G11 High Temperature Glass Tubes .750" Wall Thickness
G11 Glass Tubes - natural (yellow green to amber) Technical Data Sheet
This grade is similar to G10 FR4, with the addition of a higher operating
temperature and some improved mechanical strength at elevated temperatures.
The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11. Therefore, FR5 can be safely substituted when G11 is called for, while G11 can never be substituted where FR5 is called for. (NEMA G-11 certs to MIL-I-24768/3 GEB, IEC 60893-3 Type 2 EP GC 203; FR5 certifies to Mil-I-24768/28 GEB-F.)
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.750" Wall Thickness G11 Tubes |
||||
| Part # | OD (in.) | ID (in.) | Price Per Foot | Minimum Purchase |
|---|---|---|---|---|
| DPT-10499 | 2.000 | 0.500 | $367.66 | 3 Feet |
| DPT-10521 | 2.062 | 0.562 | $384.60 | 3 Feet |
| DPT-10520 | 2.125 | 0.625 | $275.76 | 3 Feet |
| DPT-10519 | 2.187 | 0.687 | $287.41 | 3 Feet |
| DPT-10518 | 2.250 | 0.750 | $299.06 | 3 Feet |
| DPT-10517 | 2.312 | 0.812 | $310.68 | 3 Feet |
| DPT-10507 | 2.375 | 0.875 | $322.33 | 3 Feet |
| DPT-10515 | 2.437 | 0.937 | $333.98 | 3 Feet |
| DPT-10523 | 2.500 | 1.000 | $345.61 | 3 Feet |
| DPT-10513 | 2.562 | 1.062 | $357.16 | 3 Feet |
| DPT-10512 | 2.625 | 1.125 | $368.91 | 3 Feet |
| DPT-10511 | 2.687 | 1.187 | $380.43 | 3 Feet |
| DPT-10510 | 2.750 | 1.250 | $392.18 | 3 Feet |
| DPT-10509 | 2.812 | 1.312 | $403.73 | 3 Feet |
| DPT-10406 | 2.875 | 1.375 | $415.46 | 3 Feet |
| DPT-10716 | 2.937 | 1.437 | $427.01 | 3 Feet |
| DPT-10442 | 3.000 | 1.500 | $438.73 | 3 Feet |
| DPT-10310 | 3.062 | 1.562 | $450.28 | 3 Feet |
| DPT-10309 | 3.125 | 1.625 | $462.03 | 3 Feet |
| DPT-10308 | 3.187 | 1.687 | $473.58 | 3 Feet |
| DPT-10307 | 3.250 | 1.750 | $485.31 | 3 Feet |
| DPT-10306 | 3.312 | 1.812 | $496.86 | 3 Feet |
| DPT-10305 | 3.375 | 1.875 | $508.58 | 3 Feet |
| DPT-10296 | 3.437 | 1.937 | $520.13 | 3 Feet |
| DPT-10303 | 3.500 | 2.000 | $531.88 | 3 Feet |
| DPT-10311 | 3.562 | 2.062 | $543.41 | 3 Feet |
| DPT-10301 | 3.625 | 2.125 | $555.16 | 3 Feet |
| DPT-10300 | 3.687 | 2.187 | $566.71 | 3 Feet |
| DPT-10299 | 3.750 | 2.250 | $578.43 | 3 Feet |
| DPT-10298 | 3.812 | 2.312 | $589.98 | 3 Feet |
