G11 High Temperature Tubes Glass .375" Wall Thickness
G11 Glass Reinforced Tubes - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10 FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.375" Wall Thickness G11 Tubes |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum Purchase |
|---|---|---|---|---|
| DPT-8565 | 1.125 | 0.750 | $127.35 | 9 Feet |
| DPT-8556 | 1.187 | 0.437 | $135.98 | 6 Feet |
| DPT-8567 | 1.250 | 0.500 | $144.63 | 6 Feet |
| DPT-11022 | 1.312 | 0.562 | $153.26 | 6 Feet |
| DPT-11039 | 1.375 | 0.625 | $111.18 | 9 Feet |
| DPT-11017 | 1.437 | 0.687 | $117.11 | 9 Feet |
| DPT-11018 | 1.500 | 0.750 | $123.03 | 6 Feet |
| DPT-11019 | 1.562 | 0.812 | $128.96 | 6 Feet |
| DPT-11020 | 1.625 | 0.875 | $134.88 | 6 Feet |
| DPT-11021 | 1.687 | 0.937 | $140.81 | 6 Feet |
| DPT-11031 | 1.750 | 1.000 | $146.73 | 6 Feet |
| DPT-11023 | 1.812 | 1.062 | $152.61 | 6 Feet |
| DPT-11015 | 1.875 | 1.125 | $158.58 | 6 Feet |
| DPT-11025 | 1.937 | 1.187 | $164.46 | 6 Feet |
| DPT-1531 | 2.000 | 1.250 | $170.43 | 6 Feet |
| DPT-11027 | 2.062 | 1.312 | $176.31 | 6 Feet |
| DPT-11028 | 2.125 | 1.375 | $182.28 | 6 Feet |
| DPT-8546 | 2.187 | 1.437 | $188.16 | 6 Feet |
| DPT-1535 | 2.250 | 1.500 | $194.13 | 6 Feet |
| DPT-8564 | 2.312 | 1.562 | $200.01 | 6 Feet |
| DPT-8538 | 2.375 | 1.625 | $205.98 | 6 Feet |
| DPT-8539 | 2.437 | 1.687 | $211.86 | 6 Feet |
| DPT-1540 | 2.500 | 1.750 | $217.83 | 6 Feet |
| DPT-8541 | 2.562 | 1.812 | $223.71 | 6 Feet |
| DPT-8542 | 2.625 | 1.875 | $229.68 | 3 Feet |
| DPT-8543 | 2.687 | 1.937 | $235.56 | 3 Feet |
| DPT-1545 | 2.750 | 2.000 | $241.53 | 3 Feet |
| DPT-8545 | 2.812 | 2.062 | $247.41 | 3 Feet |
| DPT-8536 | 2.875 | 2.125 | $253.36 | 3 Feet |
| DPT-8547 | 2.937 | 2.187 | $259.26 | 3 Feet |
| DPT-1550 | 3.000 | 2.250 | $265.21 | 3 Feet |
| DPT-8549 | 3.062 | 2.312 | $271.10 | 3 Feet |
| DPT-8550 | 3.125 | 2.375 | $277.06 | 3 Feet |
| DPT-8551 | 3.187 | 2.437 | $282.93 | 3 Feet |
| DPT-1555 | 3.250 | 2.500 | $288.91 | 3 Feet |
| DPT-8553 | 3.312 | 2.562 | $294.78 | 3 Feet |
| DPT-8577 | 3.375 | 2.625 | $300.76 | 3 Feet |
| DPT-8537 | 3.437 | 2.687 | $306.63 | 3 Feet |
| DPT-1560 | 3.500 | 2.750 | $312.61 | 3 Feet |
| DPT-8597 | 3.562 | 2.812 | $318.48 | 3 Feet |
