G10 FR4 Tubes Glass Filled  .125" Wall

(Micarta) (High Pressure Laminates) G10 FR4 Glass Reinforced Epoxy - natural (yellowish to light green) Technical Data Sheet    Chemical Resistance Chart
The most versatile all-around laminate and composite, this grade is a continuous glass woven fabric base impregnated with an epoxy resin binder. It has extremely high mechanical strength, good dielectric loss properties, and good electric strength properties, both wet and dry.
NEMA G-10 certs to MIL-I-24768/2 GEE, IPC 4101/20, IEC 60893-3 Type 2 EP GC 201
NEMA FR-4 certs to MIL-I-24768/27 GEE-F, IPC 4101/21, IEC 60893-3 Type 2 EP GC 202

.031" (1/32") Wall Thickness	.062" (1/16")Wall Thickness	.093" (3/32")Wall Thickness	.125" (1/8")Wall Thickness	.187" (3/16")Wall Thickness
.250" (1/4")Wall Thickness	.375" (3/8")Wall Thickness	.500" (1/2")Wall Thickness	.750" (3/4")WallThickness	1.00" Wall Thickness (Max. Possible)

**Minimum's and Lead Times Apply on Special Order Non Stocked Item

Tolerances (Note: Pricing for Over 4.00" Diameter Wound Only)

Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts  42-48"

G10 FR4 Tubes .125" Wall Thickness

Part #	Outside Diameter (in.)	Inside Diameter (in.)	Price Per Foot	Minimum Purchase
DPT-1336	0.437	0.188	$35.86	24 Feet
DPT-1340	0.500	0.250	$38.96	21 Feet
DPT-1344	0.562	0.312	$42.08	21 Feet
DPT-1348	0.625	0.375	$45.18	18 Feet
DPT-1352	0.687	0.437	$48.30	18 Feet
DPT-1356	0.750	0.500	$51.41	18 Feet
DPT-1361	0.812	0.562	$54.50	15 Feet
DPT-1367	0.875	0.625	$37.68	24 Feet
DPT-1372	0.937	0.687	$39.71	21 Feet
DPT-1376	1.000	0.750	$41.76	21 Feet
DPT-6169	1.031	0.781	$42.75	21 Feet
DPT-5826	1.062	0.812	$43.78	21 Feet
DPT-6170	1.094	0.843	$44.78	18 Feet
DPT-1385	1.125	0.875	$45.80	18 Feet
DPT-6171	1.156	0.906	$46.83	18 Feet
DPT-6172	1.187	0.937	$47.83	18 Feet
DPT-1391	1.250	1.000	$49.88	18 Feet
DPT-6173	1.312	1.062	$51.88	18 Feet
DPT-6174	1.375	1.125	$53.93	15 Feet
DPT-6175	1.437	1.187	$55.96	15 Feet
DPT-1395	1.500	1.250	$58.01	15 Feet
DPT-6176	1.562	1.312	$60.00	15 Feet
DPT-4794	1.625	1.375	$62.05	15 Feet
DPT-6177	1.687	1.437	$64.08	15 Feet
DPT-1400	1.750	1.500	$66.13	12 Feet
DPT-6179	1.812	1.687	$68.16	12 Feet
DPT-6180	1.937	1.781	$72.21	12 Feet
DPT-1405	2.000	1.750	$74.26	12 Feet
DPT-6181	2.031	1.812	$76.28	12 Feet
DPT-6182	2.062	1.842	$77.26	12 Feet
DPT-6183	2.094	1.875	$78.33	12 Feet
DPT-6184	2.156	1.906	$79.33	12 Feet
