Victex PEEK Pressure Sensitive Tape
ASTM D1000, ASTM D3759, ASTM D140
Dielectric Strength: 8800 V/Mil
Elongation: 165%
Tensile : 36 Lb/In
Max. Oper. Temp 350F - Acrylic, Silicone 450F
One Side Adhesive
| Part # | Tape Width | Adhesive Thickness | Total Overall Thickness | Length | Rolls/Pkg | Pkg. Price |
|---|---|---|---|---|---|---|
| Acrylic Adhesive | ||||||
| TAPE-530 | .500" | .002" | .004" | 15' | 2 | $26.58 |
| TAPE-531 | .500" | .005" | .007" | 15' | 2 | $32.41 |
| TAPE-532 | .500" | .010" | .012" | 15' | 1 | $47.76 |
| TAPE-539 | 1.00" | .002" | .004" | 15' | 1 | $53.09 |
| TAPE-541 | 1.00" | .005" | .007" | 15' | 1 | $48.54 |
| TAPE-542 | 1.00" | .005" | .007" | 108' | 1 | $221.84 |
| TAPE-543 | 1.00" | .010" | .012" | 15' | 1 | $95.41 |
| TAPE-560 | 2.00" | .002" | .004" | 15' | 1 | $129.41 |
| TAPE-561 | 2.00" | .005" | .007" | 15' | 1 | $129.41 |
| TAPE-562 | 2.00" | .010" | .012" | 15' | 1 | $190.72 |
| TAPE-571 | 6.00" | .002" | .004" | 6.00" | 4 | $12.79 |
| TAPE-572 | 6.00" | .005" | .007" | 6.00" | 3 | $30.95 |
| TAPE-573 | 6.00" | .010" | .012" | 6.00" | 2 | $35.47 |
| TAPE-551 | 12.00" | .002" | .004" | 12.00" | 1 | $38.24 |
| TAPE-552 | 12.00" | .005" | .007" | 12.00" | 1 | $81.91 |
| TAPE-553 | 12.00" | .010" | .012" | 12.00" | 1 | $194.57 |
| Silicone Adhesive | ||||||
| TAPE-533 | .500" | .002" | .004" | 15' | 2 | $39.86 |
| TAPE-534 | .500" | .005" | .007" | 15' | 1 | $47.94 |
| TAPE-535 | .500" | .010" | .012" | 15' | 1 | $45.08 |
| TAPE-544 | 1.00" | .002" | .004" | 15' | 1 | $79.57 |
| TAPE-549 | 1.00" | .005" | .007" | 15' | 1 | $95.77 |
| TAPE-550 | 1.00" | .010" | .012" | 15' | 1 | $90.08 |
| TAPE-548 | 1.00" | .010" | .012" | 108' | 1 | $324.08 |
| TAPE-563 | 2.00" | .002" | .004" | 15' | 1 | $159.07 |
| TAPE-569 | 2.00" | .005" | .007" | 15' | 1 | $191.49 |
| TAPE-570 | 2.00" | .010" | .012" | 15' | 1 | $180.08 |
| TAPE-568 | 2.00" | .010" | .012" | 108' | 1 | $648.08 |
| TAPE-574 | 6.00" | .002" | .004" | 6.00" | 3 | $21.79 |
| TAPE-576 | 6.00" | .005" | .007" | 6.00" | 2 | $28.79 |
| TAPE-575 | 6.00" | .010" | .012" | 6.00" | 2 | $48.73 |
| TAPE-554 | 12.00" | .002" | .004" | 12.00" | 1 | $86.80 |
| TAPE-555 | 12.00" | .005" | .007" | 12.00" | 1 | $114.83 |
| TAPE-556 | 12.00" | .010" | .012" | 12.00" | 1 | $194.57 |
