G11 High Temperature Glass Tubes .500" Wall Thickness
G11 Glass Tubes - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10 FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.500" Wall Thickness G11 Tube |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum Purchase |
|---|---|---|---|---|
| DPT-11042 | 1.500 | 0.500 | $207.98 | 6 Feet |
| DPT-11043 | 1.562 | 0.562 | $219.38 | 6 Feet |
| DPT-11044 | 1.625 | 0.625 | $158.51 | 6 Feet |
| DPT-11045 | 1.687 | 0.687 | $166.33 | 6 Feet |
| DPT-11064 | 1.750 | 0.750 | $174.16 | 6 Feet |
| DPT-11047 | 1.812 | 0.812 | $181.98 | 6 Feet |
| DPT-11041 | 1.875 | 0.875 | $189.81 | 6 Feet |
| DPT-10734 | 1.937 | 0.937 | $197.66 | 6 Feet |
| DPT-10726 | 2.000 | 1.000 | $205.48 | 6 Feet |
| DPT-10736 | 2.062 | 1.062 | $213.23 | 6 Feet |
| DPT-10737 | 2.125 | 1.125 | $221.13 | 6 Feet |
| DPT-10738 | 2.187 | 1.187 | $228.91 | 6 Feet |
| DPT-10739 | 2.250 | 1.250 | $236.81 | 6 Feet |
| DPT-10740 | 2.312 | 1.312 | $244.56 | 6 Feet |
| DPT-8859 | 2.375 | 1.375 | $252.46 | 6 Feet |
| DPT-8971 | 2.437 | 1.437 | $260.23 | 6 Feet |
| DPT-1536 | 2.500 | 1.500 | $268.10 | 3 Feet |
| DPT-8973 | 2.562 | 1.562 | $275.88 | 3 Feet |
| DPT-8974 | 2.625 | 1.625 | $283.78 | 3 Feet |
| DPT-8952 | 2.687 | 1.687 | $291.53 | 3 Feet |
| DPT-1541 | 2.750 | 1.750 | $299.43 | 3 Feet |
| DPT-8967 | 2.812 | 1.812 | $307.21 | 3 Feet |
| DPT-8945 | 2.875 | 1.875 | $315.11 | 3 Feet |
| DPT-8946 | 2.937 | 1.937 | $322.86 | 3 Feet |
| DPT-1546 | 3.000 | 2.000 | $330.76 | 3 Feet |
| DPT-8948 | 3.062 | 2.062 | $338.53 | 3 Feet |
| DPT-8949 | 3.125 | 2.125 | $346.41 | 3 Feet |
| DPT-8959 | 3.187 | 2.187 | $354.18 | 3 Feet |
| DPT-1551 | 3.250 | 2.250 | $362.08 | 3 Feet |
| DPT-9044 | 3.312 | 2.312 | $369.83 | 3 Feet |
| DPT-9024 | 3.375 | 2.375 | $377.73 | 3 Feet |
| DPT-9025 | 3.437 | 2.437 | $385.50 | 3 Feet |
| DPT-1556 | 3.500 | 2.500 | $393.41 | 3 Feet |
| DPT-9027 | 3.562 | 2.562 | $401.16 | 3 Feet |
| DPT-9037 | 3.625 | 2.625 | $409.06 | 3 Feet |
| DPT-8568 | 3.687 | 2.687 | $416.83 | 3 Feet |
| DPT-1561 | 3.750 | 2.750 | $424.71 | 3 Feet |
| DPT-8570 | 3.812 | 2.812 | $432.48 | 3 Feet |
| DPT-8571 | 3.875 | 2.875 | $440.38 | 3 Feet |
