Paper X, XX, XXX Reinforced Phenolic Laminate Tubes 3/4" Wall Thickness
Paper X/XX/XXX Reinforced Phenolic
Tubes - natural
(tan)
Technical Data Sheet
This grade is composed of a paper base impregnated with a phenolic resin binder.
It has good electric strength properties with fair mechanical strength.
Outstanding for use as template material and or backup material.
NEMA X certs to MIL-I-24768/12 PBM, IEC 60893-3 Type 4 PF CP 201
NEMA XX certs to MIL-I-24768/11 PBG, IEC 60893-3 Type 4 PF CP 203
NEMA XXX certs to MIL-I-24768/10 PBE, IEC 60893-3 Type 4 PF CP 201
NEMA grades X, XX and XXX Paper Reinforced Phenolic -- natural color is typically light tan to brown. These grades are composed of a paper base impregnated with a phenolic resin binder. (Phenolics are the oldest, best-known general purpose thermoset resins. They are among the lowest in cost and easiest to process. Phenolics are quite adequate for a fair percentage of electrical applications. Generally speaking, they are not equivalent to epoxies in resistance to moisture, humidity, dimensional stability, shrinkage and retention of electrical properties in extreme environments.) The paper reinforced phenolic has good electric strength properties with fair mechanical strength and are outstanding for use as template material and/or back-up material.
Click Here for X, XX, XXX or Sheets, Rods
| Select X, XX, XXX Tubing Wall Thickness | ||
| | | |
Can be made in 3 foot lengths 30-36" or 4 Foot Lenghts 42-48"
.750" Wall Thickness Paper Phenolic Tubes |
||||
| Part # | OD (in.) | ID (in.) | Minimum Purchase | Price Per Foot |
|---|---|---|---|---|
| DPT-22046 | 2.000 | .500 | 6 Feet | $256.01 |
| DPT-22045 | 2.062 | .562 | 6 Feet | $267.81 |
| DPT-22044 | 2.125 | .625 | 6 Feet | $279.60 |
| DPT-22043 | 2.188 | .687 | 6 Feet | $291.41 |
| DPT-22042 | 2.250 | .750 | 6 Feet | $303.23 |
| DPT-22013 | 2.312 | .812 | 6 Feet | $315.03 |
| DPT-21985 | 2.375 | .875 | 6 Feet | $326.83 |
| DPT-22023 | 2.437 | .937 | 6 Feet | $338.63 |
| DPT-22000 | 2.500 | 1.000 | 6 Feet | $350.43 |
| DPT-21999 | 2.562 | 1.062 | 6 Feet | $362.13 |
| DPT-21998 | 2.625 | 1.125 | 6 Feet | $374.03 |
| DPT-21997 | 2.688 | 1.187 | 6 Feet | $385.76 |
| DPT-21996 | 2.750 | 1.250 | 6 Feet | $437.48 |
| DPT-21995 | 2.812 | 1.312 | 3 Feet | $450.36 |
| DPT-21984 | 2.875 | 1.375 | 3 Feet | $463.46 |
| DPT-21993 | 2.937 | 1.437 | 3 Feet | $476.33 |
| DPT-22002 | 3.000 | 1.500 | 3 Feet | $489.43 |
