Paper X, XX, XXX Phenolic Laminate Tubes 1/4" Wall Thickness
Paper X/XX/XXX Paper Reinforced Phenolic
- natural (tan)
Technical Data Sheet
This grade is composed of a paper base impregnated with a phenolic resin binder.
It has good electric strength properties with fair mechanical strength.
Outstanding for use as template material and or backup material.
NEMA
X certs to MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
NEMA XX certs to
MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
NEMA XXX certs to
MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201
NEMA grades X,
XX and XXX Paper Reinforced Phenolic -- natural color is typically light tan to
brown. These grades are composed of a paper base impregnated with a phenolic
resin binder. (Phenolics are the oldest, best-known general purpose thermoset
resins. They are among the lowest in cost and easiest to process. Phenolics are
quite adequate for a fair percentage of electrical applications. Generally
speaking, they are not equivalent to epoxies in resistance to moisture,
humidity, dimensional stability, shrinkage and retention of electrical
properties in extreme environments.) The paper reinforced phenolic has good
electric strength properties with fair mechanical strength and are outstanding
for use as template material and/or back-up material.
Click Here for X, XX, XXX or Sheets, Rods
| Select X, XX, XXX Tubing Wall Thickness | ||
| | ||
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.250" Wall Thickness Paper Phenolics Tubes |
||||
| Part # | OD (in.) | ID (in.) | Minimum Purchase | Price Per Foot |
|---|---|---|---|---|
| DPT-21720 | .938 | .437 | 24 Feet | $60.18 |
| DPT-1884 | 1.000 | .500 | 21 Feet | $64.26 |
| DPT-1889 | 1.062 | .562 | 21 Feet | $68.33 |
| DPT-1895 | 1.125 | .625 | 21 Feet | $72.41 |
| DPT-21727 | 1.187 | .687 | 18 Feet | $76.48 |
| DPT-1904 | 1.250 | .750 | 18 Feet | $80.55 |
| DPT-21752 | 1.312 | .812 | 18 Feet | $84.63 |
| DPT-1910 | 1.375 | .875 | 15 Feet | $88.71 |
| DPT-21750 | 1.437 | .937 | 15 Feet | $92.78 |
| DPT-1916 | 1.500 | 1.000 | 15 Feet | $96.86 |
| DPT-21748 | 1.562 | 1.062 | 15 Feet | $100.90 |
| DPT-21747 | 1.625 | 1.125 | 15 Feet | $105.01 |
| DPT-21736 | 1.688 | 1.187 | 15 Feet | $109.06 |
| DPT-1920 | 1.750 | 1.250 | 12 Feet | $124.48 |
| DPT-21754 | 1.812 | 1.312 | 12 Feet | $128.93 |
| DPT-21743 | 1.875 | 1.375 | 12 Feet | $133.46 |
| DPT-21742 | 1.937 | 1.437 | 12 Feet | $137.91 |