| DPT-8598 | 3.625 | 2.875 | $324.46 | 3 Feet |
| DPT-8599 | 3.687 | 2.937 | $330.33 | 3 Feet |
| DPT-1564 | 3.750 | 3.000 | $336.31 | 3 Feet |
| DPT-8601 | 3.812 | 3.062 | $342.18 | 3 Feet |
| DPT-8602 | 3.875 | 3.125 | $348.16 | 3 Feet |
| DPT-8603 | 3.937 | 3.187 | $354.03 | 3 Feet |
| DPT-1569 | 4.000 | 3.250 | $360.01 | 3 Feet |
| DPT-8605 | 4.062 | 3.312 | $365.88 | 3 Feet |
| DPT-8596 | 4.125 | 3.375 | $371.86 | 3 Feet |
| DPT-8607 | 4.187 | 3.437 | $377.73 | 3 Feet |
| DPT-1574 | 4.250 | 3.500 | $383.71 | 3 Feet |
| DPT-8609 | 4.312 | 3.562 | $389.58 | 3 Feet |
| DPT-8610 | 4.375 | 3.625 | $395.56 | 3 Feet |
| DPT-8611 | 4.437 | 3.687 | $401.43 | 3 Feet |
| DPT-1579 | 4.500 | 3.750 | $407.41 | 3 Feet |
| DPT-8613 | 4.562 | 3.812 | $413.28 | 3 Feet |
| DPT-8614 | 4.625 | 3.875 | $419.25 | 3 Feet |
| DPT-8586 | 4.687 | 3.937 | $425.13 | 3 Feet |
| DPT-8584 | 4.750 | 4.000 | $431.10 | 3 Feet |
| DPT-8604 | 4.812 | 4.062 | $436.98 | 3 Feet |
| DPT-8578 | 4.875 | 4.125 | $442.96 | 3 Feet |
| DPT-8579 | 4.937 | 4.187 | $448.83 | 3 Feet |
| DPT-8580 | 5.000 | 4.250 | $454.80 | 3 Feet |
| DPT-8581 | 5.062 | 4.312 | $460.68 | 3 Feet |
| DPT-8582 | 5.125 | 4.375 | $466.66 | 3 Feet |
| DPT-8583 | 5.187 | 4.437 | $472.53 | 3 Feet |
| DPT-8595 | 5.250 | 4.500 | $478.51 | 3 Feet |
| DPT-8585 | 5.312 | 4.562 | $484.38 | 3 Feet |
| DPT-8576 | 5.375 | 4.625 | $490.36 | 3 Feet |
| DPT-8587 | 5.437 | 4.687 | $496.23 | 3 Feet |
| DPT-8588 | 5.500 | 4.750 | $502.21 | 3 Feet |
| DPT-8589 | 5.562 | 4.812 | $508.08 | 3 Feet |
| DPT-8590 | 5.625 | 4.875 | $564.43 | 3 Feet |
| DPT-8591 | 5.687 | 4.937 | $570.88 | 3 Feet |
| DPT-8592 | 5.750 | 5.000 | $577.46 | 3 Feet |
| DPT-8593 | 5.812 | 5.062 | $583.91 | 3 Feet |
| DPT-8594 | 5.875 | 5.125 | $590.46 | 3 Feet |
| DPT-8526 | 5.937 | 5.187 | $596.91 | 3 Feet |
| DPT-8474 | 6.000 | 5.250 | $603.46 | 3 Feet |
| DPT-8554 | 6.062 | 5.312 | $609.93 | 3 Feet |
| DPT-8478 | 6.125 | 5.375 | $616.48 | 3 Feet |
| DPT-8479 | 6.187 | 5.437 | $622.93 | 3 Feet |
| DPT-8480 | 6.250 | 5.500 | $629.48 | 3 Feet |
| DPT-8481 | 6.312 | 5.562 | $635.93 | 3 Feet |
| DPT-8482 | 6.375 | 5.625 | $642.51 | 3 Feet |
| DPT-8483 | 6.437 | 5.687 | $648.96 | 3 Feet |