| DPT-10297 | 3.875 | 2.375 | $601.71 | 3 Feet |
| DPT-10319 | 3.937 | 2.437 | $613.26 | 3 Feet |
| DPT-10351 | 4.000 | 2.500 | $625.01 | 3 Feet |
| DPT-10304 | 4.062 | 2.562 | $636.56 | 3 Feet |
| DPT-10356 | 4.125 | 2.625 | $648.28 | 3 Feet |
| DPT-10355 | 4.187 | 2.687 | $659.83 | 3 Feet |
| DPT-10354 | 4.250 | 2.750 | $671.56 | 3 Feet |
| DPT-10352 | 4.375 | 2.875 | $694.86 | 3 Feet |
| DPT-10353 | 4.312 | 2.812 | $683.11 | 3 Feet |
| DPT-10312 | 4.437 | 2.937 | $706.38 | 3 Feet |
| DPT-10350 | 4.500 | 3.000 | $718.13 | 3 Feet |
| DPT-10358 | 4.562 | 3.062 | $729.68 | 3 Feet |
| DPT-10318 | 4.625 | 3.125 | $741.41 | 3 Feet |
| DPT-10317 | 4.687 | 3.187 | $752.96 | 3 Feet |
| DPT-10316 | 4.750 | 3.250 | $764.68 | 3 Feet |
| DPT-10315 | 4.812 | 3.312 | $776.23 | 3 Feet |
| DPT-10314 | 4.875 | 3.375 | $787.98 | 3 Feet |
| DPT-10288 | 4.937 | 3.437 | $799.53 | 3 Feet |
| DPT-10357 | 5.000 | 3.500 | $811.26 | 3 Feet |
| DPT-10302 | 5.062 | 3.562 | $822.81 | 3 Feet |
| DPT-10278 | 5.125 | 3.625 | $834.53 | 3 Feet |
| DPT-10277 | 5.187 | 3.687 | $846.08 | 3 Feet |
| DPT-10276 | 5.250 | 3.750 | $857.81 | 3 Feet |
| DPT-10275 | 5.312 | 3.812 | $869.36 | 3 Feet |
| DPT-10274 | 5.375 | 3.875 | $881.11 | 3 Feet |
| DPT-10273 | 5.437 | 3.937 | $892.66 | 3 Feet |
| DPT-10264 | 5.500 | 4.000 | $904.38 | 3 Feet |
| DPT-10271 | 5.562 | 4.062 | $915.93 | 3 Feet |
| DPT-10279 | 5.625 | 4.125 | $927.66 | 3 Feet |
| DPT-10269 | 5.687 | 4.187 | $939.21 | 3 Feet |
| DPT-10268 | 5.750 | 4.250 | $950.96 | 3 Feet |
| DPT-10267 | 5.812 | 4.312 | $962.51 | 3 Feet |
| DPT-10266 | 5.875 | 4.375 | $974.23 | 3 Feet |
| DPT-10286 | 5.937 | 4.437 | $985.78 | 3 Feet |
| DPT-10270 | 6.000 | 4.500 | $997.51 | 3 Feet |
| DPT-10272 | 6.062 | 4.562 | $1,009.06 | 3 Feet |
| DPT-10294 | 6.125 | 4.625 | $1,020.78 | 3 Feet |
| DPT-10293 | 6.187 | 4.687 | $1,032.33 | 3 Feet |
| DPT-10292 | 6.250 | 4.750 | $1,044.08 | 3 Feet |
| DPT-10291 | 6.312 | 4.812 | $1,055.63 | 3 Feet |
| DPT-10290 | 6.375 | 4.875 | $1,171.98 | 3 Feet |
| DPT-10289 | 6.437 | 4.937 | $1,184.68 | 3 Feet |
| DPT-10280 | 6.500 | 5.000 | $1,197.55 | 3 Feet |
| DPT-10287 | 6.562 | 5.062 | $1,210.23 | 3 Feet |
| DPT-10295 | 6.625 | 5.125 | $1,223.13 | 3 Feet |
