.062 | $1,092.23 | 3 Feet |
| DPT-9315 | 16.625 | 16.125 | $1,096.46 | 3 Feet |
| DPT-9353 | 16.687 | 16.187 | $1,100.60 | 3 Feet |
| DPT-9352 | 16.750 | 16.250 | $1,104.83 | 3 Feet |
| DPT-9351 | 16.812 | 16.312 | $1,108.98 | 3 Feet |
| DPT-9350 | 16.875 | 16.375 | $1,113.21 | 3 Feet |
| DPT-9349 | 16.937 | 16.437 | $1,117.36 | 3 Feet |
| DPT-9348 | 17.000 | 16.500 | $1,121.55 | 3 Feet |
| DPT-9347 | 17.062 | 16.562 | $1,125.71 | 3 Feet |
| DPT-9069 | 17.125 | 16.625 | $1,129.93 | 3 Feet |
| DPT-9061 | 17.187 | 16.687 | $1,134.08 | 3 Feet |
| DPT-9054 | 17.250 | 16.750 | $1,138.31 | 3 Feet |
| DPT-9063 | 17.312 | 16.812 | $1,142.46 | 3 Feet |
| DPT-9064 | 17.375 | 16.875 | $1,146.68 | 3 Feet |
| DPT-9065 | 17.437 | 16.937 | $1,150.83 | 3 Feet |
| DPT-9066 | 17.500 | 17.000 | $1,155.03 | 3 Feet |
| DPT-9067 | 17.562 | 17.062 | $1,159.18 | 3 Feet |
| DPT-9087 | 17.625 | 17.125 | $1,163.41 | 3 Feet |
| DPT-9055 | 17.687 | 17.187 | $1,167.55 | 3 Feet |
| DPT-9078 | 17.750 | 17.250 | $1,171.78 | 3 Feet |
| DPT-9151 | 17.812 | 17.312 | $1,175.93 | 3 Feet |
| DPT-9119 | 17.875 | 17.375 | $1,180.15 | 3 Feet |
| DPT-9118 | 17.937 | 17.437 | $1,184.30 | 3 Feet |
| DPT-9117 | 18.000 | 17.500 | $1,188.50 | 3 Feet |
| DPT-9101 | 18.062 | 17.562 | $1,192.68 | 3 Feet |
| DPT-9115 | 18.125 | 17.625 | $1,196.88 | 3 Feet |
| DPT-9160 | 18.187 | 17.687 | $1,201.03 | 3 Feet |
| DPT-9113 | 18.250 | 17.750 | $1,205.25 | 3 Feet |
| DPT-9112 | 18.312 | 17.812 | $1,209.41 | 3 Feet |
| DPT-9111 | 18.375 | 17.875 | $1,213.63 | 3 Feet |
| DPT-8951 | 18.437 | 17.937 | $1,217.78 | 3 Feet |
| DPT-8944 | 18.500 | 18.000 | $1,222.00 | 3 Feet |
| DPT-8953 | 18.562 | 18.062 | $1,226.16 | 3 Feet |
| DPT-8954 | 18.625 | 18.125 | $1,230.36 | 3 Feet |
| DPT-8955 | 18.687 | 18.187 | $1,234.50 | 3 Feet |
| DPT-8956 | 18.750 | 18.250 | $1,238.73 | 3 Feet |
| DPT-8957 | 18.812 | 18.312 | $1,242.88 | 3 Feet |
| DPT-9053 | 18.875 | 18.375 | $1,247.11 | 3 Feet |
| DPT-8928 | 18.937 | 18.437 | $1,251.26 | 3 Feet |
| DPT-9045 | 19.000 | 18.500 | $1,255.48 | 3 Feet |
| DPT-9038 | 19.062 | 18.562 | $1,259.63 | 3 Feet |
| DPT-9047 | 19.125 | 18.625 | $1,263.83 | 3 Feet |
| DPT-9048 | 19.187 | 18.687 | $1,267.98 | 3 Feet |
| DPT-9049 | 19.250 | 18.750 | $1,272.21 | 3 Feet |
| DPT-9050 | 19.312 | 18.812 | $1,276.36 | 3 Feet |
| DPT-9051 | 19.375 | 18.875 | $1,280.58 | 3 Feet |
| DPT-9052 | 19.437 | 18.937 | $1,284.73 | 3 Feet |
| DPT-9030 | 19.500 | 19.000 | $1,288.96 | 3 Feet |
| DPT-8766 | 19.562 | 19.062 | $1,293.11 | 3 Feet |
| DPT-9029 | 19.625 | 19.125 | $1,297.33 | 3 Feet |
| DPT-8797 | 19.687 | 19.187 | $1,301.48 | 3 Feet |
| DPT-8557 | 19.750 | 19.250 | $1,305.68 | 3 Feet |
| DPT-8558 | 19.812 | 19.312 | $1,309.83 | 3 Feet |
| DPT-8559 | 19.875 | 19.375 | $1,314.06 | 3 Feet |
| DPT-8560 | 19.937 | 19.437 | $1,318.21 | 3 Feet |
| DPT-8561 | 20.000 | 19.500 | $1,322.43 | 3 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