| DPT-8572 | 3.937 | 2.937 | $448.13 | 3 Feet |
| DPT-1565 | 4.000 | 3.000 | $456.03 | 3 Feet |
| DPT-8574 | 4.062 | 3.062 | $463.81 | 3 Feet |
| DPT-9446 | 4.125 | 3.125 | $471.71 | 3 Feet |
| DPT-9445 | 4.187 | 3.187 | $479.46 | 3 Feet |
| DPT-1570 | 4.250 | 3.250 | $487.35 | 3 Feet |
| DPT-9443 | 4.312 | 3.312 | $495.13 | 3 Feet |
| DPT-9442 | 4.375 | 3.375 | $503.00 | 3 Feet |
| DPT-9441 | 4.437 | 3.437 | $510.78 | 3 Feet |
| DPT-1575 | 4.500 | 3.500 | $518.68 | 3 Feet |
| DPT-9439 | 4.562 | 3.562 | $526.43 | 3 Feet |
| DPT-9588 | 4.625 | 3.625 | $534.33 | 3 Feet |
| DPT-9380 | 4.687 | 3.687 | $542.11 | 3 Feet |
| DPT-1580 | 4.750 | 3.750 | $550.01 | 3 Feet |
| DPT-9692 | 4.812 | 3.812 | $557.76 | 3 Feet |
| DPT-9691 | 4.875 | 3.875 | $565.66 | 3 Feet |
| DPT-9689 | 4.937 | 3.937 | $573.43 | 3 Feet |
| DPT-1584 | 5.000 | 4.000 | $581.31 | 3 Feet |
| DPT-9617 | 5.062 | 4.062 | $589.08 | 3 Feet |
| DPT-9665 | 5.125 | 4.125 | $596.98 | 3 Feet |
| DPT-9637 | 5.187 | 4.187 | $604.73 | 3 Feet |
| DPT-9636 | 5.250 | 4.250 | $612.63 | 3 Feet |
| DPT-9635 | 5.312 | 4.312 | $620.41 | 3 Feet |
| DPT-9634 | 5.375 | 4.375 | $628.31 | 3 Feet |
| DPT-9633 | 5.437 | 4.437 | $636.06 | 3 Feet |
| DPT-1589 | 5.500 | 4.500 | $643.96 | 3 Feet |
| DPT-9631 | 5.562 | 4.562 | $651.73 | 3 Feet |
| DPT-9630 | 5.625 | 4.625 | $659.61 | 3 Feet |
| DPT-9629 | 5.687 | 4.687 | $667.38 | 3 Feet |
| DPT-9616 | 5.750 | 4.750 | $675.28 | 3 Feet |
| DPT-9627 | 5.812 | 4.812 | $683.03 | 3 Feet |
| DPT-9639 | 5.875 | 4.875 | $758.66 | 3 Feet |
| DPT-9625 | 5.937 | 4.937 | $767.21 | 3 Feet |
| DPT-1594 | 6.000 | 5.000 | $775.86 | 3 Feet |
| DPT-9623 | 6.062 | 5.062 | $784.38 | 3 Feet |
| DPT-9622 | 6.125 | 5.125 | $793.06 | 3 Feet |
| DPT-9621 | 6.187 | 5.187 | $801.58 | 3 Feet |
| DPT-9620 | 6.250 | 5.250 | $810.26 | 3 Feet |
| DPT-9619 | 6.312 | 5.312 | $818.78 | 3 Feet |
| DPT-9618 | 6.375 | 5.375 | $827.46 | 3 Feet |
| DPT-9650 | 6.437 | 5.437 | $835.98 | 3 Feet |
| DPT-1600 | 6.500 | 5.500 | $844.66 | 3 Feet |
| DPT-9628 | 6.562 | 5.562 | $853.18 | 3 Feet |
| DPT-9662 | 6.625 | 5.625 | $861.83 | 3 Feet |
| DPT-9661 | 6.687 | 5.687 | $870.36 | 3 Feet |
| DPT-9660 | 6.750 | 5.750 | $879.03 | 3 Feet |
