G5, G9 Glass Melamine Tubes .250" Wall
G5, G9 Glass Reinforced Melamine
(grayish
brown or white) Technical Data Sheet
This grade is composed of a continuous glass woven cloth base impregnated with a
melamine resin binder. Melamines are the hardest of all laminates, exhibiting
good dimensional stability and arc resistance. It is also caustic resistant.
Chemical
Resistance Chart
NEMA grades G5 and G9 Glass-Cloth Reinforced Melamine -- natural color is typically a grayish brown. These grades are composed of a continuous glass woven cloth base impregnated with a melamine resin binder. (Melamine resins, once cured, are the hardest, most rigid and abrasion resistant of the standard resins employed in the production of industrial laminates. However, prolonged exposure to high temperature can adversely affect its mechanical and electrical strength properties. Arc resistance, however, may remain unaffected despite excessive thermal exposure.) Melamines are the hardest of laminates, exhibiting good dimensional stability and arc resistance. It's also caustic resistant. A key difference between NEMA Grades G5 and G9 are that G9 is more resistant to the elements of the environment. Thus, G9 can be safely substituted where G5 is called for.
NEMA G-5 certs to MIL-I-24768/8 GMG ,
IEC 60893-3 Type 3 MF GC 201
NEMA G-9 certs to MIL-I-24768/1 GME, IEC 60893-3 Type 3 MF GC 201
| G5, G9 Tube Wall Thickness Options | |||
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
G5, G9 Tubes .250" Wall Thickness |
||||
| Part # | OD (in.) | ID (in.) | Minimum Purchase | Price Per Foot |
|---|---|---|---|---|
| DPT-1636 | 1.00 | .500 | 9 Feet | $91.35 |
| DPT-1645 | 1.063 | .562 | 9 Feet | $97.15 |
| DPT-1651 | 1.125 | .625 | 12 Feet | $64.38 |
| DPT-20863 | 1.187 | .687 | 9 Feet | $68.01 |
| DPT-1660 | 1.250 | .750 | 12 Feet | $71.63 |
| DPT-20859 | 1.312 | .812 | 12 Feet | $75.26 |
| DPT-1666 | 1.375 | .875 | 12 Feet | $78.86 |
| DPT-20973 | 1.437 | .937 | 12 Feet | $82.48 |
| DPT-1672 | 1.500 | 1.00 | 12 Feet | $86.10 |
| DPT-20971 | 1.562 | 1.062 | 9 Feet | $89.71 |
| DPT-20970 | 1.625 | 1.125 | 9 Feet | $93.36 |
| DPT-20969 | 1.688 | 1.187 | 9 Feet | $96.96 |
| DPT-1676 | 1.750 | 1.250 | 9 Feet | $100.61 |
| DPT-20967 | 1.812 | 1.312 | 9 Feet | $104.21 |
| DPT-20956 | 1.875 | 1.375 | 9 Feet | $107.86 |
| DPT-20965 | 1.937 | 1.437 | 9 Feet | $111.43 |
| DPT-1680 | 2.000 | 1.500 | 9 Feet | $115.10 |