DPT-6185	2.187	1.937	$80.33	12 Feet
DPT-6186	2.250	2.000	$82.38	9 Feet
DPT-6187	2.312	2.062	$84.40	9 Feet
DPT-6188	2.375	2.125	$86.46	9 Feet
DPT-6189	2.437	2.187	$88.46	9 Feet
DPT-1415	2.500	2.250	$90.51	9 Feet
DPT-6190	2.562	2.312	$92.53	9 Feet
DPT-6191	2.625	2.375	$94.58	9 Feet
DPT-6192	2.687	2.437	$96.58	9 Feet
DPT-1420	2.750	2.500	$98.63	9 Feet
DPT-6193	2.812	2.562	$100.65	9 Feet
DPT-1425	3.000	2.750	$106.76	9 Feet
DPT-6195	3.031	2.781	$107.78	9 Feet
DPT-6196	3.062	2.812	$108.78	9 Feet
DPT-6197	3.094	2.843	$109.78	9 Feet
DPT-6198	3.125	2.875	$110.83	9 Feet
DPT-6199	3.156	2.906	$111.83	9 Feet
DPT-6200	3.187	2.937	$112.86	9 Feet
DPT-1430	3.250	3.000	$114.91	6 Feet
DPT-6201	3.312	3.062	$116.90	6 Feet
DPT-1435	3.500	3.250	$123.03	6 Feet
DPT-6204	3.562	3.312	$125.03	6 Feet
DPT-6205	3.625	3.375	$127.08	6 Feet
DPT-6206	3.687	3.437	$129.11	6 Feet
DPT-1440	3.750	3.500	$131.16	6 Feet
DPT-6207	3.812	3.562	$133.16	6 Feet
DPT-6208	3.937	3.687	$137.23	6 Feet
DPT-1445	4.000	3.750	$139.28	6 Feet
DPT-6209	4.031	3.781	$140.28	6 Feet
DPT-6210	4.062	3.812	$141.28	6 Feet
DPT-6211	4.094	3.843	$142.31	6 Feet
DPT-6212	4.125	3.875	$143.33	6 Feet
DPT-6213	4.156	3.906	$144.36	6 Feet
DPT-6214	4.187	3.937	$145.36	6 Feet
DPT-1450	4.250	4.000	$147.41	6 Feet
DPT-6215	4.312	4.062	$149.43	6 Feet
DPT-6216	4.375	4.125	$151.48	6 Feet
DPT-6217	4.437	4.187	$153.48	6 Feet
DPT-6218	4.500	4.250	$155.53	6 Feet
DPT-6219	4.562	4.312	$157.56	6 Feet
DPT-6220	4.625	4.375	$159.61	6 Feet
DPT-6221	4.687	4.437	$161.61	6 Feet
DPT-1455	4.750	4.500	$163.66	6 Feet
DPT-6222	4.812	4.562	$165.68	6 Feet
DPT-6223	4.937	4.687	$169.73	6 Feet
DPT-1146Q	5.000	4.750	$171.78	6 Feet
DPT-6224	5.031	4.781	$172.81	6 Feet
DPT-6225	5.062	4.812	$173.81	6 Feet
DPT-6226	5.094	4.842	$174.78	6 Feet
DPT-6227	5.125	4.875	$193.56	6 Feet
DPT-6228	5.156	4.906	$194.66	6 Feet
DPT-6229	5.187	4.937	$195.78	6 Feet
DPT-1460	5.250	5.000	$198.03	6 Feet
DPT-6230	5.312	5.062	$200.26	6 Feet
DPT-6231	5.375	5.125	$202.51	6 Feet
DPT-6232	5.437	5.187	$204.73	6 Feet
DPT-6233	5.500	5.250	$206.98	6 Feet
DPT-6234	5.562	5.312	$209.21	6 Feet
DPT-5023	5.625	5.375	$211.46	6 Feet
DPT-6235	5.687	5.437	$213.68	6 Feet
DPT-1466	5.750	5.500	$215.93	6 Feet
DPT-6236	5.812	5.562	$218.16	6 Feet
DPT-6237	5.937	5.687	$222.61	6 Feet
DPT-5827	6.000	5.750	$224.88	6 Feet
DPT-6238	6.031	5.781	$225.98	6 Feet
DPT-6239	6.062	5.812	$255.14	6 Feet
DPT-6240	6.094	5.843	$228.21	6 Feet
DPT-6241	6.125	5.875	$229.36	6 Feet