| DPT-10285 | 6.687 | 5.187 | $1,235.81 | 3 Feet |
| DPT-10284 | 6.750 | 5.250 | $1,248.68 | 3 Feet |
| DPT-10283 | 6.812 | 5.312 | $1,261.36 | 3 Feet |
| DPT-10282 | 6.875 | 5.375 | $1,274.25 | 3 Feet |
| DPT-10281 | 6.937 | 5.437 | $1,286.93 | 3 Feet |
| DPT-10373 | 7.000 | 5.500 | $1,299.80 | 3 Feet |
| DPT-10423 | 7.062 | 5.562 | $1,312.51 | 3 Feet |
| DPT-10313 | 7.125 | 5.625 | $1,325.38 | 3 Feet |
| DPT-10405 | 7.187 | 5.687 | $1,338.06 | 3 Feet |
| DPT-10404 | 7.250 | 5.750 | $1,350.96 | 3 Feet |
| DPT-10403 | 7.312 | 5.812 | $1,363.63 | 3 Feet |
| DPT-10402 | 7.375 | 5.875 | $1,376.51 | 3 Feet |
| DPT-10401 | 7.437 | 5.937 | $1,389.18 | 3 Feet |
| DPT-10392 | 7.500 | 6.000 | $1,402.08 | 3 Feet |
| DPT-10399 | 7.562 | 6.062 | $1,368.35 | 3 Feet |
| DPT-10407 | 7.625 | 6.125 | $1,381.00 | 3 Feet |
| DPT-10397 | 7.687 | 6.187 | $1,393.46 | 3 Feet |
| DPT-10396 | 7.750 | 6.250 | $1,406.13 | 3 Feet |
| DPT-10395 | 7.812 | 6.312 | $1,418.58 | 3 Feet |
| DPT-10394 | 7.875 | 6.375 | $1,431.23 | 3 Feet |
| DPT-10393 | 7.937 | 6.437 | $1,443.68 | 3 Feet |
| DPT-10415 | 8.000 | 6.500 | $1,456.33 | 3 Feet |
| DPT-10417 | 8.062 | 6.562 | $1,468.78 | 3 Feet |
| DPT-10400 | 8.125 | 6.625 | $1,481.43 | 3 Feet |
| DPT-10422 | 8.187 | 6.687 | $1,493.90 | 3 Feet |
| DPT-10421 | 8.250 | 6.750 | $1,506.56 | 3 Feet |
| DPT-10420 | 8.312 | 6.812 | $1,519.01 | 3 Feet |
| DPT-10419 | 8.375 | 6.875 | $1,531.66 | 3 Feet |
| DPT-10418 | 8.437 | 6.937 | $1,544.11 | 3 Feet |
| DPT-10408 | 8.500 | 7.000 | $1,556.75 | 3 Feet |
| DPT-10416 | 8.562 | 7.062 | $1,569.23 | 3 Feet |
| DPT-10424 | 8.625 | 7.125 | $1,581.88 | 3 Feet |
| DPT-10414 | 8.687 | 7.187 | $1,594.33 | 3 Feet |
| DPT-10413 | 8.750 | 7.250 | $1,606.98 | 3 Feet |
| DPT-10412 | 8.812 | 7.312 | $1,619.43 | 3 Feet |
| DPT-10411 | 8.875 | 7.375 | $1,632.08 | 3 Feet |
| DPT-10410 | 8.937 | 7.437 | $1,644.53 | 3 Feet |
| DPT-10409 | 9.000 | 7.500 | $1,657.21 | 3 Feet |
| DPT-10390 | 9.062 | 7.562 | $1,669.66 | 3 Feet |
| DPT-10365 | 9.125 | 7.625 | $1,682.30 | 3 Feet |
| DPT-10398 | 9.187 | 7.687 | $1,694.75 | 3 Feet |
| DPT-10372 | 9.250 | 7.750 | $1,707.40 | 3 Feet |
| DPT-10371 | 9.312 | 7.812 | $1,719.85 | 3 Feet |