| DPT-21991 | 3.062 | 1.562 | 3 Feet | $502.30 |
| DPT-21990 | 3.125 | 1.625 | 3 Feet | $515.41 |
| DPT-21989 | 3.188 | 1.687 | 3 Feet | $528.28 |
| DPT-21988 | 3.250 | 1.750 | 3 Feet | $541.38 |
| DPT-21987 | 3.312 | 1.812 | 3 Feet | $554.26 |
| DPT-21986 | 3.375 | 1.875 | 3 Feet | $567.33 |
| DPT-22011 | 3.437 | 1.937 | 3 Feet | $580.23 |
| DPT-21992 | 3.500 | 2.000 | 3 Feet | $593.31 |
| DPT-21994 | 3.562 | 2.062 | 3 Feet | $606.21 |
| DPT-22020 | 3.625 | 2.125 | 3 Feet | $619.28 |
| DPT-22019 | 3.687 | 2.187 | 3 Feet | $632.16 |
| DPT-22018 | 3.750 | 2.250 | 3 Feet | $645.26 |
| DPT-22017 | 3.812 | 2.312 | 3 Feet | $658.13 |
| DPT-22339 | 3.875 | 2.375 | 3 Feet | $671.31 |
| DPT-22016 | 3.937 | 2.437 | 3 Feet | $684.11 |
| DPT-22015 | 4.000 | 2.500 | 3 Feet | $697.21 |
| DPT-22014 | 4.062 | 2.562 | 3 Feet | $710.08 |
| DPT-22003 | 4.125 | 2.625 | 3 Feet | $723.18 |
| DPT-22012 | 4.187 | 2.687 | 3 Feet | $736.06 |
| DPT-22021 | 4.250 | 2.750 | 3 Feet | $749.16 |
| DPT-22010 | 4.312 | 2.812 | 3 Feet | $762.03 |
| DPT-22009 | 4.375 | 2.875 | 3 Feet | $775.13 |
| DPT-22008 | 4.437 | 2.937 | 3 Feet | $788.01 |
| DPT-22007 | 4.500 | 3.000 | 3 Feet | $801.08 |
| DPT-22006 | 4.562 | 3.062 | 3 Feet | $813.98 |
| DPT-22005 | 4.625 | 3.125 | 3 Feet | $827.06 |
| DPT-22233 | 4.687 | 3.187 | 3 Feet | $839.96 |
| DPT-21928 | 4.750 | 3.250 | 3 Feet | $853.03 |
| DPT-22156 | 4.812 | 3.312 | 3 Feet | $865.91 |
| DPT-22420 | 4.875 | 3.375 | 3 Feet | $879.09 |
| DPT-22419 | 4.937 | 3.437 | 3 Feet | $891.96 |
| DPT-22418 | 5.000 | 3.500 | 3 Feet | $905.06 |
| DPT-22417 | 5.062 | 3.562 | 3 Feet | $917.94 |
| DPT-22416 | 5.125 | 3.625 | 3 Feet | $931.04 |
| DPT-22415 | 5.187 | 3.687 | 3 Feet | $943.91 |
| DPT-22414 | 5.250 | 3.750 | 3 Feet | $957.01 |
| DPT-22403 | 5.312 | 3.812 | 3 Feet | $969.89 |
| DPT-22412 | 5.375 | 3.875 | 3 Feet | $982.99 |
| DPT-22421 | 5.437 | 3.937 | 3 Feet | $995.86 |
| DPT-1976 | 5.500 | 4.000 | 3 Feet | $1,008.86 |
| DPT-22409 | 5.562 | 4.062 | 3 Feet | $1,021.84 |
| DPT-22408 | 5.625 | 4.125 | 3 Feet | $1,034.91 |
| DPT-22407 | 5.688 | 4.187 | 3 Feet | $1,047.81 |
| DPT-22406 | 5.750 | 4.250 | 3 Feet | $1,060.89 |
| DPT-22405 | 5.812 | 4.312 | 3 Feet | $1,073.78 |
| DPT-22430 | 5.875 | 4.375 | 3 Feet | $1,086.86 |
| DPT-22411 | 5.938 | 4.438 | 3 Feet | $1,099.74 |
| DPT-1981 | 6.000 | 4.500 | 3 Feet | $1,112.75 |
| DPT-22439 | 6.063 | 4.562 | 3 Feet | $1,125.71 |
