PTFE Pressure Sensitive Tape
| PTFE Skived Tapes | ||||||||||
| Pressure Sensitive, Chemical Resistant Silicone Adhesive | ||||||||||
| Part # | Tape Width | Adhesive Thickness | Total Overall Thickness | Length (ft.) | Adhesion Oz/In. | Break Strength Lb/In | Elongation % | Dielectric Strength V/m | Rolls/Pkg | Price |
|---|---|---|---|---|---|---|---|---|---|---|
| TAPE-952 | .250" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 3 | $18.22 |
| TAPE-953 | .250" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 3 | $18.22 |
| TAPE-954 | .250" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 2 | $26.29 |
| TAPE-977 | .500" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 3 | $18.78 |
| TAPE-976 | .500" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 1 | $70.01 |
| TAPE-979 | .500" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 2 | $25.96 |
| TAPE-978 | .500" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $95.30 |
| TAPE-980 | .500" | .0015" | .0065" | 108' | 25 | 75 | 100 | 16,000 | 1 | $122.84 |
| TAPE-981 | .500" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $50.57 |
| TAPE-1018 | .750" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 2 | $28.12 |
| TAPE-1017 | .750" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 1 | $103.96 |
| TAPE-1020 | .750" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 2 | $38.89 |
| TAPE-1019 | .750" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $142.84 |
| TAPE-1021 | .750" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $75.81 |
| TAPE-1053 | 1.00" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 2 | $37.48 |
| TAPE-1054 | 1.00" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 2 | $140.01 |
| TAPE-1055 | 1.00" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 1 | $51.83 |
| TAPE-1056 | 1.00" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $190.41 |
| TAPE-1057 | 1.00" | .0015" | .0065" | 108' | 25 | 75 | 100 | 16,000 | 1 | $245.44 |
| TAPE-1058 | 1.00" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $99.22 |
| TAPE-1085 | 1.50" | .0015" | .0065" | 108' | 25 | 75 | 100 | 16,000 | 1 | $368.25 |
| TAPE-1124 | 2.00" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 1 | $74.85 |
| TAPE-1125 | 2.00" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 1 | $279.69 |
| TAPE-1126 | 2.00" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 1 | $103.63 |
| TAPE-1127 | 2.00" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $380.76 |
| TAPE-1128 | 2.00" | .0015" | .0065" | 108' | 25 | 75 | 100 | 16,000 | 1 | $490.92 |
| TAPE-1129 | 2.00" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $201.97 |
| TAPE-1154 | 3.00" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 1 | $112.18 |
| TAPE-1153 | 3.00" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 1 | $419.53 |
| TAPE-1156 | 3.00" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 1 | $151.75 |
| TAPE-1155 | 3.00" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $571.06 |
| TAPE-1157 | 3.00" | .0015" | .0065" | 108' | 25 | 75 | 100 | 16,000 | 1 | $736.28 |
| TAPE-1158 | 3.00" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $302.93 |
| TAPE-1182 | 4.00" | .0015" | .0035" | 15' | 25 | 30 | 100 | 10,000 | 1 | $149.55 |
| TAPE-1181 | 4.00" | .0015" | .0035" | 108' | 25 | 30 | 100 | 10,000 | 1 | $559.34 |
| TAPE-1184 | 4.00" | .0015" | .0045" | 15' | 25 | 40 | 100 | 12,000 | 1 | $209.13 |
| TAPE-1183 | 4.00" | .0015" | .0045" | 108' | 25 | 40 | 100 | 12,000 | 1 | $761.39 |
| TAPE-1185 | 4.00" | .0015" | .0115" | 15' | 25 | 68 | 100 | 21,000 | 1 | $403.89 |