| DPT-20963 | 2.062 | 1.562 | 9 Feet | $118.68 |
| DPT-20962 | 2.125 | 1.625 | 9 Feet | $122.33 |
| DPT-20961 | 2.188 | 1.687 | 9 Feet | $125.93 |
| DPT-1685 | 2.25 | 1.750 | 9 Feet | $129.58 |
| DPT-20959 | 2.312 | 1.812 | 9 Feet | $133.18 |
| DPT-20958 | 2.375 | 1.875 | 6 Feet | $136.83 |
| DPT-20983 | 2.437 | 1.937 | 6 Feet | $140.43 |
| DPT-1690 | 2.500 | 2.000 | 6 Feet | $144.08 |
| DPT-20966 | 2.562 | 2.062 | 6 Feet | $147.66 |
| DPT-20992 | 2.625 | 2.125 | 6 Feet | $151.33 |
| DPT-20991 | 2.688 | 2.187 | 6 Feet | $154.91 |
| DPT-1695 | 2.750 | 2.250 | 6 Feet | $158.56 |
| DPT-20989 | 2.812 | 2.312 | 6 Feet | $162.16 |
| DPT-20988 | 2.875 | 2.375 | 6 Feet | $165.81 |
| DPT-20987 | 2.937 | 2.437 | 6 Feet | $169.41 |
| DPT-1700 | 3.000 | 2.500 | 6 Feet | $173.06 |
| DPT-20975 | 3.062 | 2.562 | 6 Feet | $176.66 |
| DPT-20984 | 3.125 | 2.625 | 6 Feet | $180.31 |
| DPT-20993 | 3.188 | 2.687 | 6 Feet | $183.91 |
| DPT-1705 | 3.250 | 2.750 | 6 Feet | $187.56 |
| DPT-20981 | 3.312 | 2.812 | 6 Feet | $191.13 |
| DPT-20980 | 3.375 | 2.875 | 6 Feet | $194.78 |
| DPT-20979 | 3.437 | 2.937 | 6 Feet | $198.38 |
| DPT-1710 | 3.500 | 3.000 | 6 Feet | $202.03 |
| DPT-20977 | 3.562 | 3.062 | 6 Feet | $205.63 |
| DPT-20976 | 3.625 | 3.125 | 6 Feet | $209.28 |
| DPT-20947 | 3.687 | 3.187 | 6 Feet | $212.88 |
| DPT-1715 | 3.750 | 3.250 | 6 Feet | $216.53 |
| DPT-20957 | 3.812 | 3.312 | 6 Feet | $220.13 |
| DPT-20934 | 3.875 | 3.375 | 6 Feet | $223.78 |
| DPT-20933 | 3.937 | 3.437 | 6 Feet | $227.36 |
| DPT-1720 | 4.00 | 3.50 | 6 Feet | $231.01 |
| DPT-20931 | 4.062 | 3.562 | 6 Feet | $234.61 |
| DPT-20930 | 4.125 | 3.625 | 6 Feet | $238.26 |
| DPT-20929 | 4.187 | 3.687 | 6 Feet | $241.86 |
| DPT-20918 | 4.250 | 3.750 | 6 Feet | $245.51 |
| DPT-20927 | 4.312 | 3.812 | 6 Feet | $249.11 |
| DPT-20936 | 4.375 | 3.875 | 6 Feet | $252.76 |
| DPT-20925 | 4.437 | 3.937 | 6 Feet | $256.36 |
| DPT-1731 | 4.500 | 4.000 | 6 Feet | $260.01 |
| DPT-20923 | 4.562 | 4.062 | 6 Feet | $263.58 |
| DPT-20922 | 4.625 | 4.125 | 3 Feet | $267.23 |
| DPT-20921 | 4.687 | 4.187 | 3 Feet | $270.83 |
| DPT-20920 | 4.750 | 4.250 | 3 Feet | $274.48 |
| DPT-20945 | 4.812 | 4.312 | 3 Feet | $278.08 |
| DPT-20926 | 4.875 | 4.438 | 3 Feet | $281.73 |
| DPT-20928 | 4.937 | 4.500 | 3 Feet | $285.33 |
| DPT-1736 | 5.000 | 4.500 | 3 Feet | $288.98 |
| DPT-20953 | 5.062 | 4.562 | 3 Feet | $292.58 |
| DPT-20952 | 5.125 | 4.625 | 3 Feet | $296.23 |