| DPT-10370 | 9.375 | 7.875 | $1,732.53 | 3 Feet |
| DPT-10369 | 9.437 | 7.937 | $1,744.98 | 3 Feet |
| DPT-10368 | 9.500 | 8.000 | $1,757.63 | 3 Feet |
| DPT-10366 | 9.625 | 8.125 | $1,782.73 | 3 Feet |
| DPT-10374 | 9.687 | 8.187 | $1,795.18 | 3 Feet |
| DPT-10364 | 9.750 | 8.250 | $1,807.86 | 3 Feet |
| DPT-10363 | 9.812 | 8.312 | $1,820.31 | 3 Feet |
| DPT-10362 | 9.875 | 8.375 | $1,832.96 | 3 Feet |
| DPT-10361 | 9.937 | 8.437 | $1,845.41 | 3 Feet |
| DPT-10360 | 10.000 | 8.500 | $1,858.06 | 3 Feet |
| DPT-10382 | 10.062 | 8.562 | $1,870.50 | 3 Feet |
| DPT-9782 | 10.125 | 8.625 | $1,883.16 | 3 Feet |
| DPT-10384 | 10.187 | 8.687 | $1,895.63 | 3 Feet |
| DPT-10367 | 10.250 | 8.750 | $1,908.28 | 3 Feet |
| DPT-10389 | 10.312 | 8.812 | $1,920.73 | 3 Feet |
| DPT-10388 | 10.375 | 8.875 | $1,933.38 | 3 Feet |
| DPT-10387 | 10.437 | 8.937 | $1,945.83 | 3 Feet |
| DPT-10386 | 10.500 | 9.000 | $1,958.48 | 3 Feet |
| DPT-10385 | 10.562 | 9.062 | $1,970.96 | 3 Feet |
| DPT-10375 | 10.625 | 9.125 | $1,983.60 | 3 Feet |
| DPT-10383 | 10.687 | 9.187 | $1,996.05 | 3 Feet |
| DPT-10391 | 10.750 | 9.250 | $2,008.71 | 3 Feet |
| DPT-10381 | 10.812 | 9.312 | $2,021.15 | 3 Feet |
| DPT-10380 | 10.875 | 9.375 | $2,033.80 | 3 Feet |
| DPT-10379 | 10.937 | 9.437 | $2,046.26 | 3 Feet |
| DPT-10378 | 11.000 | 9.500 | $2,058.93 | 3 Feet |
| DPT-10377 | 11.062 | 9.562 | $2,071.38 | 3 Feet |
| DPT-10376 | 11.125 | 9.625 | $2,084.03 | 3 Feet |
| DPT-8674 | 11.187 | 9.687 | $2,096.48 | 3 Feet |
| DPT-8673 | 11.250 | 9.750 | $2,109.13 | 3 Feet |
| DPT-8672 | 11.312 | 9.812 | $2,121.58 | 3 Feet |
| DPT-8671 | 11.375 | 9.875 | $2,134.25 | 3 Feet |
| DPT-8670 | 11.437 | 9.937 | $2,146.71 | 3 Feet |
| DPT-8669 | 11.500 | 10.000 | $2,159.36 | 3 Feet |
| DPT-8668 | 11.562 | 10.062 | $2,171.81 | 3 Feet |
| DPT-8667 | 11.625 | 10.125 | $2,184.46 | 3 Feet |
| DPT-8656 | 11.687 | 10.187 | $2,196.90 | 3 Feet |
| DPT-8665 | 11.750 | 10.250 | $2,209.58 | 3 Feet |
| DPT-8675 | 11.812 | 10.312 | $2,222.03 | 3 Feet |
| DPT-8663 | 11.875 | 10.375 | $2,234.68 | 3 Feet |
| DPT-8662 | 11.937 | 10.437 | $2,247.13 | 3 Feet |
| DPT-8661 | 12.000 | 10.500 | $2,259.78 | 3 Feet |
| DPT-8660 | 12.062 | 10.562 | $2,272.23 | 3 Feet |