| DPT-1924 | 2.000 | 1.500 | 12 Feet | $142.43 |
| DPT-21740 | 2.062 | 1.562 | 12 Feet | $146.88 |
| DPT-21739 | 2.125 | 1.625 | 9 Feet | $151.38 |
| DPT-21738 | 2.188 | 1.687 | 9 Feet | $155.83 |
| DPT-1929 | 2.250 | 1.750 | 9 Feet | $160.36 |
| DPT-21708 | 2.312 | 1.812 | 9 Feet | $164.81 |
| DPT-21680 | 2.375 | 1.875 | 9 Feet | $169.33 |
| DPT-21718 | 2.437 | 1.937 | 9 Feet | $173.78 |
| DPT-1934 | 2.500 | 2.000 | 9 Feet | $178.28 |
| DPT-21694 | 2.562 | 2.062 | 9 Feet | $182.73 |
| DPT-21693 | 2.625 | 2.125 | 9 Feet | $187.26 |
| DPT-21692 | 2.688 | 2.187 | 9 Feet | $191.71 |
| DPT-1939 | 2.750 | 2.250 | 9 Feet | $196.23 |
| DPT-21690 | 2.812 | 2.312 | 9 Feet | $200.68 |
| DPT-21679 | 2.875 | 2.375 | 9 Feet | $205.18 |
| DPT-21688 | 2.937 | 2.437 | 9 Feet | $209.63 |
| DPT-1944 | 3.000 | 2.500 | 9 Feet | $214.16 |
| DPT-21686 | 3.062 | 2.562 | 9 Feet | $218.61 |
| DPT-21685 | 3.125 | 2.625 | 6 Feet | $223.13 |
| DPT-21684 | 3.188 | 2.687 | 6 Feet | $227.58 |
| DPT-1949 | 3.250 | 2.750 | 6 Feet | $232.08 |
| DPT-21682 | 3.312 | 2.812 | 6 Feet | $236.53 |
| DPT-21681 | 3.375 | 2.875 | 6 Feet | $241.06 |
| DPT-21706 | 3.437 | 2.937 | 6 Feet | $245.51 |
| DPT-1954 | 3.500 | 3.000 | 6 Feet | $250.03 |
| DPT-21689 | 3.562 | 3.062 | 6 Feet | $254.48 |
| DPT-21715 | 3.625 | 3.125 | 6 Feet | $258.98 |
| DPT-21714 | 3.687 | 3.187 | 6 Feet | $263.43 |
| DPT-1959 | 3.750 | 3.250 | 6 Feet | $267.96 |
| DPT-21712 | 3.812 | 3.312 | 6 Feet | $272.41 |
| DPT-21711 | 3.875 | 3.375 | 6 Feet | $276.93 |
| DPT-21710 | 3.937 | 3.437 | 6 Feet | $281.38 |
| DPT-1964 | 4.000 | 3.500 | 6 Feet | $285.88 |
| DPT-21698 | 4.062 | 3.562 | 6 Feet | $290.33 |
| DPT-21707 | 4.125 | 3.625 | 6 Feet | $294.85 |
| DPT-21716 | 4.187 | 3.687 | 6 Feet | $299.31 |
| DPT-1969 | 4.250 | 3.750 | 6 Feet | $303.83 |
| DPT-21704 | 4.312 | 3.812 | 6 Feet | $308.28 |
| DPT-21703 | 4.375 | 3.875 | 6 Feet | $312.78 |
| DPT-21702 | 4.437 | 3.937 | 6 Feet | $317.23 |
| DPT-1974 | 4.500 | 4.000 | 6 Feet | $321.75 |
| DPT-21700 | 4.562 | 4.062 | 6 Feet | $326.21 |
| DPT-21699 | 4.625 | 4.125 | 6 Feet | $330.73 |
| DPT-21354 | 4.687 | 4.187 | 6 Feet | $335.18 |
| DPT-22693BQ | 4.750 | 4.250 | 6 Feet | $339.68 |
| DPT-23007 | 4.812 | 4.312 | 6 Feet | $344.13 |
| DPT-23008 | 4.875 | 4.438 | 6 Feet | $353.11 |
| DPT-1979 | 5.000 | 4.500 | 6 Feet | $357.63 |
| DPT-23011 | 5.062 | 4.562 | 6 Feet | $362.08 |
| DPT-23012 | 5.125 | 4.625 | 6 Feet | $366.58 |