DPT-6242	6.156	5.906	$230.46	6 Feet
DPT-6243	6.187	5.937	$231.56	6 Feet
DPT-1472	6.250	6.000	$233.81	6 Feet
DPT-6244	6.312	6.062	$219.66	6 Feet
DPT-6245	6.375	6.125	$221.88	3 Feet
DPT-6246	6.437	6.187	$224.08	3 Feet
DPT-6287	6.500	6.250	$226.33	3 Feet
DPT-6288	6.562	6.312	$228.53	3 Feet
DPT-6289	6.625	6.375	$230.76	3 Feet
DPT-6290	6.687	6.437	$232.96	3 Feet
DPT-6291	6.750	6.500	$235.21	3 Feet
DPT-6292	6.812	6.562	$237.41	3 Feet
DPT-6247	6.937	6.687	$241.83	3 Feet
DPT-6247W	7.000	6.750	$244.08	3 Feet
DPT-6248	7.031	6.781	$245.18	3 Feet
DPT-6249	7.062	6.812	$246.28	3 Feet
DPT-6250	7.094	6.843	$247.38	3 Feet
DPT-6251	7.125	6.875	$248.51	3 Feet
DPT-6252	7.156	6.906	$249.61	3 Feet
DPT-6253	7.187	6.937	$250.71	3 Feet
DPT-6254	7.250	7.000	$252.96	3 Feet
DPT-6255	7.312	7.062	$255.16	3 Feet
DPT-6256	7.375	7.125	$257.38	3 Feet
DPT-6257	7.437	7.187	$259.58	3 Feet
DPT-6258	7.500	7.250	$261.81	3 Feet
DPT-6259	7.562	7.312	$264.00	3 Feet
DPT-6260	7.625	7.375	$266.26	3 Feet
DPT-6261	7.687	7.437	$268.46	3 Feet
DPT-5639	7.750	7.500	$270.68	3 Feet
DPT-6262	7.812	7.562	$272.88	3 Feet
DPT-6263	7.937	7.687	$277.33	3 Feet
DPT-6264	8.000	7.750	$279.56	3 Feet
DPT-6265	8.031	7.781	$280.66	3 Feet
DPT-6266	8.062	7.812	$281.76	3 Feet
DPT-6267	8.094	7.843	$282.85	3 Feet
DPT-6268	8.125	7.875	$284.00	3 Feet
DPT-6269	8.156	7.906	$285.11	3 Feet
DPT-6270	8.187	7.937	$286.21	3 Feet
DPT-5270	8.250	8.000	$288.43	3 Feet
DPT-6272	8.375	8.125	$292.88	3 Feet
DPT-6273	8.437	8.187	$295.08	3 Feet
DPT-6274	8.500	8.250	$297.31	3 Feet
DPT-6275	8.562	8.312	$299.51	3 Feet
DPT-6276	8.625	8.375	$301.76	3 Feet
DPT-6277	8.687	8.437	$303.96	3 Feet
DPT-6278	8.750	8.500	$306.18	3 Feet
DPT-6279	8.812	8.562	$308.38	3 Feet
DPT-6280	8.937	8.687	$312.81	3 Feet
DPT-6281	9.000	8.750	$315.05	3 Feet
DPT-6282	9.031	8.781	$316.16	3 Feet
DPT-6283	9.062	8.812	$317.26	3 Feet
DPT-6284	9.094	8.843	$318.35	3 Feet
DPT-6285	9.125	8.875	$319.48	3 Feet
DPT-6286	9.156	8.906	$320.58	3 Feet
DPT-6293	9.187	8.937	$321.68	3 Feet
DPT-6294	9.250	9.000	$323.93	3 Feet
DPT-6295	9.312	9.062	$326.13	3 Feet
DPT-6296	9.375	9.062	$328.35	3 Feet
DPT-6297	9.437	9.187	$330.56	3 Feet
DPT-6298	9.500	9.250	$332.81	3 Feet
DPT-6299	9.562	9.312	$335.01	3 Feet
DPT-6300	9.625	9.375	$337.23	3 Feet
DPT-6301	9.687	9.437	$339.43	3 Feet
DPT-6302	9.750	9.500	$341.68	3 Feet
DPT-6303	9.812	9.562	$343.88	3 Feet
DPT-6304	9.937	9.687	$348.30	3 Feet
