G10 FR4 Tubes Glass Reinforced Tubes .187" (1/16")Wall

G10 FR4 Tubes 3/16 Wall Thickness

(Micarta) (High Pressure Laminates) G10 FR4 Glass Reinforced  natural (yellowish to light green) Technical Data Sheet    Chemical Resistance Chart
The most versatile all-around laminate and composite, this grade is a continuous glass woven fabric base impregnated with an epoxy resin binder. It has extremely high mechanical strength, good dielectric loss properties, and good electric strength properties, both wet and dry.
NEMA G-10 certs to MIL-I-24768/2 GEE, IPC 4101/20, IEC 60893-3 Type 2 EP GC 201
NEMA FR-4 certs to MIL-I-24768/27 GEE-F, IPC 4101/21, IEC 60893-3 Type 2 EP GC 202



.031" (1/32") Wall Thickness

.062" (1/16")Wall Thickness

.093" (3/32")Wall Thickness

.125" (1/8")Wall Thickness

.187" (3/16")Wall Thickness

.250" (1/4")Wall Thickness

.375" (3/8")Wall Thickness

.500" (1/2")Wall Thickness

.750" (3/4")WallThickness

1.00" Wall Thickness (Max. Possible)

.187" G10 FR4 Tubes Wall Thickness

Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts  42-48"

**Minimum's Apply, Non Stocked Item

Tolerances (Note: Pricing for Over 4.00" Diameter Wound Only)
Part # Outside Diameter (in.) Inside Diameter (in.) Price Per Foot Minimum Purchase