| DPT-9659 | 6.812 | 5.812 | $887.56 | 3 Feet |
| DPT-9658 | 6.875 | 5.875 | $896.23 | 3 Feet |
| DPT-9657 | 6.937 | 5.937 | $904.76 | 3 Feet |
| DPT-1606 | 7.000 | 6.000 | $913.43 | 3 Feet |
| DPT-9655 | 7.062 | 6.062 | $878.78 | 3 Feet |
| DPT-9654 | 7.125 | 6.125 | $887.23 | 3 Feet |
| DPT-9653 | 7.187 | 6.187 | $895.53 | 3 Feet |
| DPT-9640 | 7.250 | 6.250 | $903.96 | 3 Feet |
| DPT-9651 | 7.312 | 6.312 | $912.26 | 3 Feet |
| DPT-9663 | 7.375 | 6.375 | $920.71 | 3 Feet |
| DPT-9649 | 7.437 | 6.437 | $929.01 | 3 Feet |
| DPT-9648 | 7.500 | 6.500 | $937.43 | 3 Feet |
| DPT-9647 | 7.562 | 6.562 | $945.73 | 3 Feet |
| DPT-9646 | 7.625 | 6.625 | $954.18 | 3 Feet |
| DPT-9645 | 7.687 | 6.687 | $962.48 | 3 Feet |
| DPT-9644 | 7.750 | 6.750 | $970.91 | 3 Feet |
| DPT-9643 | 7.812 | 6.812 | $979.23 | 3 Feet |
| DPT-9642 | 7.875 | 6.875 | $987.66 | 3 Feet |
| DPT-9857 | 7.937 | 6.937 | $995.96 | 3 Feet |
| DPT-9531 | 8.000 | 7.000 | $1,004.41 | 3 Feet |
| DPT-9833 | 8.062 | 7.062 | $1,012.71 | 3 Feet |
| DPT-9930 | 8.125 | 7.125 | $1,021.13 | 3 Feet |
| DPT-9980 | 8.187 | 7.187 | $1,029.43 | 3 Feet |
| DPT-9895 | 8.250 | 7.250 | $1,037.88 | 3 Feet |
| DPT-9967 | 8.312 | 7.312 | $1,046.18 | 3 Feet |
| DPT-9966 | 8.375 | 7.375 | $1,054.61 | 3 Feet |
| DPT-9965 | 8.437 | 7.437 | $1,062.91 | 3 Feet |
| DPT-9964 | 8.500 | 7.500 | $1,071.36 | 3 Feet |
| DPT-9963 | 8.562 | 7.562 | $1,079.66 | 3 Feet |
| DPT-9962 | 8.625 | 7.625 | $1,088.08 | 3 Feet |
| DPT-9951 | 8.687 | 7.687 | $1,096.38 | 3 Feet |
| DPT-9960 | 8.750 | 7.750 | $1,104.83 | 3 Feet |
| DPT-9969 | 8.812 | 7.812 | $1,113.13 | 3 Feet |
| DPT-9958 | 8.875 | 7.875 | $1,121.55 | 3 Feet |
| DPT-9957 | 8.937 | 7.937 | $1,129.86 | 3 Feet |
| DPT-9956 | 9.000 | 8.000 | $1,138.31 | 3 Feet |
| DPT-9954 | 9.125 | 8.125 | $1,155.03 | 3 Feet |
| DPT-9953 | 9.187 | 8.187 | $1,163.33 | 3 Feet |
| DPT-9978 | 9.250 | 8.250 | $1,171.78 | 3 Feet |
| DPT-9959 | 9.312 | 8.312 | $1,180.08 | 3 Feet |
| DPT-9961 | 9.375 | 8.375 | $1,188.50 | 3 Feet |
| DPT-9987 | 9.437 | 8.437 | $1,196.83 | 3 Feet |
| DPT-9986 | 9.500 | 8.500 | $1,205.25 | 3 Feet |
| DPT-9985 | 9.562 | 8.562 | $1,213.55 | 3 Feet |
| DPT-9984 | 9.625 | 8.625 | $1,222.00 | 3 Feet |