DPT-9488Q	10.000	9.750	$350.53	3 Feet
DPT-6305	10.031	9.781	$351.63	3 Feet
DPT-6306	10.062	9.812	$352.73	3 Feet
DPT-6307	10.094	9.842	$353.81	3 Feet
DPT-6308	10.125	9.875	$354.98	3 Feet
DPT-6309	10.156	9.906	$356.08	3 Feet
DPT-6310	10.187	9.937	$357.18	3 Feet
DPT-6311	10.250	10.000	$359.41	3 Feet
DPT-6312	10.312	10.062	$361.61	3 Feet
DPT-6313	10.375	10.125	$363.85	3 Feet
DPT-6314	10.437	10.187	$366.05	3 Feet
DPT-6315	10.500	10.250	$368.28	3 Feet
DPT-6316	10.562	10.312	$370.48	3 Feet
DPT-6317	10.625	10.370	$372.73	3 Feet
DPT-6318	10.687	10.437	$374.93	3 Feet
DPT-6319	10.750	10.500	$377.16	3 Feet
DPT-6320	10.812	10.562	$379.36	3 Feet
DPT-6321	10.937	10.687	$383.81	3 Feet
DPT-6322	11.000	10.750	$386.03	3 Feet
DPT-6323	11.031	10.781	$387.13	3 Feet
DPT-6324	11.062	10.812	$388.23	3 Feet
DPT-6325	11.094	10.843	$389.33	3 Feet
DPT-6326	11.125	10.875	$390.46	3 Feet
DPT-6327	11.156	10.906	$391.56	3 Feet
DPT-6328	11.187	10.937	$392.66	3 Feet
DPT-6329	11.250	11.000	$394.91	3 Feet
DPT-6330	11.312	11.062	$397.10	3 Feet
DPT-6331	11.375	11.125	$399.33	3 Feet
DPT-6332	11.437	11.187	$401.53	3 Feet
DPT-6333	11.500	11.250	$403.78	3 Feet
DPT-6334	11.562	11.312	$405.98	3 Feet
DPT-6335	11.625	11.375	$408.21	3 Feet
DPT-6336	11.687	11.437	$410.41	3 Feet
DPT-6337	11.750	11.500	$412.66	3 Feet
DPT-6338	11.812	11.562	$414.85	3 Feet
DPT-6339	11.937	11.687	$419.28	3 Feet
DPT-418PW	12.000	11.750	$421.53	3 Feet
DPT-6340	12.031	11.781	$422.63	3 Feet
DPT-6341	12.062	11.812	$423.73	3 Feet
DPT-6342	12.094	11.843	$424.83	3 Feet
DPT-6343	12.125	11.875	$425.96	3 Feet
DPT-6344	12.156	11.906	$427.05	3 Feet
DPT-6345	12.187	11.937	$428.16	3 Feet
DPT-6346	12.250	12.000	$430.41	3 Feet
DPT-6347	12.312	12.062	$432.60	3 Feet
DPT-6348	12.375	12.125	$434.83	3 Feet
DPT-6349	12.437	12.187	$437.03	3 Feet
DPT-6350	12.500	12.250	$439.25	3 Feet
DPT-6351	12.562	12.312	$441.46	3 Feet
DPT-6352	12.625	12.375	$443.71	3 Feet
DPT-6353	12.687	12.437	$445.91	3 Feet
DPT-6354	12.750	12.500	$448.13	3 Feet
DPT-6355	12.812	12.562	$450.33	3 Feet
DPT-6356	12.937	12.687	$454.78	3 Feet
DPT-6357	13.000	12.750	$457.01	3 Feet
DPT-6358	13.031	12.781	$458.11	3 Feet
DPT-6359	13.062	12.812	$459.21	3 Feet
DPT-6360	13.094	12.843	$460.31	3 Feet
DPT-6361	13.125	12.875	$461.46	3 Feet
DPT-6362	13.156	12.906	$462.56	3 Feet
DPT-6363	13.187	12.937	$463.66	3 Feet
DPT-6364	13.250	13.000	$465.88	3 Feet
DPT-6365	13.312	13.062	$468.08	3 Feet
DPT-6366	13.375	13.125	$470.33	3 Feet