| DPT-8495 | 6.500 | 5.750 | $655.51 | 3 Feet |
| DPT-8485 | 6.562 | 5.812 | $661.96 | 3 Feet |
| DPT-8476 | 6.625 | 5.875 | $668.53 | 3 Feet |
| DPT-8487 | 6.687 | 5.937 | $674.98 | 3 Feet |
| DPT-8488 | 6.750 | 6.000 | $681.53 | 3 Feet |
| DPT-8489 | 6.812 | 6.062 | $646.56 | 3 Feet |
| DPT-8490 | 6.875 | 6.125 | $652.88 | 3 Feet |
| DPT-8491 | 6.937 | 6.187 | $659.11 | 3 Feet |
| DPT-8492 | 7.000 | 6.250 | $665.43 | 3 Feet |
| DPT-8493 | 7.062 | 6.312 | $671.66 | 3 Feet |
| DPT-8494 | 7.125 | 6.375 | $677.98 | 3 Feet |
| DPT-8466 | 7.187 | 6.437 | $684.23 | 3 Feet |
| DPT-8464 | 7.250 | 6.500 | $690.56 | 3 Feet |
| DPT-8484 | 7.312 | 6.562 | $696.78 | 3 Feet |
| DPT-8458 | 7.375 | 6.625 | $703.11 | 3 Feet |
| DPT-8459 | 7.437 | 6.687 | $709.33 | 3 Feet |
| DPT-8460 | 7.500 | 6.750 | $715.66 | 3 Feet |
| DPT-8461 | 7.562 | 6.812 | $721.88 | 3 Feet |
| DPT-8462 | 7.625 | 6.875 | $728.21 | 3 Feet |
| DPT-8463 | 7.687 | 6.937 | $734.43 | 3 Feet |
| DPT-8475 | 7.750 | 7.000 | $740.76 | 3 Feet |
| DPT-8465 | 7.812 | 7.062 | $746.98 | 3 Feet |
| DPT-8528 | 7.875 | 7.125 | $753.31 | 3 Feet |
| DPT-8529 | 7.937 | 7.187 | $759.53 | 3 Feet |
| DPT-8530 | 8.000 | 7.250 | $765.88 | 3 Feet |
| DPT-9022 | 8.062 | 7.312 | $772.11 | 3 Feet |
| DPT-9031 | 8.125 | 7.375 | $778.43 | 3 Feet |
| DPT-9032 | 8.187 | 7.437 | $784.66 | 3 Feet |
| DPT-9033 | 8.250 | 7.500 | $790.98 | 3 Feet |
| DPT-9034 | 8.312 | 7.562 | $797.21 | 3 Feet |
| DPT-9035 | 8.375 | 7.625 | $803.53 | 3 Feet |
| DPT-9103 | 8.437 | 7.687 | $809.76 | 3 Feet |
| DPT-9005 | 8.500 | 7.750 | $816.08 | 3 Feet |
| DPT-9100 | 8.562 | 7.812 | $822.31 | 3 Feet |
| DPT-9174 | 8.625 | 7.875 | $828.63 | 3 Feet |
| DPT-9114 | 8.687 | 7.937 | $834.86 | 3 Feet |
| DPT-9116 | 8.750 | 8.000 | $841.18 | 3 Feet |
| DPT-9188 | 8.875 | 8.125 | $853.76 | 3 Feet |
| DPT-9187 | 8.937 | 8.187 | $859.98 | 3 Feet |
| DPT-9186 | 9.000 | 8.250 | $866.31 | 3 Feet |
| DPT-9185 | 9.062 | 8.312 | $872.53 | 3 Feet |
| DPT-9184 | 9.125 | 8.375 | $878.86 | 3 Feet |
| DPT-9183 | 9.187 | 8.437 | $885.08 | 3 Feet |
| DPT-9182 | 9.250 | 8.500 | $891.41 | 3 Feet |
| DPT-9181 | 9.312 | 8.562 | $897.63 | 3 Feet |
| DPT-9180 | 9.375 | 8.625 | $903.96 | 3 Feet |
| DPT-9179 | 9.437 | 8.687 | $910.18 | 3 Feet |
