PTFE Bars
Virgin PTFE : The best chemically resistant material available and it continuously handles high temperatures.
Virgin PTFE Bar Etched on One Side (Bondable) Bars, Standard Lengths are 4 Feet. Etched Face is Brown, opposite Side is White, ASTM D3308, ASTM D3294 Tolerance +.062"/-0.00" |
|||
| Part # | Thickness (in.) | Width (in.) | Price Per Foot |
|---|---|---|---|
| DPBS-889 | .125 (+/- .007") | .500 | $17.28 |
| DPBS-890 | .125 (+/- .007") | 1.00 | $30.26 |
| DPBS-891 | .125 (+/- .007") | 1.50 | $42.79 |
| DPBS-892 | .125 (+/- .007") | 2.00 | $53.97 |
| DPBS-893 | .125 (+/- .007") | 3.00 | $74.78 |
| DPBS-894 | .125 (+/- .007") | 4.00 | $99.74 |
| DPBS-895 | .188 (+/- .012") | .500 | $16.85 |
| DPBS-896 | .188 (+/- .012") | 1.00 | $38.97 |
| DPBS-897 | .188 (+/- .012") | 1.50 | $55.21 |
| DPBS-898 | .188 (+/- .012") | 2.00 | $88.68 |
| DPBS-899 | .188 (+/- .012") | 3.00 | $106.59 |
| DPBS-900 | .188 (+/- .012") | 4.00 | $126.63 |
| DPBS-901 | .250 (+.031"/-.015") | .500 | $29.70 |
| DPBS-902 | .250 (+.031"/-.015") | 1.00 | $52.91 |
| DPBS-903 | .250 (+.031"/-.015") | 1.50 | $73.34 |
| DPBS-904 | .250 (+.031"/-.015") | 2.00 | $91.27 |
| DPBS-905 | .250 (+.031"/-.015") | 3.00 | $127.27 |
| DPBS-906 | .250 (+.031"/-.015") | 4.00 | $158.62 |
| DPBS-907 | .375 (+.038"/-.019") | .500 | $40.81 |
| DPBS-908 | .375 (+.038"/-.019") | 1.00 | $71.04 |
| DPBS-909 | .375 (+.038"/-.019") | 1.50 | $107.03 |
| DPBS-910 | .375 (+.038"/-.019") | 2.00 | $132.72 |
| DPBS-911 | .375 (+.038"/-.019") | 3.00 | $185.18 |
| DPBS-912 | .375 (+.038"/-.019") | 4.00 | $237.51 |
| DPBS-913 | .500 (+.046"/-.022") | .500 | $51.05 |
| DPBS-914 | .500 (+.046"/-.022") | 1.00 | $94.38 |
| DPBS-915 | .500 (+.046"/-.022") | 1.50 | $131.62 |
| DPBS-916 | .500 (+.046"/-.022") | 2.00 | $164.02 |
| DPBS-917 | .500 (+.046"/-.022") | 3.00 | $235.78 |
| DPBS-918 | .500 (+.046"/-.022") | 4.00 | $295.84 |
PTFE Rectangle Bar Virgin Grade White, Maximum Length 4 Feet Tolerance +.062"/-0.00" |
|||
| Part # | Thickness (in.) | Width (in.) | Price Per Foot |
|---|---|---|---|
| DPBS-919 | .125 (+.035"/-0.007") | .125 | $24.86 |
| DPBS-920 | .125 (+.035"/-0.007") | .500 | $14.92 |
| DPBS-921 | .125 (+.035"/-0.007") | 1.00 | $24.64 |
| DPBS-922 | .125 (+.035"/-0.007") | 1.50 | $32.44 |
| DPBS-923 | .125 (+.035"/-0.007") | 2.00 | $43.24 |
| DPBS-1327 | .125 (+.035"/-0.007") | 2.50 | $42.06 |
| DPBS-924 | .125 (+.035"/-0.007") | 3.00 | $57.80 |
| DPBS-1353 | .125 (+.035"/-0.007") | 3.50 | $54.64 |
| DPBS-925 | .125 (+.035"/-0.007") | 4.00 | $77.06 |
| DPBS-926 | .188 (+.035"/-0.012") | .188 | $27.72 |
| DPBS-927 | .188 (+.035"/-0.012") | .500 | $19.86 |
| DPBS-928 | .188 (+.035"/-0.012") | 1.00 | $32.44 |
| DPBS-929 | .188 (+.035"/-0.012") | 1.50 | $45.86 |
| DPBS-930 | .188 (+.035"/-0.012") | 2.00 | $57.80 |
| DPBS-1328 | .188 (+.035"/-0.012") | 2.50 | $33.34 |
| DPBS-931 | .188 (+.035"/-0.012") | 3.00 | $86.68 |
| DPBS-1354 | .187 (+.035"/-0.012") | 3.50 | $88.58 |
| DPBS-932 | .188 (+.035"/-0.012") | 4.00 | $106.88 |
