Slotted Spring Pins: 18-8 Stainless Steel

Stainless steel Slotted Spring Pin
18-8 Slotted Stainless Steel Spring Pins, Inches
Corrosion resistant, mildly magnetic.
Part # Diameter (in.) Length (in.) Pkg. Qty. Pkg. Price
DSP-753 0.062 0.187 400 $23.52
DSP-751 0.062 0.250 200 $20.72
DSP-750 0.062 0.312 200 $20.84
DSP-749 0.062 0.375 200 $22.48
DSP-748 0.062 0.437 200 $23.60
DSP-734 0.062 0.500 200 $24.72
DSP-745 0.062 0.562 300 $23.46
DSP-757 0.062 0.625 200 $21.64
DSP-743 0.062 0.687 300 $24.66
DSP-742 0.062 0.750 200 $26.76
DSP-741 0.062 0.875 200 $35.84
DSP-740 0.062 1.000 100 $15.03
DSP-739 0.078 0.187 300 $21.42
DSP-738 0.078 0.250 300 $18.48
DSP-737 0.078 0.312 300 $18.78
DSP-736 0.078 0.375 300 $19.20
DSP-769 0.078 0.437 400 $24.48
DSP-771 0.078 0.500 400 $24.80
DSP-762 0.078 0.562 300 $23.64
DSP-761 0.078 0.625 300 $20.46
DSP-760 0.078 0.687 300 $24.84
DSP-759 0.078 0.750 300 $23.16
DSP-732 0.078 0.812 300 $26.40
DSP-695 0.078 0.875 200 $18.16
DSP-744 0.078 1.000 200 $20.92
DSP-706 0.078 1.250 200 $24.44
DSP-704 0.078 1.500 200 $24.76
DSP-752 0.093 0.187 300 $21.78
DSP-747 0.093 0.250 400 $21.28
DSP-735 0.093 0.312 400 $22.24
DSP-705 0.093 0.375 400 $24.00
DSP-703 0.093 0.437 400 $25.60
DSP-702 0.093 0.500 300 $20.16
DSP-701 0.093 0.562 300 $21.66
DSP-700 0.093 0.625 300 $21.60
DSP-699 0.093 0.687 300 $23.46
DSP-698 0.093 0.750 300 $22.44
DSP-685 0.093 0.812 300 $25.74
DSP-717 0.093 0.875 300 $23.94
DSP-716 0.093 1.000 200 $18.84
DSP-715 0.093 1.125 200 $21.44
DSP-714 0.093 1.250 100 $21.96
DSP-713 0.093 1.375 200 $22.04
DSP-712 0.093 1.500 200 $27.32
DSP-780 0.125 0.187 300 $23.16
DSP-746 0.125 0.250 300 $22.44
DSP-779 0.125 0.375 300 $23.52
DSP-778 0.125 0.437 300 $24.96
DSP-777 0.125 0.500 300 $25.02
DSP-776 0.125 0.562 300 $26.46
DSP-775 0.125 0.625 200 $18.48
DSP-774 0.125 0.687 200 $19.64
DSP-773 0.125 0.750 200 $20.28
DSP-758 0.125 0.812 200 $22.40
DSP-770 0.125 0.875 200 $24.28
DSP-782 0.125 1.000 200 $26.56
DSP-768 0.125 1.125 200 $29.52
DSP-767 0.125 1.250 200 $32.68
DSP-766 0.125 1.375 200 $35.84
DSP-764 0.125 1.500 100 $30.40
DSP-763 0.125 1.625 100 $23.20
DSP-708 0.125 1.750 100 $23.46
DSP-694 0.125 1.875 100 $26.16
DSP-693 0.125 2.000 100 $27.36
DSP-692 0.125 2.250 50 $27.44
DSP-691 0.125 2.500 100 $30.08
DSP-690 0.156 0.375 200 $23.88