| DPT-9983 | 9.687 | 8.687 | $1,230.30 | 3 Feet |
| DPT-9982 | 9.750 | 8.750 | $1,238.73 | 3 Feet |
| DPT-9981 | 9.812 | 8.812 | $1,247.03 | 3 Feet |
| DPT-9970 | 9.875 | 8.875 | $1,255.48 | 3 Feet |
| DPT-9979 | 9.937 | 8.937 | $1,263.78 | 3 Feet |
| DPT-9988 | 10.000 | 9.000 | $1,272.21 | 3 Feet |
| DPT-9977 | 10.062 | 9.062 | $1,280.50 | 3 Feet |
| DPT-9976 | 10.125 | 9.125 | $1,288.96 | 3 Feet |
| DPT-9975 | 10.187 | 9.187 | $1,297.25 | 3 Feet |
| DPT-9974 | 10.250 | 9.250 | $1,305.68 | 3 Feet |
| DPT-9973 | 10.312 | 9.312 | $1,313.98 | 3 Feet |
| DPT-9972 | 10.375 | 9.375 | $1,322.43 | 3 Feet |
| DPT-9971 | 10.437 | 9.437 | $1,330.73 | 3 Feet |
| DPT-9942 | 10.500 | 9.500 | $1,339.16 | 3 Feet |
| DPT-9914 | 10.562 | 9.562 | $1,347.46 | 3 Feet |
| DPT-9952 | 10.625 | 9.625 | $1,355.91 | 3 Feet |
| DPT-9929 | 10.687 | 9.687 | $1,364.21 | 3 Feet |
| DPT-9928 | 10.750 | 9.750 | $1,372.63 | 3 Feet |
| DPT-9927 | 10.812 | 9.812 | $1,380.96 | 3 Feet |
| DPT-9926 | 10.875 | 9.875 | $1,389.38 | 3 Feet |
| DPT-9925 | 10.937 | 9.937 | $1,397.68 | 3 Feet |
| DPT-9924 | 11.000 | 10.000 | $1,406.13 | 3 Feet |
| DPT-9913 | 11.062 | 10.062 | $1,414.43 | 3 Feet |
| DPT-9922 | 11.125 | 10.125 | $1,422.86 | 3 Feet |
| DPT-9931 | 11.187 | 10.187 | $1,431.15 | 3 Feet |
| DPT-9920 | 11.250 | 10.250 | $1,439.60 | 3 Feet |
| DPT-9919 | 11.312 | 10.312 | $1,447.91 | 3 Feet |
| DPT-9918 | 11.375 | 10.375 | $1,456.33 | 3 Feet |
| DPT-9917 | 11.437 | 10.437 | $1,464.63 | 3 Feet |
| DPT-9916 | 11.500 | 10.500 | $1,473.08 | 3 Feet |
| DPT-9915 | 11.562 | 10.562 | $1,481.38 | 3 Feet |
| DPT-9940 | 11.625 | 10.625 | $1,489.80 | 3 Feet |
| DPT-9921 | 11.687 | 10.687 | $1,498.11 | 3 Feet |
| DPT-9923 | 11.750 | 10.750 | $1,506.56 | 3 Feet |
| DPT-9949 | 11.812 | 10.812 | $1,514.85 | 3 Feet |
| DPT-9948 | 11.875 | 10.875 | $1,523.28 | 3 Feet |
| DPT-9947 | 11.937 | 10.937 | $1,531.58 | 3 Feet |
| DPT-9946 | 12.000 | 11.000 | $1,540.03 | 3 Feet |
| DPT-9945 | 12.062 | 11.062 | $1,548.33 | 3 Feet |
| DPT-9944 | 12.125 | 11.125 | $1,556.75 | 3 Feet |
| DPT-9943 | 12.187 | 11.187 | $1,565.05 | 3 Feet |
| DPT-9932 | 12.250 | 11.250 | $1,573.50 | 3 Feet |