| DPT-20951 | 5.187 | 4.687 | 3 Feet | $299.81 |
| DPT-20950 | 5.250 | 4.750 | 3 Feet | $303.48 |
| DPT-20949 | 5.312 | 4.812 | 3 Feet | $307.06 |
| DPT-20948 | 5.375 | 4.875 | 3 Feet | $348.18 |
| DPT-20937 | 5.437 | 4.937 | 3 Feet | $352.21 |
| DPT-1741 | 5.500 | 5.000 | 3 Feet | $356.31 |
| DPT-20955 | 5.562 | 5.062 | 3 Feet | $360.33 |
| DPT-20944 | 5.625 | 5.125 | 3 Feet | $364.43 |
| DPT-20943 | 5.688 | 5.187 | 3 Feet | $368.46 |
| DPT-20942 | 5.750 | 5.250 | 3 Feet | $372.56 |
| DPT-20941 | 5.812 | 5.313 | 3 Feet | $376.58 |
| DPT-20940 | 5.875 | 5.375 | 3 Feet | $380.66 |
| DPT-20939 | 5.938 | 5.437 | 3 Feet | $384.68 |
| DPT-1747 | 6.000 | 5.500 | 3 Feet | $388.78 |
| DPT-20710 | 6.125 | 5.625 | 3 Feet | $396.91 |
| DPT-20862 | 6.187 | 5.687 | 3 Feet | $400.93 |
| DPT-20744 | 6.250 | 5.750 | 3 Feet | $405.03 |
| DPT-20743 | 6.312 | 5.812 | 3 Feet | $409.06 |
| DPT-20742 | 6.375 | 5.875 | 3 Feet | $413.13 |
| DPT-20741 | 6.437 | 5.937 | 3 Feet | $417.16 |
| DPT-1753 | 6.500 | 6.00 | 3 Feet | $421.26 |
| DPT-21270 | 6.562 | 6.062 | 3 Feet | $388.85 |
| DPT-20739 | 6.625 | 6.125 | 3 Feet | $392.73 |
| DPT-20728 | 6.688 | 6.187 | 3 Feet | $396.56 |
| DPT-20737 | 6.750 | 6.250 | 3 Feet | $400.43 |
| DPT-20746 | 6.812 | 6.312 | 3 Feet | $404.25 |
| DPT-20735 | 6.875 | 6.375 | 3 Feet | $408.13 |
| DPT-20734 | 6.938 | 6.437 | 3 Feet | $411.96 |
| DPT-20733 | 7.000 | 6.500 | 3 Feet | $415.83 |
| DPT-20833 | 6.063 | 6.562 | 3 Feet | $392.81 |
| DPT-20732 | 7.062 | 6.562 | 3 Feet | $419.66 |
| DPT-20731 | 7.125 | 6.625 | 3 Feet | $423.53 |
| DPT-20730 | 7.187 | 6.687 | 3 Feet | $427.35 |
| DPT-20755 | 7.250 | 6.750 | 3 Feet | $431.23 |
| DPT-20736 | 7.312 | 6.812 | 3 Feet | $435.06 |
| DPT-20738 | 7.375 | 6.875 | 3 Feet | $438.93 |
| DPT-20764 | 7.437 | 6.938 | 3 Feet | $442.73 |
| DPT-20763 | 7.500 | 7.000 | 3 Feet | $446.63 |
| DPT-20762 | 7.562 | 7.062 | 3 Feet | $450.43 |
| DPT-20761 | 7.625 | 7.125 | 3 Feet | $454.33 |
| DPT-20760 | 7.688 | 7.187 | 3 Feet | $458.13 |
| DPT-20759 | 7.750 | 7.250 | 3 Feet | $462.03 |
| DPT-20758 | 7.812 | 7.312 | 3 Feet | $465.83 |
| DPT-20747 | 7.875 | 7.375 | 3 Feet | $469.73 |
| DPT-20756 | 7.938 | 7.437 | 3 Feet | $473.53 |
| DPT-20765 | 8.000 | 7.500 | 3 Feet | $477.43 |
| DPT-20754 | 8.062 | 7.562 | 3 Feet | $481.23 |
| DPT-20753 | 8.125 | 7.625 | 3 Feet | $485.10 |
| DPT-20752 | 8.188 | 7.687 | 3 Feet | $488.93 |