| DPT-23013 | 5.187 | 4.687 | 6 Feet | $371.03 |
| DPT-23014 | 5.250 | 4.750 | 6 Feet | $375.56 |
| DPT-23024 | 5.312 | 4.812 | 6 Feet | $380.01 |
| DPT-23016 | 5.375 | 4.875 | 6 Feet | $384.53 |
| DPT-23005 | 5.437 | 4.937 | 6 Feet | $388.98 |
| DPT-1984 | 5.500 | 5.000 | 6 Feet | $393.48 |
| DPT-23018 | 5.562 | 5.062 | 6 Feet | $397.93 |
| DPT-23019 | 5.625 | 5.125 | 6 Feet | $402.46 |
| DPT-23026 | 5.688 | 5.187 | 6 Feet | $406.91 |
| DPT-23034 | 5.750 | 5.250 | 6 Feet | $411.43 |
| DPT-23033 | 5.812 | 5.313 | 6 Feet | $415.88 |
| DPT-23032 | 5.875 | 5.375 | 6 Feet | $420.38 |
| DPT-23031 | 5.938 | 5.437 | 6 Feet | $424.83 |
| DPT-1990 | 6.000 | 5.500 | 6 Feet | $429.36 |
| DPT-23029 | 6.063 | 6.562 | 6 Feet | $433.81 |
| DPT-23028 | 6.125 | 5.625 | 6 Feet | $438.33 |
| DPT-23027 | 6.187 | 5.687 | 3 Feet | $442.78 |
| DPT-23020 | 6.250 | 5.750 | 3 Feet | $447.28 |
| DPT-23025 | 6.312 | 5.812 | 3 Feet | $451.73 |
| DPT-23023 | 6.375 | 5.875 | 3 Feet | $456.26 |
| DPT-23022 | 6.437 | 5.937 | 3 Feet | $460.71 |
| DPT-1996 | 6.500 | 6.000 | 3 Feet | $465.23 |
| DPT-22477Q | 6.562 | 6.062 | 6 Feet | $429.43 |
| DPT-23006 | 6.625 | 6.125 | 6 Feet | $433.71 |
| DPT-22934 | 6.688 | 6.187 | 6 Feet | $437.93 |
| DPT-22946BQ | 6.750 | 6.250 | 6 Feet | $442.23 |
| DPT-22947 | 6.812 | 6.312 | 3 Feet | $446.43 |
| DPT-22948BQ | 6.875 | 6.375 | 3 Feet | $450.73 |
| DPT-22949BQ | 6.938 | 6.437 | 3 Feet | $454.93 |
| DPT-22950 | 7.000 | 6.500 | 3 Feet | $459.23 |
| DPT-22951 | 7.062 | 6.562 | 3 Feet | $463.46 |
| DPT-22952 | 7.125 | 6.625 | 3 Feet | $467.73 |
| DPT-22964 | 7.187 | 6.687 | 3 Feet | $471.96 |
| DPT-22954BQ | 7.250 | 6.750 | 3 Feet | $476.23 |
| DPT-22945 | 7.312 | 6.812 | 3 Feet | $480.46 |
| DPT-22956 | 7.375 | 6.875 | 3 Feet | $484.73 |
| DPT-22957 | 7.437 | 6.938 | 3 Feet | $488.96 |
| DPT-22958 | 7.500 | 7.000 | 3 Feet | $493.23 |
| DPT-22959BQ | 7.562 | 7.062 | 3 Feet | $497.46 |
| DPT-22960 | 7.625 | 7.125 | 3 Feet | $501.73 |
| DPT-22961 | 7.688 | 7.187 | 3 Feet | $505.96 |
| DPT-22962 | 7.750 | 7.250 | 3 Feet | $510.23 |
| DPT-22936 | 7.812 | 7.312 | 3 Feet | $514.46 |
| DPT-22955BQ | 7.875 | 7.375 | 3 Feet | $518.76 |
| DPT-22953BQ | 7.938 | 7.437 | 3 Feet | $522.96 |
| DPT-22927 | 8.000 | 7.500 | 3 Feet | $527.26 |
| DPT-22928 | 8.062 | 7.562 | 3 Feet | $531.46 |
| DPT-22929BQ | 8.125 | 7.625 | 3 Feet | $535.76 |
| DPT-22930 | 8.188 | 7.687 | 3 Feet | $539.96 |
| DPT-22931BQ | 8.250 | 7.750 | 3 Feet | $544.26 |