| DPT-9941 | 12.312 | 11.312 | $1,581.81 | 3 Feet |
| DPT-9950 | 12.375 | 11.375 | $1,590.23 | 3 Feet |
| DPT-9939 | 12.437 | 11.437 | $1,598.55 | 3 Feet |
| DPT-9938 | 12.500 | 11.500 | $1,606.98 | 3 Feet |
| DPT-9937 | 12.562 | 11.562 | $1,615.28 | 3 Feet |
| DPT-9936 | 12.625 | 11.625 | $1,623.73 | 3 Feet |
| DPT-9935 | 12.687 | 11.687 | $1,632.03 | 3 Feet |
| DPT-9934 | 12.750 | 11.750 | $1,640.46 | 3 Feet |
| DPT-10215 | 12.812 | 11.812 | $1,648.76 | 3 Feet |
| DPT-10472 | 12.875 | 11.875 | $1,657.21 | 3 Feet |
| DPT-10471 | 12.937 | 11.937 | $1,665.50 | 3 Feet |
| DPT-10470 | 13.000 | 12.000 | $1,673.93 | 3 Feet |
| DPT-10469 | 13.062 | 12.062 | $1,682.23 | 3 Feet |
| DPT-10468 | 13.125 | 12.125 | $1,690.68 | 3 Feet |
| DPT-10467 | 13.187 | 12.187 | $1,698.98 | 3 Feet |
| DPT-10458 | 13.250 | 12.250 | $1,707.40 | 3 Feet |
| DPT-10465 | 13.312 | 12.312 | $1,715.71 | 3 Feet |
| DPT-10473 | 13.375 | 12.375 | $1,724.16 | 3 Feet |
| DPT-10463 | 13.437 | 12.437 | $1,732.46 | 3 Feet |
| DPT-10462 | 13.500 | 12.500 | $1,740.88 | 3 Feet |
| DPT-10461 | 13.562 | 12.562 | $1,749.18 | 3 Feet |
| DPT-10460 | 13.625 | 12.625 | $1,757.63 | 3 Feet |
| DPT-10459 | 13.687 | 12.687 | $1,765.93 | 3 Feet |
| DPT-10481 | 13.750 | 12.750 | $1,774.36 | 3 Feet |
| DPT-10483 | 13.812 | 12.812 | $1,782.68 | 3 Feet |
| DPT-10466 | 13.875 | 12.875 | $1,791.10 | 3 Feet |
| DPT-10488 | 13.937 | 12.937 | $1,799.41 | 3 Feet |
| DPT-10487 | 14.000 | 13.000 | $1,807.86 | 3 Feet |
| DPT-10486 | 14.062 | 13.062 | $1,816.15 | 3 Feet |
| DPT-10485 | 14.125 | 13.125 | $1,824.58 | 3 Feet |
| DPT-10484 | 14.187 | 13.187 | $1,832.88 | 3 Feet |
| DPT-10474 | 14.250 | 13.250 | $1,841.33 | 3 Feet |
| DPT-10482 | 14.312 | 13.312 | $1,849.63 | 3 Feet |
| DPT-10490 | 14.375 | 13.375 | $1,858.06 | 3 Feet |
| DPT-10480 | 14.437 | 13.437 | $1,866.36 | 3 Feet |
| DPT-10479 | 14.500 | 13.500 | $1,874.80 | 3 Feet |
| DPT-10478 | 14.562 | 13.562 | $1,883.11 | 3 Feet |
| DPT-10477 | 14.625 | 13.625 | $1,891.53 | 3 Feet |
| DPT-10476 | 14.687 | 13.687 | $1,899.83 | 3 Feet |
| DPT-10475 | 14.750 | 13.750 | $1,908.28 | 3 Feet |
| DPT-10456 | 14.812 | 13.812 | $1,916.58 | 3 Feet |
| DPT-10431 | 14.875 | 13.875 | $1,925.01 | 3 Feet |
