1.50" Long Spacers
| 1.50" Length Spacers | ||||||||
| Part # | Material | Screw Size | OD | OD Tol | ID | ID Tol | Pkg. Qty. | Pkg. Price |
|---|---|---|---|---|---|---|---|---|
| Spacer-475 | 18-8 Stainless Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $9.50 |
| Spacer-487 | 18-8 Stainless Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $9.58 |
| Spacer-499 | 18-8 Stainless Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $9.50 |
| Spacer-541 | 18-8 Stainless Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $14.29 |
| Spacer-1530 | 18-8 Stainless Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $12.88 |
| Spacer-1570 | 18-8 Stainless Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $16.26 |
| Spacer-511 | 18-8 Stainless Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $9.50 |
| Spacer-571 | 18-8 Stainless Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $14.29 |
| Spacer-1535 | 18-8 Stainless Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $12.88 |
| Spacer-1595 | 18-8 Stainless Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $16.26 |
| Spacer-601 | 18-8 Stainless Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $14.29 |
| Spacer-1540 | 18-8 Stainless Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $12.88 |
| Spacer-1620 | 18-8 Stainless Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $16.26 |
| Spacer-1660 | 18-8 Stainless Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $28.59 |
| Spacer-1545 | 18-8 Stainless Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $12.88 |
| Spacer-1645 | 18-8 Stainless Steel | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $16.26 |
| Spacer-1675 | 18-8 Stainless Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $28.59 |
| Spacer-1693 | 18-8 Stainless Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $35.94 |
| Spacer-1684 | 18-8 Stainless Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $35.94 |
| Spacer-918 | Aluminum 2011-T3 | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $2.80 |
| Spacer-930 | Aluminum 2011-T3 | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $2.88 |
| Spacer-823 | Aluminum 2011-T3 | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $2.80 |
| Spacer-961 | Aluminum 2011-T3 | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $6.35 |
| Spacer-1866 | Aluminum 2011-T3 | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $4.38 |
| Spacer-1906 | Aluminum 2011-T3 | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $9.17 |
| Spacer-942 | Aluminum 2011-T3 | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $2.80 |
| Spacer-991 | Aluminum 2011-T3 | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $6.35 |
| Spacer-1871 | Aluminum 2011-T3 | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $4.38 |
| Spacer-1931 | Aluminum 2011-T3 | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $9.17 |
| Spacer-1021 | Aluminum 2011-T3 | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $6.35 |
| Spacer-1876 | Aluminum 2011-T3 | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $4.38 |
| Spacer-1956 | Aluminum 2011-T3 | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $9.09 |
| Spacer-1997 | Aluminum 2011-T3 | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $11.08 |
| Spacer-1881 | Aluminum 2011-T3 | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $4.38 |
| Spacer-2056 | Aluminum 2011-T3 | 1.00" | 1.50" | +/-.003" | 1.005" | +.010"/-0 | 1 | $30.53 |
| Spacer-2038 | Aluminum 2011-T3 | 1/2" | 1.00" | +/-.003" | .505"" | +.010"/-0 | 1 | $31.66 |
| Spacer-2012 | Aluminum 2011-T3 | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $11.08 |
| Spacer-2050 | Aluminum 2011-T3 | 3/4" | 1.50" | +/-.003" | .755" | +.010"/-0 | 1 | $30.61 |
| Spacer-3039 | Aluminum 2011-T3 | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $11.08 |
| Spacer-2044 | Aluminum 2011-T3 | 5/8" | 1.00" | +/-.003" | .630" | +.010"/-0 | 1 | $31.66 |
| Spacer-1379 | Nylon 6-6 Natural | 4 | .250" | +/-.015" | .115" | +/-.005" | 50 | $37.78 |
| Spacer-1392 | Nylon 6-6 Natural | 6 | .250" | +/-.015" | .140" | +/-.005" | 50 | $37.70 |
| Spacer-2895 | Nylon 6-6 Natural | 6 | .312" | +/-.015" | .140" | +/-.005" | 50 | $40.16 |
| Spacer-2252 | Nylon 6-6 Natural | 6 | .375" | +/-.015" | .140" | +/-.005" | 50 | $37.37 |
