G11/FR5 High Temperature Glass Tubes .187" Wall Thickness
G11 Glass Reinforced
Epoxy - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10 FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.187" Wall Thickness G11 Tubes |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum Purchase |
|---|---|---|---|---|
| DPT-1503 | 0.875 | 0.500 | $70.21 | 12 Feet |
| DPT-1508 | 0.937 | 0.562 | $74.65 | 12 Feet |
| DPT-1514 | 1.000 | 0.625 | $54.36 | 15 Feet |
| DPT-10898 | 1.062 | 0.687 | $57.43 | 15 Feet |
| DPT-1513K | 1.125 | 0.750 | $60.48 | 15 Feet |
| DPT-9259 | 1.187 | 0.812 | $63.56 | 15 Feet |
| DPT-1519 | 1.250 | 0.875 | $66.63 | 12 Feet |
| DPT-10732 | 1.312 | 0.937 | $69.68 | 12 Feet |
| DPT-1525 | 1.375 | 1.000 | $72.76 | 12 Feet |
| DPT-10741 | 1.437 | 1.062 | $75.80 | 12 Feet |
| DPT-10718 | 1.500 | 1.125 | $78.88 | 12 Feet |
| DPT-10083 | 1.562 | 1.187 | $81.93 | 12 Feet |
| DPT-1529 | 1.625 | 1.250 | $85.03 | 9 Feet |
| DPT-10178 | 1.687 | 1.312 | $88.05 | 9 Feet |
| DPT-10177 | 1.750 | 1.375 | $91.16 | 9 Feet |
| DPT-10176 | 1.812 | 1.437 | $94.21 | 9 Feet |
| DPT-10175 | 1.875 | 1.500 | $97.28 | 9 Feet |
| DPT-10174 | 1.937 | 1.562 | $100.33 | 9 Feet |
| DPT-10165 | 2.000 | 1.625 | $103.43 | 9 Feet |
| DPT-10172 | 2.062 | 1.687 | $106.46 | 9 Feet |
| DPT-10180 | 2.125 | 1.750 | $109.55 | 9 Feet |
| DPT-10170 | 2.187 | 1.812 | $112.60 | 9 Feet |
| DPT-10169 | 2.250 | 1.875 | $115.68 | 9 Feet |
| DPT-9346 | 2.312 | 1.937 | $118.73 | 9 Feet |
| DPT-9345 | 2.375 | 2.000 | $121.80 | 9 Feet |
| DPT-9344 | 2.437 | 2.062 | $124.85 | 9 Feet |
| DPT-9343 | 2.500 | 2.125 | $127.96 | 9 Feet |
| DPT-9328 | 2.562 | 2.187 | $130.98 | 6 Feet |
| DPT-9341 | 2.625 | 2.250 | $134.08 | 6 Feet |
| DPT-9354 | 2.687 | 2.312 | $137.13 | 6 Feet |
| DPT-9339 | 2.750 | 2.375 | $140.21 | 6 Feet |
| DPT-9338 | 2.812 | 2.437 | $143.26 | 6 Feet |
| DPT-9337 | 2.875 | 2.500 | $146.36 | 6 Feet |
| DPT-9336 | 2.937 | 2.562 | $149.38 | 6 Feet |
| DPT-9335 | 3.000 | 2.625 | $152.48 | 6 Feet |
| DPT-9334 | 3.062 | 2.687 | $155.53 | 6 Feet |
| DPT-9162 | 3.125 | 2.750 | $158.61 | 6 Feet |
| DPT-9333 | 3.187 | 2.812 | $161.66 | 6 Feet |
| DPT-9218 | 3.250 | 2.875 | $164.76 | 6 Feet |