DPT-6367	13.437	13.187	$472.53	3 Feet
DPT-6368	13.500	13.250	$474.76	3 Feet
DPT-6369	13.562	13.312	$476.96	3 Feet
DPT-6370	13.625	13.375	$479.18	3 Feet
DPT-6371	13.687	13.437	$481.38	3 Feet
DPT-6372	13.750	13.500	$483.63	3 Feet
DPT-6373	13.812	13.562	$485.83	3 Feet
DPT-6374	13.937	13.687	$490.25	3 Feet
DPT-6375	14.000	13.750	$492.51	3 Feet
DPT-6376	14.031	13.781	$493.60	3 Feet
DPT-6377	14.062	13.812	$494.71	3 Feet
DPT-6378	14.094	13.843	$495.80	3 Feet
DPT-6379	14.125	13.875	$496.93	3 Feet
DPT-6380	14.156	13.906	$498.03	3 Feet
DPT-6381	14.187	13.937	$499.13	3 Feet
DPT-6382	14.250	14.000	$501.38	3 Feet
DPT-6383	14.312	14.062	$503.58	3 Feet
DPT-6384	14.375	14.125	$505.80	3 Feet
DPT-6385	14.437	14.187	$508.00	3 Feet
DPT-6386	14.500	14.250	$510.25	3 Feet
DPT-6387	14.562	14.312	$512.46	3 Feet
DPT-6388	14.625	14.375	$514.68	3 Feet
DPT-6389	14.687	14.437	$516.88	3 Feet
DPT-6390	14.750	14.500	$519.11	3 Feet
DPT-6391	14.812	14.562	$521.31	3 Feet
DPT-6392	14.937	14.687	$525.76	3 Feet
DPT-6393	15.000	14.750	$527.98	3 Feet
DPT-6394	15.031	14.781	$529.08	3 Feet
DPT-6395	15.062	14.812	$530.18	3 Feet
DPT-6396	15.094	14.843	$531.28	3 Feet
DPT-6397	15.125	14.875	$532.43	3 Feet
DPT-6398	15.156	14.906	$533.53	3 Feet
DPT-6399	15.187	14.937	$534.63	3 Feet
DPT-6400	15.250	15.000	$536.86	3 Feet
DPT-6401	15.312	15.062	$539.06	3 Feet
DPT-6402	15.375	15.125	$541.31	3 Feet
DPT-6403	15.437	15.187	$543.51	3 Feet
DPT-6404	15.500	15.250	$545.73	3 Feet
DPT-6405	15.562	15.312	$547.93	3 Feet
DPT-6406	15.625	15.375	$550.18	3 Feet
DPT-6407	15.687	15.437	$552.38	3 Feet
DPT-6408	15.750	15.500	$554.61	3 Feet
DPT-6409	15.812	15.562	$556.81	3 Feet
DPT-6410	15.937	15.687	$561.26	3 Feet
DPT-6411	16.000	15.750	$563.48	3 Feet
DPT-6412	16.031	15.781	$564.58	3 Feet
DPT-6413	16.062	15.812	$565.68	3 Feet
DPT-6414	16.094	15.843	$566.78	3 Feet
DPT-6415	16.125	15.875	$567.91	3 Feet
DPT-6416	16.156	15.906	$569.01	3 Feet
DPT-6417	16.187	15.937	$570.11	3 Feet
DPT-6418	16.250	16.000	$572.36	3 Feet
DPT-6419	16.312	16.062	$574.56	3 Feet
DPT-6420	16.375	16.125	$576.78	3 Feet
DPT-6421	16.437	16.187	$578.98	3 Feet
DPT-6422	16.500	16.250	$581.23	3 Feet
DPT-6423	16.562	16.312	$583.43	3 Feet
DPT-6424	16.625	16.375	$585.66	3 Feet
DPT-6425	16.687	16.437	$587.86	3 Feet
DPT-6426	16.750	16.500	$590.11	3 Feet
DPT-6427	16.812	16.562	$592.31	3 Feet
DPT-6428	16.937	16.687	$596.73	3 Feet
DPT-6429	17.000	16.750	$598.98	3 Feet