| DPT-8659 | 12.125 | 10.625 | $2,284.88 | 3 Feet |
| DPT-8658 | 12.187 | 10.687 | $2,297.36 | 3 Feet |
| DPT-8684 | 12.250 | 10.750 | $2,310.01 | 3 Feet |
| DPT-8664 | 12.312 | 10.812 | $2,322.46 | 3 Feet |
| DPT-8666 | 12.375 | 10.875 | $2,335.11 | 3 Feet |
| DPT-8694 | 12.437 | 10.937 | $2,347.56 | 3 Feet |
| DPT-8693 | 12.500 | 11.000 | $2,360.21 | 3 Feet |
| DPT-8692 | 12.562 | 11.062 | $2,372.68 | 3 Feet |
| DPT-8691 | 12.625 | 11.125 | $2,385.33 | 3 Feet |
| DPT-8690 | 12.687 | 11.187 | $2,397.78 | 3 Feet |
| DPT-8689 | 12.750 | 11.250 | $2,410.43 | 3 Feet |
| DPT-8688 | 12.812 | 11.312 | $2,422.88 | 3 Feet |
| DPT-8687 | 12.875 | 11.375 | $2,435.53 | 3 Feet |
| DPT-8676 | 12.937 | 11.437 | $2,447.98 | 3 Feet |
| DPT-8685 | 13.000 | 11.500 | $2,460.65 | 3 Feet |
| DPT-8695 | 13.062 | 11.562 | $2,473.11 | 3 Feet |
| DPT-8683 | 13.125 | 11.625 | $2,485.76 | 3 Feet |
| DPT-8682 | 13.187 | 11.687 | $2,498.21 | 3 Feet |
| DPT-8681 | 13.250 | 11.750 | $2,510.85 | 3 Feet |
| DPT-8680 | 13.312 | 11.812 | $2,523.31 | 3 Feet |
| DPT-8679 | 13.375 | 11.875 | $2,535.98 | 3 Feet |
| DPT-8678 | 13.437 | 11.937 | $2,548.43 | 3 Feet |
| DPT-8677 | 13.500 | 12.000 | $2,561.08 | 3 Feet |
| DPT-8646 | 13.562 | 12.062 | $2,573.53 | 3 Feet |
| DPT-8617 | 13.625 | 12.125 | $2,586.18 | 3 Feet |
| DPT-8657 | 13.687 | 12.187 | $2,598.63 | 3 Feet |
| DPT-8633 | 13.750 | 12.250 | $2,611.31 | 3 Feet |
| DPT-8632 | 13.812 | 12.312 | $2,623.76 | 3 Feet |
| DPT-8631 | 13.875 | 12.375 | $2,636.40 | 3 Feet |
| DPT-8630 | 13.937 | 12.437 | $2,648.86 | 3 Feet |
| DPT-8629 | 14.000 | 12.500 | $2,661.50 | 3 Feet |
| DPT-8628 | 14.062 | 12.562 | $2,673.96 | 3 Feet |
| DPT-8627 | 14.125 | 12.625 | $2,686.60 | 3 Feet |
| DPT-8616 | 14.187 | 12.687 | $2,699.08 | 3 Feet |
| DPT-8625 | 14.250 | 12.750 | $2,711.73 | 3 Feet |
| DPT-8635 | 14.312 | 12.812 | $2,724.18 | 3 Feet |
| DPT-8623 | 14.375 | 12.875 | $2,736.83 | 3 Feet |
| DPT-8622 | 14.437 | 12.937 | $2,749.28 | 3 Feet |
| DPT-8621 | 14.500 | 13.000 | $2,761.93 | 3 Feet |
| DPT-8620 | 14.562 | 13.062 | $2,774.40 | 3 Feet |
| DPT-8619 | 14.625 | 13.125 | $2,787.06 | 3 Feet |
| DPT-8618 | 14.687 | 13.187 | $2,799.51 | 3 Feet |
| DPT-8644 | 14.750 | 13.250 | $2,812.15 | 3 Feet |