| DPT-9178 | 9.500 | 8.750 | $916.51 | 3 Feet |
| DPT-9177 | 9.562 | 8.812 | $922.73 | 3 Feet |
| DPT-9161 | 9.625 | 8.875 | $929.08 | 3 Feet |
| DPT-9175 | 9.687 | 8.937 | $935.31 | 3 Feet |
| DPT-9190 | 9.750 | 9.000 | $941.63 | 3 Feet |
| DPT-9173 | 9.812 | 9.062 | $947.86 | 3 Feet |
| DPT-9172 | 9.875 | 9.125 | $954.18 | 3 Feet |
| DPT-9171 | 9.937 | 9.187 | $960.41 | 3 Feet |
| DPT-9170 | 10.000 | 9.250 | $966.73 | 3 Feet |
| DPT-9169 | 10.062 | 9.312 | $972.96 | 3 Feet |
| DPT-9168 | 10.125 | 9.375 | $979.28 | 3 Feet |
| DPT-9167 | 10.187 | 9.437 | $985.51 | 3 Feet |
| DPT-9166 | 10.250 | 9.500 | $991.83 | 3 Feet |
| DPT-9165 | 10.312 | 9.562 | $998.06 | 3 Feet |
| DPT-9164 | 10.375 | 9.625 | $1,004.41 | 3 Feet |
| DPT-9163 | 10.437 | 9.687 | $1,010.63 | 3 Feet |
| DPT-9279 | 10.500 | 9.750 | $1,016.96 | 3 Feet |
| DPT-9159 | 10.562 | 9.812 | $1,023.18 | 3 Feet |
| DPT-9236 | 10.625 | 9.875 | $1,029.50 | 3 Feet |
| DPT-9332 | 10.687 | 9.937 | $1,035.73 | 3 Feet |
| DPT-9331 | 10.750 | 10.000 | $1,042.06 | 3 Feet |
| DPT-9330 | 10.812 | 10.062 | $1,048.28 | 3 Feet |
| DPT-9329 | 10.875 | 10.125 | $1,054.61 | 3 Feet |
| DPT-9435 | 10.937 | 10.187 | $1,060.83 | 3 Feet |
| DPT-9518 | 11.000 | 10.250 | $1,067.16 | 3 Feet |
| DPT-9383 | 11.062 | 10.312 | $1,073.38 | 3 Feet |
| DPT-9489 | 11.125 | 10.375 | $1,079.71 | 3 Feet |
| DPT-9488 | 11.187 | 10.437 | $1,085.96 | 3 Feet |
| DPT-9487 | 11.250 | 10.500 | $1,092.28 | 3 Feet |
| DPT-9486 | 11.312 | 10.562 | $1,098.50 | 3 Feet |
| DPT-9485 | 11.375 | 10.625 | $1,104.83 | 3 Feet |
| DPT-9484 | 11.437 | 10.687 | $1,111.05 | 3 Feet |
| DPT-9483 | 11.500 | 10.750 | $1,117.38 | 3 Feet |
| DPT-9482 | 11.562 | 10.812 | $1,123.61 | 3 Feet |
| DPT-9481 | 11.625 | 10.875 | $1,129.93 | 3 Feet |
| DPT-9480 | 11.687 | 10.937 | $1,136.16 | 3 Feet |
| DPT-9465 | 11.750 | 11.000 | $1,142.48 | 3 Feet |
| DPT-9478 | 11.812 | 11.062 | $1,148.71 | 3 Feet |
| DPT-9491 | 11.875 | 11.125 | $1,155.03 | 3 Feet |
| DPT-9476 | 11.937 | 11.187 | $1,161.26 | 3 Feet |
| DPT-9475 | 12.000 | 11.250 | $1,167.61 | 3 Feet |
| DPT-9474 | 12.062 | 11.312 | $1,173.83 | 3 Feet |
| DPT-9473 | 12.125 | 11.375 | $1,180.15 | 3 Feet |
| DPT-9472 | 12.187 | 11.437 | $1,186.38 | 3 Feet |