| DPT-9217 | 3.312 | 2.937 | $167.78 | 6 Feet |
| DPT-9216 | 3.375 | 3.000 | $170.88 | 6 Feet |
| DPT-9215 | 3.437 | 3.062 | $173.93 | 6 Feet |
| DPT-9214 | 3.500 | 3.125 | $177.01 | 6 Feet |
| DPT-9213 | 3.562 | 3.187 | $180.06 | 6 Feet |
| DPT-9212 | 3.625 | 3.250 | $183.13 | 6 Feet |
| DPT-9211 | 3.687 | 3.312 | $186.18 | 6 Feet |
| DPT-9210 | 3.750 | 3.375 | $189.28 | 6 Feet |
| DPT-9209 | 3.812 | 3.437 | $192.31 | 6 Feet |
| DPT-9208 | 3.875 | 3.500 | $195.41 | 6 Feet |
| DPT-9207 | 3.937 | 3.562 | $198.46 | 6 Feet |
| DPT-9191 | 4.000 | 3.625 | $201.53 | 6 Feet |
| DPT-9205 | 4.062 | 3.687 | $204.58 | 6 Feet |
| DPT-9084 | 4.125 | 3.750 | $207.68 | 6 Feet |
| DPT-9076 | 4.187 | 3.812 | $210.71 | 6 Feet |
| DPT-9056 | 4.250 | 3.875 | $213.81 | 6 Feet |
| DPT-9057 | 4.312 | 3.937 | $216.86 | 6 Feet |
| DPT-9058 | 4.375 | 4.000 | $219.93 | 6 Feet |
| DPT-9059 | 4.437 | 4.062 | $222.98 | 6 Feet |
| DPT-9110 | 4.500 | 4.125 | $226.08 | 6 Feet |
| DPT-9109 | 4.562 | 4.187 | $229.11 | 6 Feet |
| DPT-9108 | 4.625 | 4.250 | $232.21 | 6 Feet |
| DPT-9107 | 4.687 | 4.312 | $235.26 | 6 Feet |
| DPT-9094 | 4.750 | 4.375 | $238.33 | 6 Feet |
| DPT-9092 | 4.812 | 4.437 | $241.38 | 6 Feet |
| DPT-9106 | 4.875 | 4.500 | $244.46 | 6 Feet |
| DPT-8958 | 4.937 | 4.562 | $247.51 | 6 Feet |
| DPT-9088 | 5.000 | 4.625 | $250.61 | 6 Feet |
| DPT-9089 | 5.062 | 4.687 | $253.63 | 6 Feet |
| DPT-9090 | 5.125 | 4.750 | $256.73 | 6 Feet |
| DPT-9091 | 5.187 | 4.812 | $259.78 | 3 Feet |
| DPT-9105 | 5.250 | 4.875 | $288.63 | 3 Feet |
| DPT-9093 | 5.312 | 4.937 | $291.98 | 3 Feet |
| DPT-9086 | 5.375 | 5.000 | $295.35 | 3 Feet |
| DPT-9095 | 5.437 | 5.062 | $298.71 | 3 Feet |
| DPT-9096 | 5.500 | 5.125 | $302.10 | 3 Feet |
| DPT-9097 | 5.562 | 5.187 | $305.43 | 3 Feet |
| DPT-9098 | 5.625 | 5.250 | $308.83 | 3 Feet |
| DPT-9099 | 5.687 | 5.312 | $312.18 | 3 Feet |
| DPT-9039 | 5.750 | 5.375 | $315.56 | 3 Feet |
| DPT-9104 | 5.812 | 5.437 | $318.91 | 3 Feet |
| DPT-8985 | 5.875 | 5.500 | $322.30 | 3 Feet |
| DPT-9068 | 5.937 | 5.562 | $325.63 | 3 Feet |
| DPT-9007 | 6.000 | 5.625 | $329.03 | 3 Feet |
| DPT-8978 | 6.062 | 5.687 | $332.38 | 3 Feet |
| DPT-8979 | 6.125 | 5.750 | $335.76 | 3 Feet |