DSP-689 0.156 0.500 200 $24.00
DSP-688 0.156 0.625 200 $28.00
DSP-687 0.156 0.750 200 $30.48
DSP-686 0.156 0.875 200 $34.40
DSP-720 0.156 1.000 100 $26.90
DSP-722 0.156 1.125 100 $41.81
DSP-697 0.156 1.250 100 $36.35
DSP-731 0.156 1.375 100 $19.78
DSP-730 0.156 1.750 50 $32.48
DSP-729 0.156 2.000 50 $18.98
DSP-728 0.156 2.500 50 $20.48
DSP-727 0.187 0.375 100 $33.34
DSP-726 0.187 0.437 25 $26.58
DSP-725 0.187 0.500 100 $23.68
DSP-724 0.187 0.562 100 $19.60
DSP-723 0.187 0.625 100 $19.56
DSP-709 0.187 0.687 100 $38.01
DSP-721 0.187 0.750 100 $21.96
DSP-733 0.187 0.812 50 $22.20
DSP-719 0.187 0.875 100 $23.92
DSP-781 0.187 1.000 100 $39.77
DSP-854 0.187 1.000 100 $24.36
DSP-853 0.187 1.250 100 $33.84
DSP-852 0.187 1.375 50 $38.17
DSP-718 0.187 1.500 50 $42.16
DSP-851 0.187 1.625 100 $30.96
DSP-850 0.187 1.750 50 $48.57
DSP-849 0.187 1.875 50 $24.26
DSP-848 0.187 2.000 50 $30.78
DSP-847 0.187 2.250 50 $31.10
DSP-846 0.187 2.500 50 $58.75
DSP-832 0.187 2.750 25 $20.68
DSP-844 0.187 3.000 25 $25.34
DSP-856 0.218 0.500 100 $24.56
DSP-842 0.218 0.625 50 $27.97
DSP-841 0.218 0.750 50 $34.58
DSP-840 0.218 1.000 50 $39.90
DSP-839 0.218 1.250 50 $23.72
DSP-838 0.218 1.500 50 $27.42
DSP-837 0.218 1.750 50 $35.12
DSP-836 0.218 2.000 25 $36.18
DSP-835 0.218 2.250 25 $21.28
DSP-834 0.218 2.500 25 $21.48
DSP-868 0.218 2.750 25 $29.42
DSP-843 0.218 3.000 25 $31.04
DSP-845 0.250 0.500 100 $32.88
DSP-880 0.250 0.625 100 $33.08
DSP-879 0.250 0.750 50 $36.24
DSP-878 0.250 0.875 50 $38.66
DSP-877 0.250 1.000 50 $43.09
DSP-876 0.250 1.125 50 $33.78
DSP-875 0.250 1.250 50 $27.14
DSP-874 0.250 1.375 50 $29.16
DSP-873 0.250 1.500 50 $31.32
DSP-872 0.250 1.625 25 $29.48
DSP-871 0.250 1.750 25 $35.97
DSP-857 0.250 1.875 25 $20.50
DSP-869 0.250 2.000 25 $23.24
DSP-881 0.250 2.250 25 $25.96
DSP-867 0.250 2.500 25 $31.40
DSP-866 0.250 2.750 25 $20.20
DSP-865 0.250 3.000 20 $31.28
DSP-864 0.250 3.250 20 $18.04
DSP-863 0.250 3.500 10 $19.82
DSP-862 0.312 0.750 25 $27.00
DSP-861 0.312 1.000 50 $28.76
DSP-860 0.312 1.250 50 $33.76
DSP-859 0.312 1.500 25 $19.50
DSP-830 0.312 1.750 25 $22.10
DSP-870 0.312 2.000 20 $30.84
DSP-833 0.312 2.250 10 $25.76
DSP-805 0.312 2.500 20 $26.40
DSP-804 0.312 2.750 20 $28.56
DSP-803 0.312 3.000 20 $32.64
DSP-802 0.312 3.250 20 $35.88