| DPT-9471 | 12.250 | 11.500 | $1,192.71 | 3 Feet |
| DPT-9470 | 12.312 | 11.562 | $1,198.93 | 3 Feet |
| DPT-9469 | 12.375 | 11.625 | $1,205.25 | 3 Feet |
| DPT-9468 | 12.437 | 11.687 | $1,211.48 | 3 Feet |
| DPT-9467 | 12.500 | 11.750 | $1,217.80 | 3 Feet |
| DPT-9466 | 12.562 | 11.812 | $1,224.03 | 3 Feet |
| DPT-9504 | 12.625 | 11.875 | $1,230.36 | 3 Feet |
| DPT-9506 | 12.687 | 11.937 | $1,236.58 | 3 Feet |
| DPT-9479 | 12.750 | 12.000 | $1,242.91 | 3 Feet |
| DPT-9517 | 12.812 | 12.062 | $1,249.16 | 3 Feet |
| DPT-9516 | 12.875 | 12.125 | $1,255.48 | 3 Feet |
| DPT-9515 | 12.937 | 12.187 | $1,261.71 | 3 Feet |
| DPT-9514 | 13.000 | 12.250 | $1,268.03 | 3 Feet |
| DPT-9513 | 13.062 | 12.312 | $1,274.25 | 3 Feet |
| DPT-9512 | 13.125 | 12.375 | $1,280.58 | 3 Feet |
| DPT-9511 | 13.187 | 12.437 | $1,286.81 | 3 Feet |
| DPT-9510 | 13.250 | 12.500 | $1,293.13 | 3 Feet |
| DPT-9509 | 13.312 | 12.562 | $1,299.36 | 3 Feet |
| DPT-9508 | 13.375 | 12.625 | $1,305.68 | 3 Feet |
| DPT-9507 | 13.437 | 12.687 | $1,311.91 | 3 Feet |
| DPT-9492 | 13.500 | 12.750 | $1,318.23 | 3 Feet |
| DPT-9505 | 13.562 | 12.812 | $1,324.46 | 3 Feet |
| DPT-9519 | 13.625 | 12.875 | $1,330.80 | 3 Feet |
| DPT-9503 | 13.687 | 12.937 | $1,337.03 | 3 Feet |
| DPT-9502 | 13.750 | 13.000 | $1,343.35 | 3 Feet |
| DPT-9501 | 13.812 | 13.062 | $1,349.58 | 3 Feet |
| DPT-9500 | 13.875 | 13.125 | $1,355.91 | 3 Feet |
| DPT-9499 | 13.937 | 13.187 | $1,362.13 | 3 Feet |
| DPT-9498 | 14.000 | 13.250 | $1,368.46 | 3 Feet |
| DPT-9497 | 14.062 | 13.312 | $1,374.68 | 3 Feet |
| DPT-9496 | 14.125 | 13.375 | $1,381.00 | 3 Feet |
| DPT-9495 | 14.187 | 13.437 | $1,387.23 | 3 Feet |
| DPT-9494 | 14.250 | 13.500 | $1,393.55 | 3 Feet |
| DPT-9296 | 14.312 | 13.562 | $1,399.78 | 3 Feet |
| DPT-9252 | 14.375 | 13.625 | $1,406.13 | 3 Feet |
| DPT-9493 | 14.437 | 13.687 | $1,412.35 | 3 Feet |
| DPT-9278 | 14.500 | 13.750 | $1,418.68 | 3 Feet |
| DPT-9277 | 14.562 | 13.812 | $1,424.90 | 3 Feet |
| DPT-9276 | 14.625 | 13.875 | $1,431.23 | 3 Feet |
| DPT-9275 | 14.687 | 13.937 | $1,437.46 | 3 Feet |
| DPT-9274 | 14.750 | 14.000 | $1,443.78 | 3 Feet |
| DPT-9273 | 14.812 | 14.062 | $1,450.01 | 3 Feet |
| DPT-9272 | 14.875 | 14.125 | $1,456.33 | 3 Feet |