| DPT-8980 | 6.187 | 5.812 | $339.11 | 3 Feet |
| DPT-8981 | 6.250 | 5.875 | $342.51 | 3 Feet |
| DPT-8982 | 6.312 | 5.937 | $345.83 | 3 Feet |
| DPT-9008 | 6.375 | 6.000 | $349.23 | 3 Feet |
| DPT-8984 | 6.437 | 6.062 | $313.91 | 3 Feet |
| DPT-8977 | 6.500 | 6.125 | $317.06 | 3 Feet |
| DPT-8986 | 6.562 | 6.187 | $320.18 | 3 Feet |
| DPT-8987 | 6.625 | 6.250 | $323.35 | 3 Feet |
| DPT-8988 | 6.687 | 6.312 | $326.46 | 3 Feet |
| DPT-8989 | 6.750 | 6.375 | $329.63 | 3 Feet |
| DPT-8990 | 6.812 | 6.437 | $332.73 | 3 Feet |
| DPT-9009 | 6.875 | 6.500 | $335.91 | 3 Feet |
| DPT-8983 | 6.937 | 6.562 | $339.00 | 3 Feet |
| DPT-9010 | 7.000 | 6.625 | $342.18 | 3 Feet |
| DPT-9011 | 7.062 | 6.687 | $345.28 | 3 Feet |
| DPT-9021 | 7.125 | 6.750 | $348.46 | 3 Feet |
| DPT-9013 | 7.187 | 6.812 | $351.56 | 3 Feet |
| DPT-9006 | 7.250 | 6.875 | $354.73 | 3 Feet |
| DPT-9015 | 7.312 | 6.937 | $357.83 | 3 Feet |
| DPT-9016 | 7.375 | 7.000 | $361.01 | 3 Feet |
| DPT-9017 | 7.437 | 7.062 | $364.13 | 3 Feet |
| DPT-9018 | 7.500 | 7.125 | $367.28 | 3 Feet |
| DPT-8794 | 7.562 | 7.187 | $370.41 | 3 Feet |
| DPT-9019 | 7.625 | 7.250 | $373.55 | 3 Feet |
| DPT-8798 | 7.687 | 7.312 | $376.68 | 3 Feet |
| DPT-8799 | 7.750 | 7.375 | $379.83 | 3 Feet |
| DPT-8800 | 7.812 | 7.437 | $382.96 | 3 Feet |
| DPT-8801 | 7.875 | 7.500 | $386.10 | 3 Feet |
| DPT-8802 | 7.937 | 7.562 | $389.23 | 3 Feet |
| DPT-8803 | 8.000 | 7.625 | $392.38 | 3 Feet |
| DPT-8815 | 8.062 | 7.687 | $395.50 | 3 Feet |
| DPT-8805 | 8.125 | 7.750 | $398.66 | 3 Feet |
| DPT-8796 | 8.187 | 7.812 | $401.78 | 3 Feet |
| DPT-8807 | 8.250 | 7.875 | $404.96 | 3 Feet |
| DPT-8808 | 8.312 | 7.937 | $408.06 | 3 Feet |
| DPT-8809 | 8.375 | 8.000 | $411.23 | 3 Feet |
| DPT-8811 | 8.500 | 8.125 | $417.51 | 3 Feet |
| DPT-8812 | 8.562 | 8.187 | $420.61 | 3 Feet |
| DPT-8813 | 8.625 | 8.250 | $423.78 | 3 Feet |
| DPT-8814 | 8.687 | 8.312 | $426.88 | 3 Feet |
| DPT-8786 | 8.750 | 8.375 | $430.06 | 3 Feet |
| DPT-8784 | 8.812 | 8.437 | $433.16 | 3 Feet |
| DPT-8804 | 8.875 | 8.500 | $436.33 | 3 Feet |
| DPT-8778 | 8.937 | 8.562 | $439.43 | 3 Feet |
| DPT-8779 | 9.000 | 8.625 | $442.60 | 3 Feet |
| DPT-8780 | 9.062 | 8.687 | $445.73 | 3 Feet |