| DPT-22438 | 6.125 | 4.625 | 3 Feet | $1,138.81 |
| DPT-22437 | 6.187 | 4.687 | 3 Feet | $1,151.69 |
| DPT-22436 | 6.250 | 4.750 | 3 Feet | $1,164.78 |
| DPT-22435 | 6.312 | 4.812 | 3 Feet | $1,177.66 |
| DPT-22434 | 6.375 | 4.875 | 3 Feet | $1,190.76 |
| DPT-22433 | 6.437 | 4.937 | 3 Feet | $1,203.63 |
| DPT-1986 | 6.500 | 5.000 | 3 Feet | $1,216.66 |
| DPT-22431 | 6.562 | 5.062 | 3 Feet | $1,229.61 |
| DPT-22440 | 6.625 | 5.125 | 3 Feet | $1,242.69 |
| DPT-22429 | 6.688 | 5.187 | 3 Feet | $1,255.58 |
| DPT-22428 | 6.750 | 5.250 | 3 Feet | $1,268.66 |
| DPT-22427 | 6.812 | 5.313 | 3 Feet | $1,281.56 |
| DPT-22426 | 6.875 | 5.375 | 3 Feet | $1,294.63 |
| DPT-22425 | 6.938 | 5.437 | 3 Feet | $1,307.53 |
| DPT-1992 | 7.000 | 5.500 | 3 Feet | $1,320.53 |
| DPT-22423 | 7.062 | 5.562 | 3 Feet | $1,333.49 |
| DPT-22394 | 7.125 | 5.625 | 3 Feet | $1,346.59 |
| DPT-22366Q | 7.187 | 5.687 | 3 Feet | $1,359.38 |
| DPT-22404 | 7.250 | 5.750 | 3 Feet | $1,372.56 |
| DPT-22381Q | 7.312 | 5.812 | 3 Feet | $1,385.36 |
| DPT-22380 | 7.375 | 5.875 | 3 Feet | $1,398.46 |
| DPT-22379 | 7.437 | 5.937 | 3 Feet | $1,411.33 |
| DPT-1998 | 7.500 | 6.000 | 3 Feet | $1,424.43 |
| DPT-22377Q | 7.562 | 6.062 | 3 Feet | $1,390.18 |
| DPT-22376 | 7.625 | 6.125 | 3 Feet | $1,403.03 |
| DPT-22365Q | 7.688 | 6.187 | 3 Feet | $1,415.68 |
| DPT-22374Q | 7.750 | 6.250 | 3 Feet | $1,428.53 |
| DPT-22383Q | 7.812 | 6.312 | 3 Feet | $1,441.18 |
| DPT-22372Q | 7.875 | 6.375 | 3 Feet | $1,454.03 |
| DPT-22371Q | 7.938 | 6.437 | 3 Feet | $1,466.71 |
| DPT-22370Q | 8.000 | 6.500 | 3 Feet | $1,479.55 |
| DPT-22369Q | 8.062 | 6.562 | 3 Feet | $1,492.21 |
| DPT-22368Q | 8.125 | 6.625 | 3 Feet | $1,505.05 |
| DPT-22367 | 8.188 | 6.687 | 3 Feet | $1,517.71 |
| DPT-22392 | 8.250 | 6.750 | 3 Feet | $1,530.64 |
| DPT-22373Q | 8.312 | 6.812 | 3 Feet | $1,543.21 |
| DPT-22375Q | 8.375 | 6.875 | 3 Feet | $1,556.08 |
| DPT-22401 | 8.437 | 6.938 | 3 Feet | $1,568.81 |
| DPT-22400 | 8.500 | 7.000 | 3 Feet | $1,581.66 |
| DPT-22399 | 8.562 | 7.062 | 3 Feet | $1,594.31 |
| DPT-22398 | 8.625 | 7.125 | 3 Feet | $1,607.16 |
| DPT-22397 | 8.688 | 7.187 | 3 Feet | $1,619.81 |
| DPT-22396 | 8.750 | 7.250 | 3 Feet | $1,632.69 |
| DPT-22395 | 8.812 | 7.312 | 3 Feet | $1,645.34 |
| DPT-22384Q | 8.875 | 7.375 | 3 Feet | $1,658.11 |
| DPT-22393 | 8.938 | 7.437 | 3 Feet | $1,670.83 |
| DPT-22402 | 9.000 | 7.500 | 3 Feet | $1,683.60 |