| DPT-9271 | 14.937 | 14.187 | $1,462.55 | 3 Feet |
| DPT-9270 | 15.000 | 14.250 | $1,468.88 | 3 Feet |
| DPT-9269 | 15.062 | 14.312 | $1,475.11 | 3 Feet |
| DPT-9268 | 15.125 | 14.375 | $1,481.43 | 3 Feet |
| DPT-9267 | 15.187 | 14.437 | $1,487.68 | 3 Feet |
| DPT-9251 | 15.250 | 14.500 | $1,494.01 | 3 Feet |
| DPT-9280 | 15.312 | 14.562 | $1,500.23 | 3 Feet |
| DPT-9263 | 15.375 | 14.625 | $1,506.56 | 3 Feet |
| DPT-9262 | 15.437 | 14.687 | $1,512.78 | 3 Feet |
| DPT-9261 | 15.500 | 14.750 | $1,519.11 | 3 Feet |
| DPT-9260 | 15.562 | 14.812 | $1,525.33 | 3 Feet |
| DPT-9258 | 15.625 | 14.875 | $1,531.66 | 3 Feet |
| DPT-9257 | 15.687 | 14.937 | $1,537.88 | 3 Feet |
| DPT-9256 | 15.750 | 15.000 | $1,544.21 | 3 Feet |
| DPT-9255 | 15.812 | 15.062 | $1,550.43 | 3 Feet |
| DPT-9254 | 15.875 | 15.125 | $1,556.75 | 3 Feet |
| DPT-9253 | 15.937 | 15.187 | $1,562.98 | 3 Feet |
| DPT-9294 | 16.000 | 15.250 | $1,569.33 | 3 Feet |
| DPT-9264 | 16.062 | 15.312 | $1,575.56 | 3 Feet |
| DPT-9266 | 16.125 | 15.375 | $1,581.88 | 3 Feet |
| DPT-9463 | 16.187 | 15.437 | $1,588.11 | 3 Feet |
| DPT-9422 | 16.250 | 15.500 | $1,594.43 | 3 Feet |
| DPT-9477 | 16.312 | 15.562 | $1,600.66 | 3 Feet |
| DPT-9434 | 16.375 | 15.625 | $1,606.98 | 3 Feet |
| DPT-9071 | 16.437 | 15.687 | $1,613.21 | 3 Feet |
| DPT-9433 | 16.500 | 15.750 | $1,619.53 | 3 Feet |
| DPT-9432 | 16.562 | 15.812 | $1,625.75 | 3 Feet |
| DPT-9431 | 16.625 | 15.875 | $1,632.08 | 3 Feet |
| DPT-9430 | 16.687 | 15.937 | $1,638.30 | 3 Feet |
| DPT-9429 | 16.750 | 16.000 | $1,644.63 | 3 Feet |
| DPT-9300 | 16.812 | 16.062 | $1,650.88 | 3 Feet |
| DPT-9299 | 16.875 | 16.125 | $1,657.21 | 3 Feet |
| DPT-9298 | 16.937 | 16.187 | $1,663.43 | 3 Feet |
| DPT-9297 | 17.000 | 16.250 | $1,669.75 | 3 Feet |
| DPT-9281 | 17.062 | 16.312 | $1,675.98 | 3 Feet |
| DPT-9295 | 17.125 | 16.375 | $1,682.30 | 3 Feet |
| DPT-9428 | 17.187 | 16.437 | $1,688.53 | 3 Feet |
| DPT-9293 | 17.250 | 16.500 | $1,694.85 | 3 Feet |
| DPT-9292 | 17.312 | 16.562 | $1,701.08 | 3 Feet |
| DPT-9291 | 17.375 | 16.625 | $1,707.40 | 3 Feet |
| DPT-9290 | 17.437 | 16.687 | $1,713.63 | 3 Feet |
| DPT-9289 | 17.500 | 16.750 | $1,719.96 | 3 Feet |
| DPT-9288 | 17.562 | 16.812 | $1,726.21 | 3 Feet |