| DPT-22932 | 8.312 | 7.812 | 3 Feet | $548.48 |
| DPT-22933 | 8.375 | 7.875 | 3 Feet | $552.76 |
| DPT-22944BQ | 8.437 | 7.937 | 3 Feet | $556.98 |
| DPT-22935 | 8.500 | 8.000 | 3 Feet | $561.26 |
| DPT-22937BQ | 8.625 | 8.125 | 3 Feet | $569.76 |
| DPT-22938BQ | 8.688 | 8.187 | 3 Feet | $573.98 |
| DPT-22939 | 8.750 | 8.250 | 3 Feet | $578.26 |
| DPT-22940BQ | 8.812 | 8.312 | 3 Feet | $582.48 |
| DPT-22986BQ | 8.875 | 8.375 | 3 Feet | $586.76 |
| DPT-22941 | 8.938 | 8.437 | 3 Feet | $590.98 |
| DPT-23015 | 9.000 | 8.500 | 3 Feet | $595.28 |
| DPT-22943BQ | 9.062 | 8.562 | 3 Feet | $599.48 |
| DPT-22966 | 9.125 | 8.625 | 3 Feet | $603.78 |
| DPT-22995 | 9.188 | 8.687 | 3 Feet | $607.98 |
| DPT-22963 | 9.250 | 8.750 | 3 Feet | $612.28 |
| DPT-22987BQ | 9.312 | 8.812 | 3 Feet | $616.48 |
| DPT-22988 | 9.375 | 8.875 | 3 Feet | $620.78 |
| DPT-22989 | 9.437 | 8.937 | 3 Feet | $625.01 |
| DPT-22990 | 9.500 | 9.000 | 3 Feet | $629.28 |
| DPT-22991BQ | 9.563 | 9.062 | 3 Feet | $633.51 |
| DPT-22992 | 9.625 | 9.125 | 3 Feet | $637.78 |
| DPT-23004 | 9.688 | 9.187 | 3 Feet | $642.01 |
| DPT-22994Q | 9.750 | 9.250 | 3 Feet | $646.28 |
| DPT-22985 | 9.812 | 9.312 | 3 Feet | $650.51 |
| DPT-22996 | 9.875 | 9.375 | 3 Feet | $654.78 |
| DPT-22997 | 9.937 | 9.437 | 3 Feet | $659.01 |
| DPT-22998 | 10.000 | 9.500 | 3 Feet | $663.28 |
| DPT-22999BQ | 10.062 | 9.562 | 3 Feet | $667.51 |
| DPT-23000 | 10.125 | 9.625 | 3 Feet | $671.81 |
| DPT-23001 | 10.187 | 9.687 | 3 Feet | $676.01 |
| DPT-23002 | 10.250 | 9.750 | 3 Feet | $680.31 |
| DPT-23003 | 10.313 | 9.813 | 3 Feet | $684.51 |
| DPT-22975 | 10.375 | 9.875 | 3 Feet | $688.81 |
| DPT-22973 | 10.437 | 9.937 | 3 Feet | $693.01 |
| DPT-22993 | 10.500 | 10.000 | 3 Feet | $697.31 |
| DPT-22967BQ | 10.563 | 10.062 | 3 Feet | $701.53 |
| DPT-22968 | 10.625 | 10.125 | 3 Feet | $705.81 |
| DPT-22969BQ | 10.688 | 10.187 | 3 Feet | $710.03 |
| DPT-22970BQ | 10.750 | 10.250 | 3 Feet | $714.31 |
| DPT-22971 | 10.813 | 10.312 | 3 Feet | $718.53 |
| DPT-22972 | 10.875 | 10.375 | 3 Feet | $722.81 |
| DPT-22984 | 10.937 | 10.437 | 3 Feet | $727.03 |
| DPT-22974BQ | 11.000 | 10.500 | 3 Feet | $731.31 |
| DPT-22965BQ | 11.062 | 10.562 | 3 Feet | $735.53 |
| DPT-22976 | 11.125 | 10.625 | 3 Feet | $739.81 |
| DPT-22977 | 11.188 | 10.687 | 3 Feet | $744.03 |
| DPT-22978 | 11.250 | 10.750 | 3 Feet | $748.31 |
| DPT-22979BQ | 11.313 | 10.812 | 3 Feet | $752.53 |