| DPT-10464 | 14.937 | 13.937 | $1,933.30 | 3 Feet |
| DPT-10438 | 15.000 | 14.000 | $1,941.75 | 3 Feet |
| DPT-10437 | 15.062 | 14.062 | $1,950.05 | 3 Feet |
| DPT-10436 | 15.125 | 14.125 | $1,958.48 | 3 Feet |
| DPT-10435 | 15.187 | 14.187 | $1,966.81 | 3 Feet |
| DPT-10434 | 15.250 | 14.250 | $1,975.23 | 3 Feet |
| DPT-10425 | 15.312 | 14.312 | $1,983.53 | 3 Feet |
| DPT-10432 | 15.375 | 14.375 | $1,991.96 | 3 Feet |
| DPT-10440 | 15.437 | 14.437 | $2,000.28 | 3 Feet |
| DPT-10430 | 15.500 | 14.500 | $2,008.71 | 3 Feet |
| DPT-10429 | 15.562 | 14.562 | $2,017.00 | 3 Feet |
| DPT-10428 | 15.625 | 14.625 | $2,025.46 | 3 Feet |
| DPT-10427 | 15.687 | 14.687 | $2,033.76 | 3 Feet |
| DPT-10426 | 15.750 | 14.750 | $2,042.18 | 3 Feet |
| DPT-10448 | 15.812 | 14.812 | $2,050.48 | 3 Feet |
| DPT-10450 | 15.875 | 14.875 | $2,058.93 | 3 Feet |
| DPT-10433 | 15.937 | 14.937 | $2,067.23 | 3 Feet |
| DPT-10455 | 16.000 | 15.000 | $2,075.65 | 3 Feet |
| DPT-10454 | 16.062 | 15.062 | $2,083.96 | 3 Feet |
| DPT-10453 | 16.125 | 15.125 | $2,092.40 | 3 Feet |
| DPT-10452 | 16.187 | 15.187 | $2,100.71 | 3 Feet |
| DPT-10451 | 16.250 | 15.250 | $2,109.13 | 3 Feet |
| DPT-10441 | 16.312 | 15.312 | $2,117.43 | 3 Feet |
| DPT-10449 | 16.375 | 15.375 | $2,125.88 | 3 Feet |
| DPT-10457 | 16.437 | 15.437 | $2,134.18 | 3 Feet |
| DPT-10447 | 16.500 | 15.500 | $2,142.61 | 3 Feet |
| DPT-10446 | 16.562 | 15.562 | $2,150.91 | 3 Feet |
| DPT-10445 | 16.625 | 15.625 | $2,159.36 | 3 Feet |
| DPT-10444 | 16.687 | 15.687 | $2,167.65 | 3 Feet |
| DPT-10443 | 16.750 | 15.750 | $2,176.08 | 3 Feet |
| DPT-10505 | 16.812 | 15.812 | $2,184.40 | 3 Feet |
| DPT-10439 | 16.875 | 15.875 | $2,192.83 | 3 Feet |
| DPT-10489 | 16.937 | 15.937 | $2,201.13 | 3 Feet |
| DPT-10538 | 17.000 | 16.000 | $2,209.58 | 3 Feet |
| DPT-10537 | 17.062 | 16.062 | $2,217.88 | 3 Feet |
| DPT-10536 | 17.125 | 16.125 | $2,226.31 | 3 Feet |
| DPT-10535 | 17.187 | 16.187 | $2,234.60 | 3 Feet |
| DPT-10534 | 17.250 | 16.250 | $2,243.06 | 3 Feet |
| DPT-10533 | 17.312 | 16.312 | $2,251.36 | 3 Feet |
| DPT-10524 | 17.375 | 16.375 | $2,259.78 | 3 Feet |
| DPT-10531 | 17.437 | 16.437 | $2,268.08 | 3 Feet |