| DPT-8781 | 9.125 | 8.750 | $448.88 | 3 Feet |
| DPT-8782 | 9.187 | 8.812 | $452.01 | 3 Feet |
| DPT-8783 | 9.250 | 8.875 | $455.16 | 3 Feet |
| DPT-8795 | 9.312 | 8.937 | $458.28 | 3 Feet |
| DPT-8785 | 9.375 | 9.000 | $461.43 | 3 Feet |
| DPT-8776 | 9.437 | 9.062 | $464.55 | 3 Feet |
| DPT-8787 | 9.500 | 9.125 | $467.71 | 3 Feet |
| DPT-8788 | 9.562 | 9.187 | $470.83 | 3 Feet |
| DPT-8789 | 9.625 | 9.250 | $473.98 | 3 Feet |
| DPT-8790 | 9.687 | 9.312 | $477.10 | 3 Feet |
| DPT-8791 | 9.750 | 9.375 | $480.25 | 3 Feet |
| DPT-8792 | 9.812 | 9.437 | $483.38 | 3 Feet |
| DPT-8793 | 9.875 | 9.500 | $486.56 | 3 Feet |
| DPT-8817 | 9.937 | 9.562 | $489.66 | 3 Feet |
| DPT-8777 | 10.000 | 9.625 | $492.83 | 3 Feet |
| DPT-8806 | 10.062 | 9.687 | $495.93 | 3 Feet |
| DPT-8837 | 10.125 | 9.750 | $499.11 | 3 Feet |
| DPT-8838 | 10.187 | 9.812 | $502.21 | 3 Feet |
| DPT-8839 | 10.250 | 9.875 | $505.38 | 3 Feet |
| DPT-8840 | 10.312 | 9.937 | $508.48 | 3 Feet |
| DPT-8991 | 10.375 | 10.000 | $511.66 | 3 Feet |
| DPT-9014 | 10.437 | 10.062 | $514.76 | 3 Feet |
| DPT-9012 | 10.500 | 10.125 | $517.93 | 3 Feet |
| DPT-9004 | 10.562 | 10.187 | $521.03 | 3 Feet |
| DPT-9003 | 10.625 | 10.250 | $524.21 | 3 Feet |
| DPT-8836 | 10.687 | 10.312 | $527.33 | 3 Feet |
| DPT-9002 | 10.750 | 10.375 | $530.48 | 3 Feet |
| DPT-9001 | 10.812 | 10.437 | $533.61 | 3 Feet |
| DPT-9000 | 10.875 | 10.500 | $536.76 | 3 Feet |
| DPT-8999 | 10.937 | 10.562 | $539.88 | 3 Feet |
| DPT-8998 | 11.000 | 10.625 | $543.03 | 3 Feet |
| DPT-8997 | 11.062 | 10.687 | $546.16 | 3 Feet |
| DPT-8996 | 11.125 | 10.750 | $549.31 | 3 Feet |
| DPT-8995 | 11.187 | 10.812 | $552.43 | 3 Feet |
| DPT-8826 | 11.250 | 10.875 | $555.58 | 3 Feet |
| DPT-8824 | 11.312 | 10.937 | $558.71 | 3 Feet |
| DPT-8994 | 11.375 | 11.000 | $561.88 | 3 Feet |
| DPT-8818 | 11.437 | 11.062 | $564.98 | 3 Feet |
| DPT-8819 | 11.500 | 11.125 | $568.16 | 3 Feet |
| DPT-8820 | 11.562 | 11.187 | $571.26 | 3 Feet |
| DPT-8821 | 11.625 | 11.250 | $574.43 | 3 Feet |
| DPT-8822 | 11.687 | 11.312 | $577.53 | 3 Feet |
| DPT-8823 | 11.750 | 11.375 | $580.71 | 3 Feet |
| DPT-8835 | 11.812 | 11.437 | $583.81 | 3 Feet |
| DPT-8825 | 11.875 | 11.500 | $586.98 | 3 Feet |