| DPT-22391 | 9.062 | 7.562 | 3 Feet | $1,696.34 |
| DPT-22390 | 9.125 | 7.625 | 3 Feet | $1,709.21 |
| DPT-22389 | 9.188 | 7.687 | 3 Feet | $1,721.86 |
| DPT-22388 | 9.250 | 7.750 | 3 Feet | $1,734.71 |
| DPT-22387 | 9.312 | 7.812 | 3 Feet | $1,747.36 |
| DPT-22386 | 9.375 | 7.875 | 3 Feet | $1,760.13 |
| DPT-22385Q | 9.437 | 7.937 | 3 Feet | $1,772.78 |
| DPT-22442 | 9.500 | 8.000 | 3 Feet | $1,785.74 |
| DPT-22432 | 9.625 | 8.125 | 3 Feet | $1,811.23 |
| DPT-22495 | 9.688 | 8.187 | 3 Feet | $1,823.88 |
| DPT-22494 | 9.750 | 8.250 | 3 Feet | $1,836.74 |
| DPT-22493 | 9.812 | 8.312 | 3 Feet | $1,849.39 |
| DPT-22492 | 9.875 | 8.375 | 3 Feet | $1,862.26 |
| DPT-22491 | 9.937 | 8.437 | 3 Feet | $1,874.91 |
| DPT-22490 | 10.000 | 8.500 | 3 Feet | $1,887.76 |
| DPT-22479 | 10.062 | 8.562 | 3 Feet | $1,900.41 |
| DPT-22488 | 10.125 | 8.625 | 3 Feet | $1,913.26 |
| DPT-22497 | 10.187 | 8.687 | 3 Feet | $1,925.91 |
| DPT-22486 | 10.250 | 8.750 | 3 Feet | $1,938.78 |
| DPT-22485 | 10.313 | 8.812 | 3 Feet | $1,951.44 |
| DPT-22484 | 10.375 | 8.875 | 3 Feet | $1,964.28 |
| DPT-22483 | 10.437 | 8.937 | 3 Feet | $1,976.94 |
| DPT-22482 | 10.500 | 9.000 | 3 Feet | $1,989.78 |
| DPT-22340 | 10.563 | 9.062 | 3 Feet | $2,002.35 |
| DPT-22481 | 10.625 | 9.125 | 3 Feet | $2,015.31 |
| DPT-22480 | 10.688 | 9.187 | 3 Feet | $2,027.96 |
| DPT-22506 | 10.750 | 9.250 | 3 Feet | $2,040.81 |
| DPT-22508 | 10.813 | 9.312 | 3 Feet | $2,053.46 |
| DPT-22489 | 10.875 | 9.375 | 3 Feet | $2,066.31 |
| DPT-22515 | 10.937 | 9.437 | 3 Feet | $2,078.96 |
| DPT-22514 | 11.000 | 9.500 | 3 Feet | $2,091.83 |
| DPT-22513 | 11.062 | 9.562 | 3 Feet | $2,104.48 |
| DPT-22512 | 11.125 | 9.625 | 3 Feet | $2,117.34 |
| DPT-22511 | 11.188 | 9.687 | 3 Feet | $2,129.98 |
| DPT-22510 | 11.250 | 9.750 | 3 Feet | $2,142.76 |
| DPT-22509 | 11.313 | 9.813 | 3 Feet | $2,155.48 |
| DPT-22498 | 11.375 | 9.875 | 3 Feet | $2,168.34 |
| DPT-22507 | 11.437 | 9.937 | 3 Feet | $2,181.01 |
| DPT-22517 | 11.500 | 10.000 | 3 Feet | $2,193.86 |
| DPT-22505 | 11.562 | 10.062 | 3 Feet | $2,206.51 |
| DPT-22504 | 11.625 | 10.125 | 3 Feet | $2,219.28 |
| DPT-22503 | 11.687 | 10.187 | 3 Feet | $2,232.01 |
| DPT-22502 | 11.750 | 10.250 | 3 Feet | $2,244.86 |
| DPT-22501 | 11.812 | 10.312 | 3 Feet | $2,257.54 |
| DPT-22500 | 11.875 | 10.375 | 3 Feet | $2,270.38 |
| DPT-22470 | 11.937 | 10.437 | 3 Feet | $2,283.04 |
| DPT-22516 | 12.000 | 10.500 | 3 Feet | $2,295.88 |