| DPT-22980BQ | 11.375 | 10.875 | 3 Feet | $756.83 |
| DPT-22981BQ | 11.437 | 10.937 | 3 Feet | $761.03 |
| DPT-22982BQ | 11.500 | 11.000 | 3 Feet | $765.33 |
| DPT-22983BQ | 11.562 | 11.062 | 3 Feet | $769.53 |
| DPT-22868BQ | 11.625 | 11.125 | 3 Feet | $773.83 |
| DPT-22337Q | 11.687 | 11.187 | 3 Feet | $778.03 |
| DPT-22436 | 11.750 | 11.250 | 3 Feet | $1,164.71 |
| DPT-22435 | 11.812 | 11.312 | 3 Feet | $1,177.58 |
| DPT-22434 | 11.875 | 11.375 | 3 Feet | $1,190.68 |
| DPT-22433 | 11.937 | 11.437 | 3 Feet | $1,203.55 |
| DPT-22432 | 12.000 | 11.500 | 3 Feet | $1,811.15 |
| DPT-22431 | 12.062 | 11.562 | 3 Feet | $1,229.53 |
| DPT-22421 | 12.125 | 11.625 | 3 Feet | $995.78 |
| DPT-22429 | 12.187 | 11.687 | 3 Feet | $1,255.50 |
| DPT-22437 | 12.250 | 11.750 | 3 Feet | $1,151.61 |
| DPT-22427 | 12.313 | 11.812 | 3 Feet | $1,281.48 |
| DPT-22426 | 12.375 | 11.875 | 3 Feet | $1,294.55 |
| DPT-22425 | 12.437 | 11.937 | 3 Feet | $1,307.46 |
| DPT-22424 | 12.500 | 12.000 | 3 Feet | $833.36 |
| DPT-22423 | 12.562 | 12.062 | 3 Feet | $1,333.41 |
| DPT-22445 | 12.625 | 12.125 | 3 Feet | $841.86 |
| DPT-22428 | 12.687 | 12.187 | 3 Feet | $1,268.58 |
| DPT-22430 | 12.750 | 12.250 | 3 Feet | $1,086.78 |
| DPT-22453Q | 12.812 | 12.312 | 3 Feet | $854.56 |
| DPT-22452Q | 12.875 | 12.375 | 3 Feet | $858.86 |
| DPT-22451 | 12.937 | 12.437 | 3 Feet | $863.08 |
| DPT-22450Q | 13.000 | 12.500 | 3 Feet | $867.36 |
| DPT-22449 | 13.062 | 12.562 | 3 Feet | $871.58 |
| DPT-22448Q | 13.125 | 12.625 | 3 Feet | $875.86 |
| DPT-22438 | 13.187 | 12.687 | 3 Feet | $1,138.73 |
| DPT-22446Q | 13.250 | 12.750 | 3 Feet | $884.36 |
| DPT-22454Q | 13.312 | 12.813 | 3 Feet | $888.58 |
| DPT-22444Q | 13.375 | 12.875 | 3 Feet | $892.86 |
| DPT-22443Q | 13.437 | 12.937 | 3 Feet | $897.08 |
| DPT-22746BQ | 13.500 | 13.000 | 3 Feet | $901.36 |
| DPT-22442 | 13.562 | 13.062 | 3 Feet | $1,785.66 |
| DPT-22876 | 13.625 | 13.125 | 3 Feet | $909.88 |
| DPT-22441Q | 13.687 | 13.187 | 3 Feet | $914.08 |
| DPT-22440 | 13.750 | 13.250 | 3 Feet | $1,242.61 |
| DPT-22439 | 13.812 | 13.312 | 3 Feet | $1,125.63 |
| DPT-22413 | 13.875 | 13.375 | 3 Feet | $926.88 |
| DPT-22388 | 13.937 | 13.437 | 3 Feet | $1,734.63 |
| DPT-22422 | 14.000 | 13.500 | 3 Feet | $935.38 |
| DPT-22401 | 14.062 | 13.562 | 3 Feet | $1,568.73 |
| DPT-22400 | 14.125 | 13.625 | 3 Feet | $1,581.58 |
| DPT-22476Q | 14.187 | 13.687 | 3 Feet | $948.11 |
| DPT-22399 | 14.250 | 13.750 | 3 Feet | $1,594.23 |