| DPT-8816 | 11.937 | 11.562 | $590.08 | 3 Feet |
| DPT-8827 | 12.000 | 11.625 | $593.26 | 3 Feet |
| DPT-8828 | 12.062 | 11.687 | $596.36 | 3 Feet |
| DPT-8829 | 12.125 | 11.750 | $599.53 | 3 Feet |
| DPT-8830 | 12.187 | 11.812 | $602.66 | 3 Feet |
| DPT-8831 | 12.250 | 11.875 | $605.81 | 3 Feet |
| DPT-8832 | 12.312 | 11.937 | $608.93 | 3 Feet |
| DPT-8833 | 12.375 | 12.000 | $612.08 | 3 Feet |
| DPT-8834 | 12.437 | 12.062 | $615.21 | 3 Feet |
| DPT-8993 | 12.500 | 12.125 | $618.36 | 3 Feet |
| DPT-8992 | 12.562 | 12.187 | $621.48 | 3 Feet |
| DPT-9023 | 12.625 | 12.250 | $624.63 | 3 Feet |
| DPT-9046 | 12.687 | 12.312 | $627.76 | 3 Feet |
| DPT-9020 | 12.750 | 12.375 | $630.91 | 3 Feet |
| DPT-9040 | 12.812 | 12.437 | $634.03 | 3 Feet |
| DPT-9041 | 12.875 | 12.500 | $637.18 | 3 Feet |
| DPT-9042 | 12.937 | 12.562 | $640.31 | 3 Feet |
| DPT-8975 | 13.000 | 12.625 | $643.48 | 3 Feet |
| DPT-8925 | 13.062 | 12.687 | $646.58 | 3 Feet |
| DPT-9043 | 13.125 | 12.750 | $649.76 | 3 Feet |
| DPT-8929 | 13.187 | 12.812 | $652.86 | 3 Feet |
| DPT-8909 | 13.250 | 12.875 | $656.03 | 3 Feet |
| DPT-8930 | 13.312 | 12.937 | $659.13 | 3 Feet |
| DPT-8931 | 13.375 | 13.000 | $662.31 | 3 Feet |
| DPT-8932 | 13.437 | 13.062 | $665.41 | 3 Feet |
| DPT-8933 | 13.500 | 13.125 | $668.58 | 3 Feet |
| DPT-8943 | 13.562 | 13.187 | $671.68 | 3 Feet |
| DPT-8935 | 13.625 | 13.250 | $674.86 | 3 Feet |
| DPT-8910 | 13.687 | 13.312 | $677.96 | 3 Feet |
| DPT-8927 | 13.750 | 13.375 | $681.13 | 3 Feet |
| DPT-8937 | 13.812 | 13.437 | $684.26 | 3 Feet |
| DPT-8938 | 13.875 | 13.500 | $687.41 | 3 Feet |
| DPT-8939 | 13.937 | 13.562 | $690.53 | 3 Feet |
| DPT-8940 | 14.000 | 13.625 | $693.68 | 3 Feet |
| DPT-8941 | 14.062 | 13.687 | $696.81 | 3 Feet |
| DPT-8919 | 14.125 | 13.750 | $699.96 | 3 Feet |
| DPT-8936 | 14.187 | 13.812 | $703.08 | 3 Feet |
| DPT-8934 | 14.250 | 13.875 | $706.23 | 3 Feet |
| DPT-8912 | 14.250 | 13.875 | $706.23 | 3 Feet |
| DPT-8913 | 14.312 | 13.937 | $709.36 | 3 Feet |
| DPT-8914 | 14.375 | 14.000 | $712.51 | 3 Feet |
| DPT-8915 | 14.437 | 14.062 | $715.63 | 3 Feet |
| DPT-8916 | 14.500 | 14.125 | $718.78 | 3 Feet |
| DPT-8926 | 14.562 | 14.187 | $721.91 | 3 Feet |