| DPBS-933 | .250 (+.035"/-0.015") | .250 | $32.44 |
| DPBS-934 | .250 (+.035"/-0.015") | .500 | $24.64 |
| DPBS-935 | .250 (+.035"/-0.015") | 1.00 | $43.24 |
| DPBS-936 | .250 (+.035"/-0.015") | 1.50 | $57.80 |
| DPBS-937 | .250 (+.035"/-0.015") | 2.00 | $77.06 |
| DPBS-1329 | .250 (+.035"/-0.015") | 2.50 | $80.24 |
| DPBS-938 | .250 (+.035"/-0.015") | 3.00 | $106.88 |
| DPBS-1355 | .250 (+.035"/-0.015") | 3.50 | $108.10 |
| DPBS-939 | .250 (+.035"/-0.015") | 4.00 | $142.48 |
| DPBS-940 | .313 (+.035"/-0.015") | .313 | $40.90 |
| DPBS-941 | .375 (+.038"/-0.019") | .375 | $45.06 |
| DPBS-942 | .375 (+.038"/-0.019") | .500 | $32.92 |
| DPBS-943 | .375 (+.038"/-0.019") | 1.00 | $58.72 |
| DPBS-944 | .375 (+.038"/-0.019") | 1.50 | $88.02 |
| DPBS-945 | .375 (+.038"/-0.019") | 2.00 | $108.58 |
| DPBS-1330 | .375 (+.038"/-0.019") | 2.50 | $117.68 |
| DPBS-946 | .375 (+.038"/-0.019") | 3.00 | $151.42 |
| DPBS-1356 | .375 (+.038"/-0.019") | 3.50 | $160.58 |
| DPBS-947 | .375 (+.038"/-0.019") | 4.00 | $188.74 |
| DPBS-948 | .500 (+.046"/-0.022") | .500 | $40.88 |
| DPBS-949 | .500 (+.046"/-0.022") | 1.00 | $77.06 |
| DPBS-950 | .500 (+.046"/-0.022") | 1.50 | $106.88 |
| DPBS-951 | .500 (+.046"/-0.022") | 2.00 | $142.48 |
| DPBS-1331 | .500 (+.046"/-0.022") | 2.50 | $149.86 |
| DPBS-952 | .500 (+.046"/-0.022") | 3.00 | $185.78 |
| DPBS-1357 | .500 (+.046"/-0.022") | 3.50 | $205.56 |
| DPBS-953 | .500 (+.046"/-0.022") | 4.00 | $237.38 |
| DPBS-954 | .625 (+.062"/-0.027") | .500 | $51.50 |
| DPBS-955 | .625 (+.062"/-0.027") | .625 | $88.40 |
| DPBS-956 | .625 (+.062"/-0.027") | 1.00 | $97.38 |
| DPBS-957 | .625 (+.062"/-0.027") | 1.50 | $135.08 |
| DPBS-958 | .625 (+.062"/-0.027") | 2.00 | $167.52 |
| DPBS-959 | .625 (+.062"/-0.027") | 3.00 | $225.08 |
| DPBS-960 | .625 (+.062"/-0.027") | 4.00 | $288.08 |
| DPBS-961 | .750 (+.070"/-0.035") | .500 | $57.26 |
| DPBS-962 | .750 (+.070"/-0.035") | .750 | $67.41 |
| DPBS-963 | .750 (+.070"/-0.035") | 1.00 | $105.88 |
| DPBS-964 | .750 (+.070"/-0.035") | 1.50 | $147.76 |
| DPBS-965 | .750 (+.070"/-0.035") | 2.00 | $184.12 |
| DPBS-1333 | .750 (+.070"/-0.035") | 2.50 | $225.28 |
| DPBS-966 | .750 (+.070"/-0.035") | 3.00 | $254.04 |
| DPBS-967 | .750 (+.070"/-0.035") | 4.00 | $325.66 |
| DPBS-968 | 1.00 (+.090"/-0.045") | 1.00 | $137.56 |
| DPBS-969 | 1.00 (+.090"/-0.045") | 1.50 | $184.12 |
| DPBS-970 | 1.00 (+.090"/-0.045") | 2.00 | $229.68 |
| DPBS-1335 | 1.00 (+.090"/-0.045") | 2.50 | $358.86 |
| DPBS-971 | 1.00 (+.090"/-0.045") | 3.00 | $325.66 |
| DPBS-972 | 1.00 (+.090"/-0.045") | 4.00 | $410.52 |
| DPBS-973 | 1.25 (+.090"/-0.045") | 1.25 | $137.56 |
| DPBS-974 | 1.50 (+.140"/-0.070") | 1.50 | $275.36 |
| DPBS-975 | 1.50 (+.140"/-0.070") | 2.00 | $325.00 |
| DPBS-976 | 1.50 (+.140"/-0.070") | 3.00 | $460.88 |
| DPBS-977 | 1.50 (+.140"/-0.070") | 4.00 | $592.92 |
| DPBS-978 | 2.00 (+.185"/-0.090") | 2.00 | $442.12 |
| DPBS-1339 | 2.00 (+.185"/-0.090") | 2.50 | $565.90 |
| DPBS-979 | 2.00 (+.185"/-0.090") | 3.00 | $599.58 |
| DPBS-980 | 2.00 (+.185"/-0.090") | 4.00 | $772.32 |