| Spacer-2291 | Nylon 6-6 Natural | 6 | .500" | +/-.015" | .140" | +/-.005" | 5 | $37.83 |
| Spacer-2909 | Nylon 6-6 Natural | 8 | .312" | +/-.015" | .166" | +/-.005" | 100 | $80.08 |
| Spacer-2257 | Nylon 6-6 Natural | 8 | .375" | +/-.015" | .166" | +/-.005" | 50 | $37.37 |
| Spacer-2315 | Nylon 6-6 Natural | 8 | .500" | +/-.015" | .166" | +/-.005" | 5 | $37.83 |
| Spacer-2893 | Nylon 6-6 Natural | 10 | .312" | +/-.015" | .192" | +/-.005" | 50 | $40.16 |
| Spacer-2262 | Nylon 6-6 Natural | 10 | .375" | +/-.015" | .192" | +/-.005" | 50 | $37.37 |
| Spacer-2339 | Nylon 6-6 Natural | 10 | .500" | +/-.015" | .192" | +/-.005" | 5 | $37.83 |
| Spacer-2363 | Nylon 6-6 Natural | 1/4" | .500" | +/-.015" | .252" | +/-.005" | 5 | $37.83 |
| Spacer-3092 | Zinc Plated Brass | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $14.84 |
| Spacer-3077 | Zinc Plated Brass | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $14.84 |
| Spacer-3076 | Zinc Plated Brass | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $15.55 |
| Spacer-1825 | Zinc Plated Brass | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $26.93 |
| Spacer-3075 | Zinc Plated Brass | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $15.55 |
| Spacer-1841 | Zinc Plated Brass | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $28.25 |
| Spacer-1861 | Zinc Plated Brass | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $31.19 |
| Spacer-1851 | Zinc Plated Brass | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $31.19 |
| Spacer-1135 | Zinc Plated Steel | 2 | .250" | +/-.003" | .090" | +.010"/-0 | 1 | $6.46 |
| Spacer-1148 | Zinc Plated Steel | 4 | .250" | +/-.003" | .115" | +.010"/-0 | 1 | $6.54 |
| Spacer-1161 | Zinc Plated Steel | 6 | .250" | +/-.003" | .140" | +.010"/-0 | 1 | $6.46 |
| Spacer-1204 | Zinc Plated Steel | 6 | .312" | +/-.003" | .140" | +.010"/-0 | 1 | $10.82 |
| Spacer-2059 | Zinc Plated Steel | 6 | .375" | +/-.003" | .140" | +.010"/-0 | 1 | $10.82 |
| Spacer-2096 | Zinc Plated Steel | 6 | .500" | +/-.003" | .140" | +.010"/-0 | 1 | $12.02 |
| Spacer-1174 | Zinc Plated Steel | 8 | .250" | +/-.003" | .166" | +.010"/-0 | 1 | $6.77 |
| Spacer-1234 | Zinc Plated Steel | 8 | .312" | +/-.003" | .166" | +.010"/-0 | 1 | $10.82 |
| Spacer-2063 | Zinc Plated Steel | 8 | .375" | +/-.003" | .166" | +.010"/-0 | 1 | $10.82 |
| Spacer-2121 | Zinc Plated Steel | 8 | .500" | +/-.003" | .166" | +.010"/-0 | 1 | $12.02 |
| Spacer-1264 | Zinc Plated Steel | 10 | .312" | +/-.003" | .192" | +.010"/-0 | 1 | $10.82 |
| Spacer-2067 | Zinc Plated Steel | 10 | .375" | +/-.003" | .192" | +.010"/-0 | 1 | $10.82 |
| Spacer-2146 | Zinc Plated Steel | 10 | .500" | +/-.003" | .192" | +.010"/-0 | 1 | $12.02 |
| Spacer-2187 | Zinc Plated Steel | 10 | .625" | +/-.003" | .192" | +.010"/-0 | 1 | $15.21 |
| Spacer-2071 | Zinc Plated Steel | 12 | .375" | +/-.003" | .218" | +.010"/-0 | 1 | $10.82 |
| Spacer-2248 | Zinc Plated Steel | 1.00" | 1.50" | +/-.003" | 1.005" | +.010"/-0 | 1 | $52.07 |
| Spacer-2230 | Zinc Plated Steel | 1/2" | 1.00" | +/-.003" | .505"" | +.010"/-0 | 1 | $41.34 |
| Spacer-2171 | Zinc Plated Steel | 1/4" | .500" | +/-.003" | .252" | +.010"/-0 | 1 | $12.02 |
| Spacer-2203 | Zinc Plated Steel | 1/4" | .625" | +/-.003" | .252" | +.010"/-0 | 1 | $15.21 |
| Spacer-2242 | Zinc Plated Steel | 3/4" | 1.50" | +/-.003" | .755" | +.010"/-0 | 1 | $52.15 |
| Spacer-2223 | Zinc Plated Steel | 3/8" | .750" | +/-.003" | .380"" | +.010"/-0 | 1 | $19.14 |
| Spacer-2213 | Zinc Plated Steel | 5/16" | .750" | +/-.003" | .315" | +.010"/-0 | 1 | $19.14 |
| Spacer-2236 | Zinc Plated Steel | 5/8" | 1.00" | +/-.003" | .630" | +.010"/-0 | 1 | $41.34 |
| Screw size number | SAE diameter (inch) | Metric diameter (mm) | Screw size number | SAE diameter (inch) | Metric diameter (mm) | |
| #0 | 0.060 | 1.524 | #9 | 0.177 | 4.496 | |
| #1 | 0.073 | 1.854 | #10 | 0.190 | 4.826 | |
| #2 | 0.086 | 2.184 | #11 | 0.203 | 5.156 | |
| #3 | 0.099 | 2.515 | #12 | 0.216 | 5.486 | |
| #4 | 0.122 | 3.099 | #14 | 0.242 | 6.147 | |
| #5 | 0.125 | 3.175 | #16 | 0.268 | 6.807 | |
| #6 | 0.138 | 3.505 | #18 | 0.294 | 7.468 | |
| #7 | 0.151 | 3.835 | #20 | 0.320 | 8.128 | |
| #8 | 0.164 | 4.166 | #24 | 0.372 | 9.449 |