| DPT-8918 | 14.625 | 14.250 | $725.08 | 3 Feet |
| DPT-8911 | 14.687 | 14.312 | $728.18 | 3 Feet |
| DPT-8920 | 14.750 | 14.375 | $731.36 | 3 Feet |
| DPT-8921 | 14.812 | 14.437 | $734.46 | 3 Feet |
| DPT-8922 | 14.875 | 14.500 | $737.63 | 3 Feet |
| DPT-8923 | 14.937 | 14.562 | $740.73 | 3 Feet |
| DPT-8924 | 15.000 | 14.625 | $743.91 | 3 Feet |
| DPT-8950 | 15.062 | 14.687 | $747.01 | 3 Feet |
| DPT-8917 | 15.125 | 14.750 | $750.18 | 3 Feet |
| DPT-8942 | 15.187 | 14.812 | $753.28 | 3 Feet |
| DPT-8961 | 15.250 | 14.875 | $756.46 | 3 Feet |
| DPT-8962 | 15.312 | 14.937 | $759.56 | 3 Feet |
| DPT-8963 | 15.375 | 15.000 | $762.73 | 3 Feet |
| DPT-8964 | 15.437 | 15.062 | $765.86 | 3 Feet |
| DPT-8965 | 15.500 | 15.125 | $769.01 | 3 Feet |
| DPT-8966 | 15.562 | 15.187 | $772.13 | 3 Feet |
| DPT-8976 | 15.625 | 15.250 | $775.28 | 3 Feet |
| DPT-8968 | 15.687 | 15.312 | $778.41 | 3 Feet |
| DPT-8901 | 15.750 | 15.375 | $781.56 | 3 Feet |
| DPT-8856 | 15.812 | 15.437 | $784.68 | 3 Feet |
| DPT-8960 | 15.875 | 15.500 | $787.83 | 3 Feet |
| DPT-8860 | 15.937 | 15.562 | $790.96 | 3 Feet |
| DPT-8861 | 16.000 | 15.625 | $794.11 | 3 Feet |
| DPT-8862 | 16.062 | 15.687 | $797.23 | 3 Feet |
| DPT-8863 | 16.125 | 15.750 | $800.38 | 3 Feet |
| DPT-8864 | 16.187 | 15.812 | $803.51 | 3 Feet |
| DPT-8874 | 16.250 | 15.875 | $806.68 | 3 Feet |
| DPT-8866 | 16.312 | 15.937 | $809.78 | 3 Feet |
| DPT-8858 | 16.375 | 16.000 | $812.96 | 3 Feet |
| DPT-8868 | 16.437 | 16.062 | $816.06 | 3 Feet |
| DPT-8869 | 16.500 | 16.125 | $819.23 | 3 Feet |
| DPT-8870 | 16.562 | 16.187 | $822.33 | 3 Feet |
| DPT-8871 | 16.625 | 16.250 | $825.51 | 3 Feet |
| DPT-8872 | 16.687 | 16.312 | $828.61 | 3 Feet |
| DPT-8873 | 16.750 | 16.375 | $831.78 | 3 Feet |
| DPT-8850 | 16.812 | 16.437 | $834.88 | 3 Feet |
| DPT-8848 | 16.875 | 16.500 | $838.06 | 3 Feet |
| DPT-8865 | 16.937 | 16.562 | $841.16 | 3 Feet |
| DPT-8843 | 17.000 | 16.625 | $844.33 | 3 Feet |
| DPT-8844 | 17.062 | 16.687 | $847.46 | 3 Feet |
| DPT-8845 | 17.125 | 16.750 | $850.61 | 3 Feet |
| DPT-8846 | 17.187 | 16.812 | $853.73 | 3 Feet |
| DPT-8847 | 17.250 | 16.875 | $856.88 | 3 Feet |
| DPT-8857 | 17.312 | 16.937 | $860.01 | 3 Feet |