DPT-6430	17.031	16.781	$600.08	3 Feet
DPT-6431	17.062	16.812	$601.18	3 Feet
DPT-6432	17.094	16.843	$602.28	3 Feet
DPT-6433	17.125	16.875	$603.41	3 Feet
DPT-6434	17.156	16.906	$604.51	3 Feet
DPT-6435	17.187	16.937	$605.61	3 Feet
DPT-6436	17.250	17.000	$607.83	3 Feet
DPT-6437	17.312	17.062	$610.03	3 Feet
DPT-6438	17.375	17.125	$612.28	3 Feet
DPT-6440	17.500	17.250	$616.71	3 Feet
DPT-6441	17.562	17.312	$618.91	3 Feet
DPT-6442	17.625	17.312	$621.16	3 Feet
DPT-6443	17.687	17.437	$623.36	3 Feet
DPT-6444	17.750	17.500	$625.58	3 Feet
DPT-6446	17.937	17.687	$632.23	3 Feet
DPT-6447	18.031	17.750	$634.46	3 Feet
DPT-6448	18.062	17.812	$636.66	3 Feet
DPT-6449	18.094	17.843	$637.76	3 Feet
DPT-6450	18.125	17.875	$638.91	3 Feet
DPT-6451	18.156	17.906	$640.01	3 Feet
DPT-6452	18.187	17.937	$641.11	3 Feet
DPT-6453	18.250	18.031	$644.43	3 Feet
DPT-6454	18.312	18.062	$645.53	3 Feet
DPT-6455	18.375	18.125	$647.76	3 Feet
DPT-6456	18.437	18.187	$649.98	3 Feet
DPT-6457	18.500	18.250	$652.21	3 Feet
DPT-6458	18.562	18.312	$654.41	3 Feet
DPT-6459	18.625	18.375	$656.63	3 Feet
DPT-6460	18.687	18.437	$658.83	3 Feet
DPT-6461	18.750	18.500	$661.08	3 Feet
DPT-6462	18.812	18.562	$663.28	3 Feet
DPT-6463	18.937	18.687	$667.71	3 Feet
DPT-6464	19.000	18.750	$669.96	3 Feet
DPT-6465	19.031	18.781	$671.06	3 Feet
DPT-6466	19.062	18.812	$672.16	3 Feet
DPT-6467	19.094	18.843	$673.26	3 Feet
DPT-6468	19.125	18.875	$674.38	3 Feet
DPT-6469	19.156	18.906	$675.48	3 Feet
DPT-6470	19.187	18.937	$676.58	3 Feet
DPT-6471	19.250	19.031	$679.93	3 Feet
DPT-6472	19.312	19.062	$681.03	3 Feet
DPT-6473	19.375	19.125	$683.26	3 Feet
DPT-6474	19.437	19.187	$685.46	3 Feet
DPT-6475	19.500	19.250	$687.71	3 Feet
DPT-6476	19.562	19.312	$689.91	3 Feet
DPT-6477	19.625	19.375	$692.13	3 Feet
DPT-6478	19.687	19.437	$694.33	3 Feet
DPT-6479	19.750	19.500	$696.56	3 Feet
DPT-6480	19.812	19.562	$698.76	3 Feet
DPT-6481	19.937	19.687	$703.21	3 Feet
DPT-6482	20.000	19.750	$705.43	3 Ft **

nominal inches, diameter	plus or minus (�) tolerance, inches
	ID inside diameter		OD outside diameter
	steel mandrel	built-up mandrel
.125" -.749"	.003"	-	.005"
.750" - 1.999"	.004"	-	.005"
2.000" - 4.000"	.006"	-	.008"
			*turned	*as wound
4.001" - 12.000"	.010"	-	.025"	plus only
12.001" - 18.000"	.030"	.060"	.030"	plus only
18.001" - 24.000"	.040"	.075"	.035"	plus only
24.001" - 48.000"	.060"	.090"	.040"	plus only
*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