| DPT-8624 | 14.812 | 13.312 | $2,824.60 | 3 Feet |
| DPT-8626 | 14.875 | 13.375 | $2,837.25 | 3 Feet |
| DPT-8654 | 14.937 | 13.437 | $2,849.71 | 3 Feet |
| DPT-8653 | 15.000 | 13.500 | $2,862.38 | 3 Feet |
| DPT-8652 | 15.062 | 13.562 | $2,874.83 | 3 Feet |
| DPT-8651 | 15.125 | 13.625 | $2,887.48 | 3 Feet |
| DPT-8650 | 15.187 | 13.687 | $2,899.93 | 3 Feet |
| DPT-8649 | 15.250 | 13.750 | $2,912.58 | 3 Feet |
| DPT-8648 | 15.312 | 13.812 | $2,925.03 | 3 Feet |
| DPT-8647 | 15.375 | 13.875 | $2,937.71 | 3 Feet |
| DPT-8636 | 15.437 | 13.937 | $2,950.15 | 3 Feet |
| DPT-8645 | 15.500 | 14.000 | $2,962.81 | 3 Feet |
| DPT-8655 | 15.562 | 14.062 | $2,975.25 | 3 Feet |
| DPT-8643 | 15.625 | 14.125 | $2,987.91 | 3 Feet |
| DPT-8642 | 15.687 | 14.187 | $3,000.35 | 3 Feet |
| DPT-8641 | 15.750 | 14.250 | $3,013.03 | 3 Feet |
| DPT-8640 | 15.812 | 14.312 | $3,025.48 | 3 Feet |
| DPT-8639 | 15.875 | 14.375 | $3,038.13 | 3 Feet |
| DPT-8638 | 15.937 | 14.437 | $3,050.58 | 3 Feet |
| DPT-8714 | 16.000 | 14.500 | $3,063.23 | 3 Feet |
| DPT-8634 | 16.062 | 14.562 | $3,075.68 | 3 Feet |
| DPT-8686 | 16.125 | 14.625 | $3,088.33 | 3 Feet |
| DPT-8754 | 16.187 | 14.687 | $3,100.81 | 3 Feet |
| DPT-8753 | 16.250 | 14.750 | $3,113.46 | 3 Feet |
| DPT-8752 | 16.312 | 14.812 | $3,125.90 | 3 Feet |
| DPT-8751 | 16.375 | 14.875 | $3,138.56 | 3 Feet |
| DPT-8750 | 16.437 | 14.937 | $3,151.00 | 3 Feet |
| DPT-8749 | 16.500 | 15.000 | $3,163.66 | 3 Feet |
| DPT-8747 | 16.625 | 15.125 | $3,188.78 | 3 Feet |
| DPT-8748 | 16.562 | 15.062 | $3,176.13 | 3 Feet |
| DPT-8736 | 16.687 | 15.187 | $3,201.23 | 3 Feet |
| DPT-8745 | 16.750 | 15.250 | $3,213.88 | 3 Feet |
| DPT-8755 | 16.812 | 15.312 | $3,226.33 | 3 Feet |
| DPT-8743 | 16.875 | 15.375 | $3,238.98 | 3 Feet |
| DPT-8742 | 16.937 | 15.437 | $3,251.46 | 3 Feet |
| DPT-8741 | 17.000 | 15.500 | $3,264.10 | 3 Feet |
| DPT-8740 | 17.062 | 15.562 | $3,276.56 | 3 Feet |
| DPT-8739 | 17.125 | 15.625 | $3,289.21 | 3 Feet |
| DPT-8738 | 17.187 | 15.687 | $3,301.66 | 3 Feet |
| DPT-8764 | 17.250 | 15.750 | $3,314.31 | 3 Feet |
| DPT-8744 | 17.312 | 15.812 | $3,326.76 | 3 Feet |
| DPT-8746 | 17.375 | 15.875 | $3,339.43 | 3 Feet |
| DPT-8774 | 17.437 | 15.937 | $3,351.88 | 3 Feet |