| DPT-9287 | 17.625 | 16.875 | $1,732.53 | 3 Feet |
| DPT-9286 | 17.687 | 16.937 | $1,738.76 | 3 Feet |
| DPT-9285 | 17.750 | 17.000 | $1,745.08 | 3 Feet |
| DPT-9284 | 17.812 | 17.062 | $1,751.30 | 3 Feet |
| DPT-9283 | 17.875 | 17.125 | $1,757.63 | 3 Feet |
| DPT-9282 | 17.937 | 17.187 | $1,763.86 | 3 Feet |
| DPT-9427 | 18.000 | 17.250 | $1,770.18 | 3 Feet |
| DPT-9426 | 18.062 | 17.312 | $1,776.40 | 3 Feet |
| DPT-9425 | 18.125 | 17.375 | $1,782.73 | 3 Feet |
| DPT-9410 | 18.187 | 17.437 | $1,788.96 | 3 Feet |
| DPT-9423 | 18.250 | 17.500 | $1,795.28 | 3 Feet |
| DPT-9436 | 18.312 | 17.562 | $1,801.51 | 3 Feet |
| DPT-9421 | 18.375 | 17.625 | $1,807.86 | 3 Feet |
| DPT-9420 | 18.437 | 17.687 | $1,814.08 | 3 Feet |
| DPT-9419 | 18.500 | 17.750 | $1,820.41 | 3 Feet |
| DPT-9418 | 18.562 | 17.812 | $1,826.63 | 3 Feet |
| DPT-9417 | 18.625 | 17.875 | $1,832.96 | 3 Feet |
| DPT-9416 | 18.687 | 17.937 | $1,839.18 | 3 Feet |
| DPT-9415 | 18.750 | 18.000 | $1,845.50 | 3 Feet |
| DPT-9414 | 18.812 | 18.062 | $1,851.73 | 3 Feet |
| DPT-9413 | 18.875 | 18.125 | $1,858.06 | 3 Feet |
| DPT-9412 | 18.937 | 18.187 | $1,864.28 | 3 Feet |
| DPT-9411 | 19.000 | 18.250 | $1,870.61 | 3 Feet |
| DPT-9449 | 19.062 | 18.312 | $1,876.83 | 3 Feet |
| DPT-9451 | 19.125 | 18.375 | $1,883.16 | 3 Feet |
| DPT-9424 | 19.187 | 18.437 | $1,889.41 | 3 Feet |
| DPT-9462 | 19.250 | 18.500 | $1,895.73 | 3 Feet |
| DPT-9461 | 19.312 | 18.562 | $1,901.96 | 3 Feet |
| DPT-9460 | 19.375 | 18.625 | $1,908.28 | 3 Feet |
| DPT-9459 | 19.437 | 18.687 | $1,914.50 | 3 Feet |
| DPT-9458 | 19.500 | 18.750 | $1,920.83 | 3 Feet |
| DPT-9457 | 19.562 | 18.812 | $1,927.05 | 3 Feet |
| DPT-9456 | 19.625 | 18.875 | $1,933.38 | 3 Feet |
| DPT-9455 | 19.687 | 18.937 | $1,939.60 | 3 Feet |
| DPT-9454 | 19.750 | 19.000 | $1,945.93 | 3 Feet |
| DPT-9453 | 19.812 | 19.062 | $1,952.16 | 3 Feet |
| DPT-9452 | 19.875 | 19.125 | $1,958.48 | 3 Feet |
| DPT-9437 | 19.937 | 19.187 | $1,964.71 | 3 Feet |
| DPT-9450 | 20.000 | 19.250 | $1,971.05 | 3 Feet |
| DPT-9464 | 20.062 | 19.312 | $1,977.28 | 3 Feet |
| DPT-9448 | 20.125 | 19.375 | $1,983.60 | 3 Feet |
| DPT-9447 | 20.187 | 19.437 | $1,989.83 | 3 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