| DPT-22487 | 12.062 | 10.562 | 3 Feet | $2,308.54 |
| DPT-22458 | 12.125 | 10.625 | 3 Feet | $2,321.38 |
| DPT-22457 | 12.187 | 10.687 | 3 Feet | $2,334.04 |
| DPT-22456 | 12.250 | 10.750 | 3 Feet | $2,346.91 |
| DPT-22455 | 12.313 | 10.812 | 3 Feet | $2,359.56 |
| DPT-22454 | 12.375 | 10.875 | 3 Feet | $2,372.33 |
| DPT-22453 | 12.437 | 10.937 | 3 Feet | $2,384.98 |
| DPT-22452 | 12.500 | 11.000 | 3 Feet | $2,397.83 |
| DPT-22441 | 12.562 | 11.062 | 3 Feet | $2,410.48 |
| DPT-22450 | 12.625 | 11.125 | 3 Feet | $2,423.35 |
| DPT-22459 | 12.687 | 11.187 | 3 Feet | $2,436.09 |
| DPT-22448 | 12.750 | 11.250 | 3 Feet | $2,448.86 |
| DPT-22447 | 12.812 | 11.312 | 3 Feet | $2,461.59 |
| DPT-22446 | 12.875 | 11.375 | 3 Feet | $2,474.36 |
| DPT-22445Q | 12.937 | 11.437 | 3 Feet | $2,487.01 |
| DPT-22444 | 13.000 | 11.500 | 3 Feet | $2,499.88 |
| DPT-22443 | 13.062 | 11.562 | 3 Feet | $2,512.53 |
| DPT-22468 | 13.125 | 11.625 | 3 Feet | $2,525.46 |
| DPT-22449Q | 13.187 | 11.687 | 3 Feet | $2,538.03 |
| DPT-22451Q | 13.250 | 11.750 | 3 Feet | $2,550.88 |
| DPT-22477 | 13.312 | 11.812 | 3 Feet | $2,563.53 |
| DPT-22476 | 13.375 | 11.875 | 3 Feet | $2,576.40 |
| DPT-22475 | 13.437 | 11.937 | 3 Feet | $2,589.06 |
| DPT-22474 | 13.500 | 12.000 | 3 Feet | $2,601.90 |
| DPT-22473 | 13.562 | 12.062 | 3 Feet | $2,614.56 |
| DPT-22472 | 13.625 | 12.125 | 3 Feet | $2,627.49 |
| DPT-22471 | 13.687 | 12.187 | 3 Feet | $2,640.13 |
| DPT-22460 | 13.750 | 12.250 | 3 Feet | $2,653.01 |
| DPT-22469 | 13.812 | 12.312 | 3 Feet | $2,665.66 |
| DPT-22478 | 13.875 | 12.375 | 3 Feet | $2,678.43 |
| DPT-22467 | 13.937 | 12.437 | 3 Feet | $2,691.16 |
| DPT-22466 | 14.000 | 12.500 | 3 Feet | $2,704.01 |
| DPT-22465 | 14.062 | 12.562 | 3 Feet | $2,716.66 |
| DPT-22464 | 14.125 | 12.625 | 3 Feet | $2,729.54 |
| DPT-22463 | 14.187 | 12.687 | 3 Feet | $2,742.18 |
| DPT-22462 | 14.250 | 12.750 | 3 Feet | $2,755.04 |
| DPT-22356 | 14.312 | 12.813 | 3 Feet | $2,767.61 |
| DPT-22496 | 14.375 | 12.875 | 3 Feet | $2,780.54 |
| DPT-22382 | 14.437 | 12.937 | 3 Feet | $2,793.11 |
| DPT-22268 | 14.500 | 13.000 | 3 Feet | $2,805.98 |
| DPT-22267 | 14.562 | 13.062 | 3 Feet | $2,818.63 |
| DPT-22266 | 14.625 | 13.125 | 3 Feet | $2,831.48 |
| DPT-22265 | 14.687 | 13.187 | 3 Feet | $2,844.13 |
| DPT-22264 | 14.750 | 13.250 | 3 Feet | $2,856.98 |
| DPT-22263 | 14.812 | 13.312 | 3 Feet | $2,869.63 |
| DPT-22262 | 14.875 | 13.375 | 3 Feet | $2,882.51 |