| DPT-8849 | 17.375 | 17.000 | $863.16 | 3 Feet |
| DPT-8841 | 17.437 | 17.062 | $866.28 | 3 Feet |
| DPT-8851 | 17.500 | 17.125 | $869.43 | 3 Feet |
| DPT-8852 | 17.562 | 17.187 | $872.56 | 3 Feet |
| DPT-8853 | 17.625 | 17.250 | $875.71 | 3 Feet |
| DPT-8854 | 17.687 | 17.312 | $878.83 | 3 Feet |
| DPT-8855 | 17.750 | 17.375 | $881.98 | 3 Feet |
| DPT-8876 | 17.812 | 17.437 | $885.11 | 3 Feet |
| DPT-8842 | 17.875 | 17.500 | $888.28 | 3 Feet |
| DPT-8867 | 17.937 | 17.562 | $891.38 | 3 Feet |
| DPT-8893 | 18.000 | 17.625 | $894.56 | 3 Feet |
| DPT-8894 | 18.062 | 17.687 | $897.66 | 3 Feet |
| DPT-8895 | 18.125 | 17.750 | $900.83 | 3 Feet |
| DPT-8896 | 18.187 | 17.812 | $903.93 | 3 Feet |
| DPT-8897 | 18.250 | 17.875 | $907.11 | 3 Feet |
| DPT-8898 | 18.312 | 17.937 | $910.21 | 3 Feet |
| DPT-8908 | 18.375 | 18.000 | $913.38 | 3 Feet |
| DPT-8900 | 18.437 | 18.062 | $916.48 | 3 Feet |
| DPT-8892 | 18.500 | 18.125 | $919.66 | 3 Feet |
| DPT-8902 | 18.562 | 18.187 | $922.76 | 3 Feet |
| DPT-8903 | 18.625 | 18.250 | $925.93 | 3 Feet |
| DPT-8904 | 18.687 | 18.312 | $929.06 | 3 Feet |
| DPT-8905 | 18.750 | 18.375 | $932.21 | 3 Feet |
| DPT-8906 | 18.812 | 18.437 | $935.33 | 3 Feet |
| DPT-8907 | 18.875 | 18.500 | $938.48 | 3 Feet |
| DPT-8884 | 18.937 | 18.562 | $941.61 | 3 Feet |
| DPT-8882 | 19.000 | 18.625 | $944.76 | 3 Feet |
| DPT-8899 | 19.062 | 18.687 | $947.88 | 3 Feet |
| DPT-8877 | 19.125 | 18.750 | $951.03 | 3 Feet |
| DPT-8878 | 19.187 | 18.812 | $954.16 | 3 Feet |
| DPT-8879 | 19.250 | 18.875 | $957.31 | 3 Feet |
| DPT-8880 | 19.312 | 18.937 | $960.43 | 3 Feet |
| DPT-8881 | 19.375 | 19.000 | $963.61 | 3 Feet |
| DPT-8891 | 19.437 | 19.062 | $966.71 | 3 Feet |
| DPT-8883 | 19.500 | 19.125 | $969.88 | 3 Feet |
| DPT-8875 | 19.562 | 19.187 | $972.98 | 3 Feet |
| DPT-8885 | 19.625 | 19.250 | $976.16 | 3 Feet |
| DPT-8886 | 19.687 | 19.312 | $979.26 | 3 Feet |
| DPT-8887 | 19.750 | 19.375 | $982.43 | 3 Feet |
| DPT-8888 | 19.812 | 19.437 | $985.53 | 3 Feet |
| DPT-8889 | 19.875 | 19.500 | $988.71 | 3 Feet |
| DPT-8970 | 19.937 | 19.562 | $991.81 | 3 Feet |
| DPT-9265 | 20.000 | 19.625 | $994.98 | 3 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