| DPT-20751 | 8.250 | 7.750 | 3 Feet | $492.81 |
| DPT-20750 | 8.312 | 7.812 | 3 Feet | $496.63 |
| DPT-20749 | 8.375 | 7.875 | 3 Feet | $500.50 |
| DPT-20748 | 8.437 | 7.937 | 3 Feet | $504.33 |
| DPT-20719 | 8.500 | 8.000 | 3 Feet | $508.21 |
| DPT-20729 | 8.625 | 8.125 | 3 Feet | $515.91 |
| DPT-20706 | 8.688 | 8.187 | 3 Feet | $519.73 |
| DPT-20705 | 8.750 | 8.250 | 3 Feet | $523.61 |
| DPT-20704 | 8.812 | 8.312 | 3 Feet | $527.43 |
| DPT-20703 | 8.875 | 8.375 | 3 Feet | $531.31 |
| DPT-20702 | 8.938 | 8.437 | 3 Feet | $535.13 |
| DPT-20701 | 9.000 | 8.500 | 3 Feet | $539.01 |
| DPT-20690 | 9.062 | 8.562 | 3 Feet | $542.83 |
| DPT-20699 | 9.125 | 8.625 | 3 Feet | $546.71 |
| DPT-20708 | 9.188 | 8.687 | 3 Feet | $550.53 |
| DPT-20697 | 9.250 | 8.750 | 3 Feet | $554.41 |
| DPT-21180 | 9.312 | 8.812 | 3 Feet | $558.23 |
| DPT-21179 | 9.375 | 8.875 | 3 Feet | $562.11 |
| DPT-21178 | 9.437 | 8.937 | 3 Feet | $565.93 |
| DPT-21177 | 9.500 | 9.000 | 3 Feet | $569.81 |
| DPT-21176 | 9.563 | 9.062 | 3 Feet | $573.63 |
| DPT-21165 | 9.625 | 9.125 | 3 Feet | $577.51 |
| DPT-21174 | 9.688 | 9.187 | 3 Feet | $581.33 |
| DPT-21183 | 9.750 | 9.250 | 3 Feet | $585.21 |
| DPT-21172 | 9.812 | 9.312 | 3 Feet | $589.03 |
| DPT-21171 | 9.875 | 9.375 | 3 Feet | $592.91 |
| DPT-21170 | 9.937 | 9.437 | 3 Feet | $596.73 |
| DPT-21169 | 10.000 | 9.500 | 3 Feet | $600.61 |
| DPT-21168 | 10.062 | 9.562 | 3 Feet | $604.43 |
| DPT-21167 | 10.125 | 9.625 | 3 Feet | $608.31 |
| DPT-21166 | 10.187 | 9.687 | 3 Feet | $612.13 |
| DPT-21223 | 10.250 | 9.750 | 3 Feet | $616.01 |
| DPT-21280 | 10.313 | 9.813 | 3 Feet | $619.83 |
| DPT-21213 | 10.375 | 9.875 | 3 Feet | $623.71 |
| DPT-21276 | 10.437 | 9.937 | 3 Feet | $627.53 |
| DPT-21275 | 10.500 | 10.000 | 3 Feet | $631.41 |
| DPT-21274 | 10.563 | 10.062 | 3 Feet | $635.21 |
| DPT-21273 | 10.625 | 10.125 | 3 Feet | $639.11 |
| DPT-21272 | 10.688 | 10.187 | 3 Feet | $642.91 |
| DPT-21271 | 10.750 | 10.250 | 3 Feet | $646.81 |
| DPT-21260 | 10.813 | 10.312 | 3 Feet | $650.61 |
| DPT-21269 | 10.875 | 10.375 | 3 Feet | $654.51 |
| DPT-21278 | 10.937 | 10.437 | 3 Feet | $658.31 |
| DPT-20696 | 11.00 | 10.500 | 3 Feet | $662.21 |
| DPT-20695 | 11.062 | 10.562 | 3 Feet | $666.01 |
| DPT-20694 | 11.125 | 10.625 | 3 Feet | $669.91 |
| DPT-20693 | 11.188 | 10.687 | 3 Feet | $673.71 |
| DPT-20692 | 11.250 | 10.750 | 3 Feet | $677.61 |
| DPT-20717 | 11.313 | 10.812 | 3 Feet | $681.41 |