| DPT-8773 | 17.500 | 16.000 | $3,364.53 | 3 Feet |
| DPT-8772 | 17.562 | 16.062 | $3,376.98 | 3 Feet |
| DPT-8771 | 17.625 | 16.125 | $3,389.63 | 3 Feet |
| DPT-8770 | 17.687 | 16.187 | $3,402.08 | 3 Feet |
| DPT-8769 | 17.750 | 16.250 | $3,414.75 | 3 Feet |
| DPT-8768 | 17.812 | 16.312 | $3,427.21 | 3 Feet |
| DPT-8767 | 17.875 | 16.375 | $3,439.86 | 3 Feet |
| DPT-8756 | 17.937 | 16.437 | $3,452.31 | 3 Feet |
| DPT-8765 | 18.000 | 16.500 | $3,464.96 | 3 Feet |
| DPT-8775 | 18.062 | 16.562 | $3,477.41 | 3 Feet |
| DPT-8763 | 18.125 | 16.625 | $3,490.06 | 3 Feet |
| DPT-8762 | 18.187 | 16.687 | $3,502.53 | 3 Feet |
| DPT-8761 | 18.250 | 16.750 | $3,515.18 | 3 Feet |
| DPT-8760 | 18.312 | 16.812 | $3,527.63 | 3 Feet |
| DPT-8759 | 18.375 | 16.875 | $3,540.28 | 3 Feet |
| DPT-8758 | 18.437 | 16.937 | $3,552.73 | 3 Feet |
| DPT-8757 | 18.500 | 17.000 | $3,565.38 | 3 Feet |
| DPT-8726 | 18.562 | 17.062 | $3,577.85 | 3 Feet |
| DPT-8697 | 18.625 | 17.125 | $3,590.51 | 3 Feet |
| DPT-8737 | 18.687 | 17.187 | $3,602.96 | 3 Feet |
| DPT-8713 | 18.750 | 17.250 | $3,615.61 | 3 Feet |
| DPT-8712 | 18.812 | 17.312 | $3,628.06 | 3 Feet |
| DPT-8711 | 18.875 | 17.375 | $3,640.71 | 3 Feet |
| DPT-8710 | 18.937 | 17.437 | $3,653.18 | 3 Feet |
| DPT-8709 | 19.000 | 17.500 | $3,665.83 | 3 Feet |
| DPT-8708 | 19.062 | 17.562 | $3,678.28 | 3 Feet |
| DPT-8707 | 19.125 | 17.625 | $3,690.93 | 3 Feet |
| DPT-8696 | 19.187 | 17.687 | $3,703.38 | 3 Feet |
| DPT-8705 | 19.250 | 17.750 | $3,716.03 | 3 Feet |
| DPT-8715 | 19.312 | 17.812 | $3,728.48 | 3 Feet |
| DPT-8703 | 19.375 | 17.875 | $3,741.16 | 3 Feet |
| DPT-8702 | 19.437 | 17.937 | $3,753.61 | 3 Feet |
| DPT-8701 | 19.500 | 18.000 | $3,766.26 | 3 Feet |
| DPT-8700 | 19.562 | 18.062 | $3,778.71 | 3 Feet |
| DPT-8699 | 19.625 | 18.125 | $3,791.36 | 3 Feet |
| DPT-8698 | 19.687 | 18.187 | $3,803.81 | 3 Feet |
| DPT-8724 | 19.750 | 18.250 | $3,816.48 | 3 Feet |
| DPT-8704 | 19.812 | 18.312 | $3,828.93 | 3 Feet |
| DPT-8706 | 19.875 | 18.375 | $3,841.58 | 3 Feet |
| DPT-8734 | 19.937 | 18.437 | $3,854.03 | 3 Feet |
| DPT-8733 | 20.000 | 18.500 | $3,866.68 | 3 |
| nominal inches, | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
