Cast Oil Filled Nylon Rods
Oil Filled Nylon was developed to extend the wear-resistant properties of unlubricated or dry lubricated materials such as MoS2 filled nylons. Will last 5 to 7 times longer than unlubricated or MoS2 dry lubricated cast nylons.
Lubrication results in 25% lower coefficient of friction and more dimensional stability due to reduced moisture absorption. Internal lubricant allows faster and easier machining than other nylons.
Cast Nylon Oil Filled Rod Green Color |
||
| Diameter (in.) | Part # | Price Per Foot |
|---|---|---|
| 1.00 | DPR-1469 | $57.48 |
| 1.25 | DPR-1470 | $54.71 |
| 1.50 | DPR-1471 | $57.43 |
| 1.75 | DPR-1472 | $64.93 |
| 2.00 | DPR-1449 | $67.94 |
| 2.25 | DPR-5310 | $81.53 |
| 2.50 | DPR-1473 | $91.70 |
| 2.75 | DPR-5311 | $105.83 |
| 3.00 | DPR-1450 | $100.86 |
| 3.25 | DPR-5360 | $115.75 |
| 3.50 | DPR-5348 | $145.05 |
| 3.75 | DPR-5362 | $255.62 |
| 4.00 | DPR-1450A | $174.86 |
| 4.25 | DPR-5363 | $112.15 |
| 4.50 | DPR-5364 | $202.28 |
| 4.75 | DPR-5365 | $406.56 |
| 5.00 | DPR-1451 | $271.32 |
| 5.25 | DPR-5366 | $452.78 |
| 5.50 | DPR-5367 | $294.04 |
| 6.00 | DPR-1452 | $648.63 |
| 6.25 | DPR-1452Q | $776.08 |
| 6.50 | DPR-5369 | $689.46 |
| 6.75 | DPR-5370 | $840.24 |
| 7.00 | DPR-5371 | $414.88 |
| 7.25 | DPR-5336 | $846.83 |
| 8.00 | DPR-1474 | $1,226.82 |
| Density | Tensile | Compressive | Shore | Coefficient | Continuous | Wear |
| g/cm3 | N/mm2 | N/mm2 | 'D' Scale | Sample | oC | Units |
| 1.12 | 65-70 | 85-100 | 80-85 | 0.10 | -80 | 25 |