| DPT-20698 | 11.375 | 10.875 | 3 Feet | $685.28 |
| DPT-20700 | 11.437 | 10.937 | 3 Feet | $689.11 |
| DPT-20726 | 11.500 | 11.000 | 3 Feet | $692.98 |
| DPT-20725 | 11.562 | 11.062 | 3 Feet | $696.81 |
| DPT-20724 | 11.625 | 11.125 | 3 Feet | $700.68 |
| DPT-20723 | 11.687 | 11.187 | 3 Feet | $704.51 |
| DPT-20722 | 11.750 | 11.250 | 3 Feet | $708.38 |
| DPT-20721 | 11.812 | 11.312 | 3 Feet | $712.21 |
| DPT-20720 | 11.875 | 11.375 | 3 Feet | $716.08 |
| DPT-20709 | 11.937 | 11.437 | 3 Feet | $719.91 |
| DPT-20718 | 12.000 | 11.500 | 3 Feet | $723.78 |
| DPT-20727 | 12.062 | 11.562 | 3 Feet | $727.61 |
| DPT-20716 | 12.125 | 11.625 | 3 Feet | $731.48 |
| DPT-20715 | 12.187 | 11.687 | 3 Feet | $735.31 |
| DPT-20714 | 12.250 | 11.750 | 3 Feet | $739.18 |
| DPT-20713 | 12.313 | 11.812 | 3 Feet | $743.01 |
| DPT-20712 | 12.375 | 11.875 | 3 Feet | $746.88 |
| DPT-20711 | 12.437 | 11.937 | 3 Feet | $750.71 |
| DPT-20783 | 12.500 | 12.000 | 3 Feet | $754.58 |
| DPT-20707 | 12.562 | 12.062 | 3 Feet | $758.41 |
| DPT-20757 | 12.625 | 12.125 | 3 Feet | $762.28 |
| DPT-20821 | 12.687 | 12.187 | 3 Feet | $766.11 |
| DPT-20820 | 12.750 | 12.250 | 3 Feet | $769.98 |
| DPT-20819 | 12.812 | 12.312 | 3 Feet | $773.81 |
| DPT-20818 | 12.875 | 12.375 | 3 Feet | $777.68 |
| DPT-20817 | 12.937 | 12.437 | 3 Feet | $781.51 |
| DPT-20816 | 13.000 | 12.500 | 3 Feet | $785.38 |
| DPT-20815 | 13.062 | 12.562 | 3 Feet | $789.21 |
| DPT-20804 | 13.125 | 12.625 | 3 Feet | $793.08 |
| DPT-20813 | 13.187 | 12.687 | 3 Feet | $796.91 |
| DPT-20822 | 13.250 | 12.750 | 3 Feet | $800.78 |
| DPT-20811 | 13.312 | 12.813 | 3 Feet | $804.61 |
| DPT-20810 | 13.375 | 12.875 | 3 Feet | $808.48 |
| DPT-20809 | 13.437 | 12.937 | 3 Feet | $812.31 |
| DPT-20808 | 13.500 | 13.000 | 3 Feet | $816.18 |
| DPT-20807 | 13.562 | 13.062 | 3 Feet | $820.01 |
| DPT-20806 | 13.625 | 13.125 | 3 Feet | $823.88 |
| DPT-20831 | 13.687 | 13.187 | 3 Feet | $827.71 |
| DPT-20812 | 13.750 | 13.250 | 3 Feet | $831.58 |
| DPT-20814 | 13.812 | 13.312 | 3 Feet | $835.38 |
| DPT-20840 | 13.875 | 13.375 | 3 Feet | $839.28 |
| DPT-20839 | 13.937 | 13.437 | 3 Feet | $843.08 |
| DPT-20838 | 14.000 | 13.500 | 3 Feet | $846.98 |
| DPT-20837 | 14.062 | 13.562 | 3 Feet | $850.78 |
| DPT-20836 | 14.125 | 13.625 | 3 Feet | $854.68 |
| DPT-21296 | 14.187 | 13.687 | 3 Feet | $858.48 |
| DPT-20835 | 14.250 | 13.750 | 3 Feet | $862.38 |