DSP-801 0.312 3.500 20 $35.88
DSP-800 0.312 3.750 20 $21.48
DSP-799 0.312 4.000 10 $20.64
DSP-798 0.375 0.750 20 $20.24
DSP-797 0.375 1.000 20 $24.36
DSP-796 0.375 1.250 20 $28.40
DSP-783 0.375 1.500 20 $32.48
DSP-794 0.375 1.750 10 $24.82
DSP-806 0.375 2.000 10 $27.76
DSP-792 0.375 2.250 10 $22.50
DSP-791 0.375 2.500 10 $23.40
DSP-789 0.375 2.750 10 $26.44
DSP-788 0.375 3.000 10 $28.58
DSP-787 0.375 3.250 5 $19.62
DSP-786 0.375 3.500 5 $18.40
DSP-785 0.375 3.750 5 $20.40
DSP-784 0.375 4.000 5 $20.18
DSP-790 0.437 1.750 10 $35.20
DSP-818 0.437 2.000 10 $20.00
DSP-820 0.437 2.500 5 $20.43
DSP-795 0.437 3.000 5 $17.49
DSP-829 0.437 4.000 20 $21.68
DSP-828 0.500 1.250 10 $22.52
DSP-827 0.500 1.500 10 $23.64
DSP-826 0.500 1.750 10 $24.92
DSP-825 0.500 2.000 10 $27.88
DSP-824 0.500 2.250 10 $30.64
DSP-823 0.500 2.500 5 $23.56
DSP-822 0.500 2.750 5 $28.51
DSP-821 0.500 3.000 5 $20.80
DSP-807 0.500 3.250 4 $22.64
DSP-819 0.500 3.500 3 $18.00
DSP-552 0.500 3.750 3 $18.48
DSP-551 0.500 4.000 5 $30.00


Tolerances
Lengths 0-1.0" +/-.015"
Lengths 1.125"-2.0" +/-.020"
Lengths 2.25"-3.0" +/-.025"
Lengths  3.25" and up +/-.030"
Lengths 0-24mm +/- .40mm
Lengths 26mm-50mm +/- .50mm
Lengths 55mm-60mm +/- .60mm
Lengths 80mm and up +/- .75mm

Metric Imperial Inches
Nominal Dia.   M2 M2.5 M3 M4 M5 M6 M8 1/16" 5/64" 3/32" 1/8" 5/32" 3/16" 7/32" 1/4" 5/16" 3/8" 7/16" 1/2" 5/8"
Act. Dia Min. mm 2.13 2.65 3.15 4.20 5.25 6.25 8.30 0.066 0.083 0.099 0.131 0.162 0.194 0.226 0.258 0.321 0.385 0.448 0.513 0.640
  Max. mm 2.25 2.78 3.30 4.40 5.50 6.50 8.63 0.069 0.086 0.103 0.135 0.137 0.199 0.232 0.264 0.330 0.395 0.459 0.524 0.653
Wall Thickness   * * * * * * * 0.012 0.018 0.022 0.028 0.032 0.040 0.048 0.048 0.062 0.077 0.077 0.094 0.125
Suggested Min. mm 2.00 2.50 3.00 4.00 5.10 6.00 8.00 0.062 0.078 0.094 0.125 0.156 0.187 0.219 0.250 0.312 0.375 0.437 0.500 0.625
Hole Size Max. mm 2.10 2.60 3.10 4.12 5.12 6.12 8.15 0.065 0.081 0.097 0.129 0.160 0.192 0.224 0.256 0.318 0.382 0.445 0.510 0.636
Shear Strength Lbs   562 876 1236 2158 3372 4945 8767 * * * * * * * * * * * * *
Shear Strength Lbs 18-8 SS   * * * * * * * 250 460 670 1090 1600 2425 3400 4100 6300 9500 11500 15800 18800
Shear Strength Lbs 420 SS   * * * * * * * 430 800 1150 1875 2750 4150 5850 7050 10800 16300 19800 27100 46000