| DPT-22478Q | 14.312 | 13.812 | 3 Feet | $956.61 |
| DPT-22398 | 14.375 | 13.875 | 3 Feet | $1,607.08 |
| DPT-22397 | 14.437 | 13.937 | 3 Feet | $1,619.73 |
| DPT-22387 | 14.500 | 14.000 | 3 Feet | $1,747.28 |
| DPT-22395 | 14.562 | 14.062 | 3 Feet | $1,645.26 |
| DPT-22403 | 14.625 | 14.125 | 3 Feet | $969.81 |
| DPT-22393 | 14.687 | 14.187 | 3 Feet | $1,670.75 |
| DPT-22392 | 14.750 | 14.250 | 3 Feet | $1,530.56 |
| DPT-22391 | 14.812 | 14.312 | 3 Feet | $1,696.26 |
| DPT-22390 | 14.875 | 14.375 | 3 Feet | $1,709.13 |
| DPT-22389 | 14.937 | 14.437 | 3 Feet | $1,721.78 |
| DPT-22411 | 15.000 | 14.500 | 3 Feet | $1,099.66 |
| DPT-22394 | 15.062 | 14.562 | 3 Feet | $1,346.51 |
| DPT-22396 | 15.125 | 14.625 | 3 Feet | $1,632.61 |
| DPT-22419 | 15.187 | 14.687 | 3 Feet | $891.88 |
| DPT-22418 | 15.250 | 14.750 | 3 Feet | $904.98 |
| DPT-22417 | 15.312 | 14.812 | 3 Feet | $917.86 |
| DPT-22416 | 15.375 | 14.875 | 3 Feet | $930.96 |
| DPT-22415 | 15.437 | 14.937 | 3 Feet | $943.83 |
| DPT-22414 | 15.500 | 15.000 | 3 Feet | $956.93 |
| DPT-22404 | 15.562 | 15.062 | 3 Feet | $1,372.48 |
| DPT-22412 | 15.625 | 15.125 | 3 Feet | $982.91 |
| DPT-22420 | 15.687 | 15.187 | 3 Feet | $879.01 |
| DPT-22410 | 15.750 | 15.250 | 3 Feet | $1,054.41 |
| DPT-22409 | 15.812 | 15.312 | 3 Feet | $1,021.76 |
| DPT-22408 | 15.875 | 15.375 | 3 Feet | $1,034.83 |
| DPT-22407 | 15.937 | 15.437 | 3 Feet | $1,047.73 |
| DPT-22406 | 16.000 | 15.500 | 3 Feet | $1,060.81 |
| DPT-22405 | 16.062 | 15.562 | 3 Feet | $1,073.71 |
| DPT-22456 | 16.125 | 15.625 | 3 Feet | $2,346.83 |
| DPT-22507 | 16.187 | 15.687 | 3 Feet | $2,180.93 |
| DPT-22447 | 16.250 | 15.750 | 3 Feet | $2,461.51 |
| DPT-22503 | 16.312 | 15.812 | 3 Feet | $2,231.93 |
| DPT-22502 | 16.375 | 15.875 | 3 Feet | $2,244.78 |
| DPT-22501 | 16.437 | 15.937 | 3 Feet | $2,257.46 |
| DPT-22500 | 16.500 | 16.000 | 3 Feet | $2,270.31 |
| DPT-22499 | 16.562 | 16.062 | 3 Feet | $1,408.33 |
| DPT-22489 | 16.625 | 16.125 | 3 Feet | $2,066.23 |
| DPT-22497 | 16.687 | 16.187 | 3 Feet | $1,925.83 |
| DPT-22505 | 16.750 | 16.250 | 3 Feet | $2,206.43 |
| DPT-22495 | 16.812 | 16.312 | 3 Feet | $1,823.80 |
| DPT-22494 | 16.875 | 16.375 | 3 Feet | $1,836.66 |
| DPT-22493 | 16.937 | 16.437 | 3 Feet | $1,849.31 |
| DPT-22492 | 17.000 | 16.500 | 3 Feet | $1,862.18 |
| DPT-22491 | 17.062 | 16.562 | 3 Feet | $1,874.83 |
| DPT-22490 | 17.125 | 16.625 | 3 Feet | $1,887.68 |