| DPT-21289 | 14.312 | 13.812 | 3 Feet | $866.18 |
| DPT-20834 | 14.375 | 13.875 | 3 Feet | $870.08 |
| DPT-20823 | 14.437 | 13.937 | 3 Feet | $873.88 |
| DPT-20832 | 14.500 | 14.000 | 3 Feet | $877.76 |
| DPT-20841 | 14.562 | 14.062 | 3 Feet | $881.58 |
| DPT-20830 | 14.625 | 14.125 | 3 Feet | $885.46 |
| DPT-20829 | 14.687 | 14.187 | 3 Feet | $889.28 |
| DPT-20828 | 14.750 | 14.250 | 3 Feet | $893.16 |
| DPT-20827 | 14.812 | 14.312 | 3 Feet | $896.98 |
| DPT-20826 | 14.875 | 14.375 | 3 Feet | $900.86 |
| DPT-20825 | 14.937 | 14.437 | 3 Feet | $904.68 |
| DPT-20824 | 15.000 | 14.500 | 3 Feet | $908.56 |
| DPT-20795 | 15.062 | 14.562 | 3 Feet | $912.38 |
| DPT-20767 | 15.125 | 14.625 | 3 Feet | $916.26 |
| DPT-20805 | 15.187 | 14.687 | 3 Feet | $920.08 |
| DPT-20782 | 15.250 | 14.750 | 3 Feet | $923.96 |
| DPT-20781 | 15.312 | 14.812 | 3 Feet | $927.78 |
| DPT-20780 | 15.375 | 14.875 | 3 Feet | $931.66 |
| DPT-20779 | 15.437 | 14.937 | 3 Feet | $935.48 |
| DPT-20778 | 15.500 | 15.000 | 3 Feet | $939.36 |
| DPT-20777 | 15.562 | 15.062 | 3 Feet | $943.18 |
| DPT-20766 | 15.625 | 15.125 | 3 Feet | $947.06 |
| DPT-20775 | 15.687 | 15.187 | 3 Feet | $950.88 |
| DPT-20784 | 15.750 | 15.250 | 3 Feet | $954.76 |
| DPT-20773 | 15.812 | 15.312 | 3 Feet | $958.58 |
| DPT-20772 | 15.875 | 15.375 | 3 Feet | $962.46 |
| DPT-20771 | 15.937 | 15.437 | 3 Feet | $966.28 |
| DPT-20770 | 16.000 | 15.500 | 3 Feet | $970.16 |
| DPT-20769 | 16.062 | 15.562 | 3 Feet | $973.98 |
| DPT-20768 | 16.125 | 15.625 | 3 Feet | $977.86 |
| DPT-20793 | 16.187 | 15.687 | 3 Feet | $981.68 |
| DPT-20774 | 16.250 | 15.750 | 3 Feet | $985.56 |
| DPT-20776 | 16.312 | 15.812 | 3 Feet | $989.38 |
| DPT-20802 | 16.375 | 15.875 | 3 Feet | $993.26 |
| DPT-20801 | 16.437 | 15.937 | 3 Feet | $997.08 |
| DPT-20800 | 16.500 | 16.000 | 3 Feet | $1,000.96 |
| DPT-20799 | 16.562 | 16.062 | 3 Feet | $1,004.78 |
| DPT-20798 | 16.625 | 16.125 | 3 Feet | $1,008.66 |
| DPT-20797 | 16.687 | 16.187 | 3 Feet | $1,012.48 |
| DPT-20796 | 16.750 | 16.250 | 3 Feet | $1,016.36 |
| DPT-20785 | 16.812 | 16.312 | 3 Feet | $1,020.18 |
| DPT-20794 | 16.875 | 16.375 | 3 Feet | $1,024.05 |
| DPT-20803 | 16.937 | 16.437 | 3 Feet | $1,027.86 |
| DPT-20792 | 17.000 | 16.500 | 3 Feet | $1,031.75 |
| DPT-20791 | 17.062 | 16.562 | 3 Feet | $1,035.55 |
| DPT-20790 | 17.125 | 16.625 | 3 Feet | $1,039.46 |
| DPT-20789 | 17.187 | 16.687 | 3 Feet | $1,043.25 |