| DPT-22251 | 14.937 | 13.437 | 3 Feet | $2,895.15 |
| DPT-22260 | 15.000 | 13.500 | 3 Feet | $2,908.01 |
| DPT-22269 | 15.062 | 13.562 | 3 Feet | $2,920.65 |
| DPT-22258 | 15.125 | 13.625 | 3 Feet | $2,933.50 |
| DPT-22257 | 15.187 | 13.687 | 3 Feet | $2,946.16 |
| DPT-22256 | 15.250 | 13.750 | 3 Feet | $2,959.00 |
| DPT-22255 | 15.312 | 13.812 | 3 Feet | $2,971.68 |
| DPT-22254 | 15.375 | 13.875 | 3 Feet | $2,984.53 |
| DPT-22253 | 15.437 | 13.937 | 3 Feet | $2,997.18 |
| DPT-22278 | 15.500 | 14.000 | 3 Feet | $3,010.03 |
| DPT-22259 | 15.562 | 14.062 | 3 Feet | $3,022.68 |
| DPT-22261 | 15.625 | 14.125 | 3 Feet | $3,035.53 |
| DPT-22287 | 15.687 | 14.187 | 3 Feet | $3,048.21 |
| DPT-22286 | 15.750 | 14.250 | 3 Feet | $3,061.06 |
| DPT-22285 | 15.812 | 14.312 | 3 Feet | $3,073.71 |
| DPT-22284 | 15.875 | 14.375 | 3 Feet | $3,086.56 |
| DPT-22283 | 15.937 | 14.437 | 3 Feet | $3,099.21 |
| DPT-22282 | 16.000 | 14.500 | 3 Feet | $3,112.06 |
| DPT-22281 | 16.062 | 14.562 | 3 Feet | $3,124.73 |
| DPT-22270 | 16.125 | 14.625 | 3 Feet | $3,137.58 |
| DPT-22279 | 16.187 | 14.687 | 3 Feet | $3,150.23 |
| DPT-22288 | 16.250 | 14.750 | 3 Feet | $3,163.08 |
| DPT-22277 | 16.312 | 14.812 | 3 Feet | $3,175.73 |
| DPT-22276 | 16.375 | 14.875 | 3 Feet | $3,188.58 |
| DPT-22275 | 16.437 | 14.937 | 3 Feet | $3,201.23 |
| DPT-22274 | 16.500 | 15.000 | 3 Feet | $3,214.10 |
| DPT-22273 | 16.562 | 15.062 | 3 Feet | $3,226.76 |
| DPT-22272 | 16.625 | 15.125 | 3 Feet | $3,239.60 |
| DPT-22271 | 16.687 | 15.187 | 3 Feet | $3,252.25 |
| DPT-22242 | 16.750 | 15.250 | 3 Feet | $3,265.11 |
| DPT-22214 | 16.812 | 15.312 | 3 Feet | $3,277.75 |
| DPT-22252 | 16.875 | 15.375 | 3 Feet | $3,290.63 |
| DPT-22229 | 16.937 | 15.437 | 3 Feet | $3,303.28 |
| DPT-22228 | 17.000 | 15.500 | 3 Feet | $3,316.13 |
| DPT-22227 | 17.062 | 15.562 | 3 Feet | $3,328.78 |
| DPT-21454 | 17.125 | 15.625 | 3 Feet | $3,341.63 |
| DPT-21453 | 17.187 | 15.687 | 3 Feet | $3,354.28 |
| DPT-21478 | 17.250 | 15.750 | 3 Feet | $3,367.15 |
| DPT-21459 | 17.312 | 15.812 | 3 Feet | $3,379.81 |
| DPT-21461 | 17.375 | 15.875 | 3 Feet | $3,392.65 |
| DPT-21487 | 17.437 | 15.937 | 3 Feet | $3,405.31 |
| DPT-21486 | 17.500 | 16.000 | 3 Feet | $3,418.15 |
| DPT-21485 | 17.562 | 16.062 | 3 Feet | $3,430.81 |
| DPT-21484 | 17.625 | 16.125 | 3 Feet | $3,443.68 |
| DPT-22226 | 17.687 | 16.187 | 3 Feet | $3,456.33 |
| DPT-22225 | 17.750 | 16.250 | 3 Feet | $3,469.18 |