| DPT-22513 | 17.187 | 16.687 | 3 Feet | $2,104.40 |
| DPT-22515 | 17.250 | 16.750 | 3 Feet | $2,078.88 |
| DPT-22498 | 17.312 | 16.812 | 3 Feet | $2,168.26 |
| DPT-22521 | 17.375 | 16.875 | 3 Feet | $1,164.96 |
| DPT-22520 | 17.437 | 16.937 | 3 Feet | $1,169.16 |
| DPT-22519 | 17.500 | 17.000 | 3 Feet | $1,066.41 |
| DPT-22518 | 17.562 | 17.062 | 3 Feet | $1,097.94 |
| DPT-22517 | 17.625 | 17.125 | 3 Feet | $2,193.78 |
| DPT-22516 | 17.687 | 17.187 | 3 Feet | $2,295.81 |
| DPT-22506 | 17.750 | 17.250 | 3 Feet | $2,040.73 |
| DPT-22514 | 17.812 | 17.312 | 3 Feet | $2,091.75 |
| DPT-22523 | 17.875 | 17.375 | 3 Feet | $1,115.51 |
| DPT-22512 | 17.937 | 17.437 | 3 Feet | $2,117.26 |
| DPT-22511 | 18.000 | 17.500 | 3 Feet | $2,129.90 |
| DPT-22509 | 18.125 | 17.625 | 3 Feet | $2,155.40 |
| DPT-22508 | 18.187 | 17.687 | 3 Feet | $2,053.38 |
| DPT-22481 | 18.250 | 17.750 | 3 Feet | $2,015.23 |
| DPT-22522 | 18.312 | 17.812 | 3 Feet | $1,228.68 |
| DPT-22496 | 18.375 | 17.875 | 3 Feet | $2,780.46 |
| DPT-22470 | 18.437 | 17.937 | 3 Feet | $2,282.96 |
| DPT-22469 | 18.500 | 18.000 | 3 Feet | $2,665.58 |
| DPT-22468 | 18.562 | 18.062 | 3 Feet | $2,525.38 |
| DPT-22467 | 18.625 | 18.125 | 3 Feet | $2,691.08 |
| DPT-22466 | 18.687 | 18.187 | 3 Feet | $2,703.93 |
| DPT-22465 | 18.750 | 18.250 | 3 Feet | $2,716.58 |
| DPT-22455 | 18.812 | 18.312 | 3 Feet | $2,359.48 |
| DPT-22463 | 18.875 | 18.375 | 3 Feet | $2,742.10 |
| DPT-22471 | 18.937 | 18.437 | 3 Feet | $2,640.06 |
| DPT-22461Q | 19.000 | 18.500 | 3 Feet | $1,275.48 |
| DPT-22460 | 19.062 | 18.563 | 3 Feet | $2,652.93 |
| DPT-22459 | 19.125 | 18.625 | 3 Feet | $2,436.01 |
| DPT-22458 | 19.187 | 19.687 | 3 Feet | $2,321.31 |
| DPT-22457 | 19.250 | 18.750 | 3 Feet | $2,333.96 |
| DPT-22479 | 19.312 | 18.812 | 3 Feet | $1,900.33 |
| DPT-22462 | 19.375 | 18.937 | 3 Feet | $2,754.96 |
| DPT-22464 | 19.437 | 18.937 | 3 Feet | $2,729.46 |
| DPT-22487 | 19.500 | 19.000 | 3 Feet | $2,308.46 |
| DPT-22486 | 19.562 | 19.062 | 3 Feet | $1,938.71 |
| DPT-22485 | 19.625 | 19.125 | 3 Feet | $1,951.36 |
| DPT-22484 | 19.687 | 19.187 | 3 Feet | $1,964.21 |
| DPT-22483 | 19.750 | 19.250 | 3 Feet | $1,976.86 |
| DPT-22482 | 19.812 | 19.312 | 3 Feet | $1,989.71 |
| DPT-22472 | 19.875 | 19.375 | 3 Feet | $2,627.41 |
| DPT-22480 | 19.937 | 19.437 | 3 Feet | $2,027.88 |
| DPT-22488 | 20.000 | 19.500 | 3 | $1,913.18 |
| diameter | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