| DPT-20788 | 17.250 | 16.750 | 3 Feet | $1,047.16 |
| DPT-20787 | 17.312 | 16.812 | 3 Feet | $1,050.96 |
| DPT-20786 | 17.375 | 16.875 | 3 Feet | $1,054.86 |
| DPT-21014 | 17.437 | 16.937 | 3 Feet | $1,058.66 |
| DPT-21242 | 17.500 | 17.000 | 3 Feet | $1,062.55 |
| DPT-20985 | 17.562 | 17.062 | 3 Feet | $1,066.36 |
| DPT-21200 | 17.625 | 17.125 | 3 Feet | $1,070.23 |
| DPT-21199 | 17.687 | 17.187 | 3 Feet | $1,074.05 |
| DPT-21198 | 17.750 | 17.250 | 3 Feet | $1,077.93 |
| DPT-21197 | 17.812 | 17.312 | 3 Feet | $1,081.75 |
| DPT-21196 | 17.875 | 17.375 | 3 Feet | $1,085.63 |
| DPT-21195 | 17.937 | 17.437 | 3 Feet | $1,089.46 |
| DPT-21184 | 18.000 | 17.500 | 3 Feet | $1,093.33 |
| DPT-21193 | 18.062 | 17.562 | 3 Feet | $1,097.16 |
| DPT-21202 | 18.125 | 17.625 | 3 Feet | $1,101.03 |
| DPT-21191 | 18.187 | 17.687 | 3 Feet | $1,104.86 |
| DPT-21190 | 18.250 | 17.750 | 3 Feet | $1,108.73 |
| DPT-21189 | 18.312 | 17.812 | 3 Feet | $1,112.55 |
| DPT-21188 | 18.375 | 17.875 | 3 Feet | $1,116.43 |
| DPT-21187 | 18.437 | 17.937 | 3 Feet | $1,120.25 |
| DPT-21186 | 18.500 | 18.000 | 3 Feet | $1,124.13 |
| DPT-21211 | 18.562 | 18.062 | 3 Feet | $1,127.96 |
| DPT-21192 | 18.625 | 18.125 | 3 Feet | $1,131.83 |
| DPT-21194 | 18.687 | 18.187 | 3 Feet | $1,135.66 |
| DPT-21220 | 18.750 | 18.250 | 3 Feet | $1,139.53 |
| DPT-21219 | 18.812 | 18.312 | 3 Feet | $1,143.36 |
| DPT-21218 | 18.875 | 18.375 | 3 Feet | $1,147.23 |
| DPT-21217 | 18.937 | 18.437 | 3 Feet | $1,151.05 |
| DPT-21216 | 19.000 | 18.500 | 3 Feet | $1,154.93 |
| DPT-21215 | 19.062 | 18.563 | 3 Feet | $1,158.76 |
| DPT-21214 | 19.125 | 18.625 | 3 Feet | $1,162.63 |
| DPT-21203 | 19.187 | 19.687 | 3 Feet | $1,166.46 |
| DPT-21212 | 19.250 | 18.750 | 3 Feet | $1,170.33 |
| DPT-21221 | 19.312 | 18.812 | 3 Feet | $1,174.16 |
| DPT-21210 | 19.375 | 18.937 | 3 Feet | $1,178.03 |
| DPT-21209 | 19.437 | 18.937 | 3 Feet | $1,181.85 |
| DPT-21208 | 19.500 | 19.000 | 3 Feet | $1,185.73 |
| DPT-21267 | 19.562 | 19.062 | 3 Feet | $1,189.56 |
| DPT-21266 | 19.625 | 19.125 | 3 Feet | $1,193.43 |
| DPT-21265 | 19.687 | 19.187 | 3 Feet | $1,197.25 |
| DPT-21264 | 19.750 | 19.250 | 3 Feet | $1,201.13 |
| DPT-21263 | 19.812 | 19.312 | 3 Feet | $1,204.96 |
| DPT-21262 | 19.875 | 19.375 | 3 Feet | $1,208.83 |
| DPT-21261 | 19.937 | 19.437 | 3 Feet | $1,212.65 |
| DPT-21287 | 20.000 | 19.500 | 3 | $1,216.53 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