| DPT-22224 | 17.812 | 16.312 | 3 Feet | $3,481.83 |
| DPT-22213 | 17.875 | 16.375 | 3 Feet | $3,494.68 |
| DPT-22222 | 17.937 | 16.437 | 3 Feet | $3,507.33 |
| DPT-22231 | 18.000 | 16.500 | 3 Feet | $3,520.21 |
| DPT-22220 | 18.062 | 16.562 | 3 Feet | $3,532.85 |
| DPT-22219 | 18.125 | 16.625 | 3 Feet | $3,545.71 |
| DPT-22218 | 18.187 | 16.687 | 3 Feet | $3,558.35 |
| DPT-22217 | 18.250 | 16.750 | 3 Feet | $3,571.21 |
| DPT-22216 | 18.312 | 16.812 | 3 Feet | $3,583.86 |
| DPT-22215 | 18.375 | 16.875 | 3 Feet | $3,596.73 |
| DPT-22240 | 18.437 | 16.937 | 3 Feet | $3,609.38 |
| DPT-22221 | 18.500 | 17.000 | 3 Feet | $3,622.23 |
| DPT-22223 | 18.562 | 17.062 | 3 Feet | $3,634.88 |
| DPT-22248 | 18.687 | 17.187 | 3 Feet | $3,660.38 |
| DPT-22247 | 18.750 | 17.250 | 3 Feet | $3,673.26 |
| DPT-22246 | 18.812 | 17.312 | 3 Feet | $3,685.90 |
| DPT-22245 | 18.875 | 17.375 | 3 Feet | $3,698.76 |
| DPT-22244 | 18.937 | 17.437 | 3 Feet | $3,711.40 |
| DPT-22243 | 19.000 | 17.500 | 3 Feet | $3,724.26 |
| DPT-22232 | 19.062 | 17.562 | 3 Feet | $3,736.90 |
| DPT-22241 | 19.125 | 17.625 | 3 Feet | $3,749.78 |
| DPT-22250 | 19.187 | 17.687 | 3 Feet | $3,762.43 |
| DPT-22239 | 19.250 | 17.750 | 3 Feet | $3,775.28 |
| DPT-22238 | 19.312 | 17.812 | 3 Feet | $3,787.93 |
| DPT-22237 | 19.375 | 17.875 | 3 Feet | $3,800.78 |
| DPT-22236 | 19.437 | 17.937 | 3 Feet | $3,813.43 |
| DPT-22235 | 19.500 | 18.000 | 3 Feet | $3,826.28 |
| DPT-22234 | 19.562 | 18.062 | 3 Feet | $3,838.96 |
| DPT-22306 | 19.625 | 18.125 | 3 Feet | $3,851.81 |
| DPT-22230 | 19.687 | 18.187 | 3 Feet | $3,864.46 |
| DPT-22280 | 19.750 | 18.250 | 3 Feet | $3,877.31 |
| DPT-22344 | 19.812 | 18.312 | 3 Feet | $3,889.96 |
| DPT-22343 | 19.875 | 18.375 | 3 Feet | $3,902.81 |
| DPT-22342 | 19.937 | 18.437 | 3 Feet | $3,915.48 |
| DPT-22341Q | 20.000 | 18.500 | 3 | $3,928.33 |
| diameter | plus or minus (�) tolerance, inches | |||
| ID inside diameter | OD outside diameter | |||
| steel | built-up | |||
| .125" -.749" | .003" | - | .005" | |
| .750" - 1.999" | .004" | - | .005" | |
| 2.000" - 4.000" | .006" | - | .008" | |
| | *turned | *as wound | ||
| 4.001" - 12.000" | .010" | - | .025" | plus only |
| 12.001" - 18.000" | .030" | .060" | .030" | plus only |
| 18.001" - 24.000" | .040" | .075" | .035" | plus only |
| 24.001" - 48.000" | .060" | .090" | .040" | plus only |
| *Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request) | ||||