| DPT-10539 | 17.500 | 16.500 | $2,276.53 | 3 Feet |
| DPT-10529 | 17.562 | 16.562 | $2,284.83 | 3 Feet |
| DPT-10528 | 17.625 | 16.625 | $2,293.26 | 3 Feet |
| DPT-10527 | 17.687 | 16.687 | $2,301.56 | 3 Feet |
| DPT-10526 | 17.750 | 16.750 | $2,310.01 | 3 Feet |
| DPT-10525 | 17.812 | 16.812 | $2,318.31 | 3 Feet |
| DPT-10724 | 17.875 | 16.875 | $2,326.73 | 3 Feet |
| DPT-10723 | 17.937 | 16.937 | $2,335.03 | 3 Feet |
| DPT-10532 | 18.000 | 17.000 | $2,343.48 | 3 Feet |
| DPT-10722 | 18.062 | 17.062 | $2,351.78 | 3 Feet |
| DPT-10721 | 18.125 | 17.125 | $2,360.21 | 3 Feet |
| DPT-10720 | 18.187 | 17.187 | $2,368.53 | 3 Feet |
| DPT-10719 | 18.250 | 17.250 | $2,376.96 | 3 Feet |
| DPT-10709 | 18.312 | 17.312 | $2,385.26 | 3 Feet |
| DPT-10540 | 18.375 | 17.375 | $2,393.68 | 3 Feet |
| DPT-10717 | 18.437 | 17.437 | $2,402.01 | 3 Feet |
| DPT-10725 | 18.500 | 17.500 | $2,410.43 | 3 Feet |
| DPT-10715 | 18.562 | 17.562 | $2,418.73 | 3 Feet |
| DPT-10714 | 18.625 | 17.625 | $2,427.18 | 3 Feet |
| DPT-10713 | 18.687 | 17.687 | $2,435.48 | 3 Feet |
| DPT-10712 | 18.750 | 17.750 | $2,443.90 | 3 Feet |
| DPT-10733 | 18.875 | 17.875 | $2,460.65 | 3 Feet |
| DPT-10711 | 18.812 | 17.812 | $2,452.21 | 3 Feet |
| DPT-10522 | 18.937 | 17.937 | $2,468.96 | 3 Feet |
| DPT-10497 | 19.000 | 18.000 | $2,477.38 | 3 Feet |
| DPT-10530 | 19.062 | 18.062 | $2,485.68 | 3 Feet |
| DPT-10504 | 19.125 | 18.125 | $2,494.13 | 3 Feet |
| DPT-10503 | 19.187 | 18.187 | $2,502.43 | 3 Feet |
| DPT-10502 | 19.250 | 18.250 | $2,510.85 | 3 Feet |
| DPT-10501 | 19.312 | 18.312 | $2,519.15 | 3 Feet |
| DPT-10500 | 19.375 | 18.375 | $2,527.61 | 3 Feet |
| DPT-10491 | 19.437 | 18.437 | $2,535.91 | 3 Feet |
| DPT-10498 | 19.500 | 18.500 | $2,544.33 | 3 Feet |
| DPT-10506 | 19.562 | 18.562 | $2,552.63 | 3 Feet |
| DPT-10496 | 19.625 | 18.625 | $2,561.08 | 3 Feet |
| DPT-10495 | 19.687 | 18.687 | $2,569.38 | 3 Feet |
| DPT-10494 | 19.750 | 18.750 | $2,577.81 | 3 Feet |
| DPT-10493 | 19.812 | 18.812 | $2,586.13 | 3 Feet |
| DPT-10492 | 19.875 | 18.875 | $2,594.56 | 3 Feet |
| DPT-10514 | 19.937 | 18.937 | $2,602.85 | 3 Feet |
| DPT-10516 | 20.000 | 19.000 | $2,611.31 | 3 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
